| Ref | Part Number | Description |
|---|
| 1 |
32121-6 |
PIN-ROLL, SLOTTED Price: $0.28 |
| 2 |
32121-45 |
PIN-SPRING Price: $0.27 |
| 2 |
532069180 |
LOCKNUT Price: $2.99 |
| 3 |
49-6440-03 |
PEDAL-FORWARD Price: $84.90 |
| 3 |
532127533 |
COVER SCREEN Price: $14.99 |
| 4 |
532400436 |
COVER ASM BAGGER This part replaces 532134678. Price: $229.99 |
| 4 |
74-9100 |
PAD-PEDAL, FORWARD Price: $27.08 |
| 5 |
532126840 |
CHUTE.UPPER.42" Price: $59.99 |
| 5 |
75-2970 |
PEDAL-TRACTION Price: $135.64 |
| 6 |
74-9110 |
PAD-PEDAL, REVERSE Price: $13.49 |
| 6 |
818021008 |
SCREW Price: $4.99 |
| 7 |
532140572 |
INDICATOR DUMP BAG Price: $6.99 |
| 7 |
75-6550 |
DISC-FRICTION Price: $7.96 |
| 8 |
75-6490 |
LEVER ASM Price: $78.45 |
| 8 |
874981024 |
SCREW.PAN.HEAD This part replaces 532087175. Price: $4.99 |
| 9 |
233-42 |
KNOB Price: $12.88 |
| 9 |
819061216 |
WASHER Price: $3.99 |
| 10 |
532007206 |
SPACER LT Price: $5.99 |
| 10 |
93-6699 |
DECAL-FAST / SLOW Price: $18.07 |
| 11 |
112-5084 |
BRACKET-LEVER This part replaces 75-6510. Price: $61.39 |
| 11 |
539108086 |
NUT 10-24 ACORN ZD This part replaces 532060867. Price: $3.99 |
| 12 |
75-6580 |
CABLE-PEDAL Price: $34.72 |
| 12 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 13 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 13 |
532109808 |
LATCH.HOOD. Price: $5.99 |
| 14 |
3272-2 |
PIN-COTTER Price: $2.29 |
| 14 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 15 |
3290-461 |
WASHER-SPRING Price: $3.89 |
| 15 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532130760. Price: $5.99 |
| 16 |
121-4600 |
NUT-HEX This part replaces 3296-59. Price: $0.78 |
| 16 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532130759. Price: $5.99 |
| 17 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
256-236 |
BEARING-MOUNT, FLANGE Price: $27.99 |
| 18 |
592866501 |
CHUTE.LOWER.LT.42 This part replaces 532162803. Price: $59.99 |
| 19 |
322-3 |
SCREW-HH Price: $0.79 |
| 20 |
596039001 |
Screws This part replaces 871161010. Price: $2.99 |
| 20 |
93-8742 |
FOOTPAD-BRAKE Price: $27.95 |
| 21 |
532132796 |
SPRING COVER LH Price: $5.99 |
| 22 |
532133235 |
SPACER.COVER.BAGGER Price: $5.99 |
| 23 |
532132983 |
SPRING COVER RH Price: $5.99 |
| 23 |
63-7880 |
PIN-LATCH, BRAKE Price: $6.04 |
| 24 |
532180925 |
POST.SUPPORT.BAGGER.2BIN This part replaces 532126813. Price: $32.99 |
| 24 |
63-7733 |
LH BRAKE CABLE ASM Price: $210.39 |
| 25 |
596040501 |
Hardware This part replaces 532063124. Price: $2.99 |
| 25 |
63-7732 |
RH BRAKE CABLE ASM Price: $210.39 |
| 26 |
3256-69 |
WASHER-FLAT Price: $0.62 |
| 26 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 27 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 27 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 28 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 28 |
532170053 |
MOUNTING BRACKET, BAGGER Price: $11.99 |
| 29 |
532170165 |
SHOULDER BOLT 5/16-18TT Price: $3.99 |
| 29 |
75-1440-03 |
PEDAL-BRAKE, LH Price: $207.74 |
| 30 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 30 |
532131137 |
SUPPORT POST PIN Price: $11.99 |
| 31 |
32121-50 |
PIN-SPRING Price: $1.21 |
| 31 |
532174083 |
PLUG, TUBING END Price: $5.99 |
| 32 |
532134639 |
FRAME Price: $59.63 |
| 32 |
75-1430 |
RH BRAKE PEDAL ASM Price: $255.51 |
| 33 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 33 |
532192786 |
BAGGER.HINGE.PIN This part replaces 532128600. Price: $14.99 |
| 34 |
532127534 |
GASKET.COVER.BAGGER Price: $11.99 |
| 34 |
75-3270-03 |
HUB-PIVOT, TRACTION Price: $144.73 |
| 35 |
532183286 |
CONTAINER TOP This part replaces 532129585. Price: $29.99 |
| 35 |
75-1470 |
PIN-PIVOT, BRAKE Price: $45.68 |
| 36 |
532129586 |
CONTAINER BOTTOM Price: $59.99 |
| 36 |
75-2170-03 |
TUBE-CONTROL, PUMP Price: $103.73 |
| 37 |
3220-3 |
NUT-HJ Price: $0.28 |
| 37 |
532134637 |
BAGGER TOP SEAL Price: $14.52 |
| 38 |
2411-36 |
BEARING-END, ROD Price: $32.13 |
| 38 |
532130895 |
LATCH CER38 Price: $5.99 |
| 39 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 39 |
532155857 |
STRIP.REINFORCEMENT.3.BIN. Price: $7.99 |
| 40 |
323-9 |
SCREW-HH Price: $1.29 |
| 40 |
871141008 |
Screw #10-24 x 1/2 Price: $2.99 |
| 41 |
532156006 |
TUBE.SUPPORT.BAGGER Price: $37.99 |
| 42 |
532145186 |
PLATE.ASM.REINFORCEMENT.BLACK Price: $11.99 |
| 43 |
819112410 |
WASHER Price: $3.99 |
| 44 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 45 |
532128638 |
NUT WING PM Price: $3.99 |
| 46 |
874760536 |
Bolt, Hex 5/16-18 x 2-1/4 Price: $3.99 |
| 47 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 Price: $3.99 |
