| Ref | Part Number | Description |
|---|
| 2 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 4 |
67-8820-01 |
RH HINGE ASM This part replaces 67-8820. Price: $26.10 |
| 5 |
43-3900-03 |
FAN BELT GUARD ASM This part replaces 43-3900. Price: $290.98 |
| 6 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 9 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 10 |
67-8810-01 |
LH HINGE ASM This part replaces 67-8810. Price: $26.95 |
| 11 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 12 |
67-8190-01 |
BRACKET-SUPPORT, ENGINE This part replaces 67-8190. Price: $50.66 |
| 13 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 14 |
3290-357 |
NUT-HHF, WHIZ Price: $0.61 |
| 16 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 18 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 20 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 21 |
322-2 |
SCREW-HH Price: $0.69 |
| 22 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 23 |
237-30 |
O-RING Price: $2.50 |
| 24 |
43-8610 |
GUIDE Price: $23.35 |
| 25 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 26 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 27 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 28 |
237-7 |
O-RING Price: $8.82 |
| 29 |
218-461 |
NUT-HH Price: $2.50 |
| 30 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 31 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 32 |
86-7040 |
ROD-PROP, SEAT Price: $29.51 |
| 33 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 501220001 |
501220001 |
SCREEN Price: $0.99 |
| 501220101 |
501220101 |
LOCKING RING Price: $0.69 |
| 501220201 |
501220201 |
PLUG (TIL 179-60X) Price: $2.25 |
| 501220301 |
501220301 |
Plug Price: $0.85 |
| 501220401 |
501220401 |
BALL Price: $11.99 |
| 501220501 |
501220501 |
SPRING Price: $3.99 |
| 501220801 |
501220801 |
GASKET, METERING SIDE Price: $3.99 |
| 501220901 |
501220901 |
METERING DIAPHRAGM Price: $14.99 |
| 501221001 |
501221001 |
CAP Price: $5.99 |
| 501221101 |
503486301 |
COVER SCREW This part replaces 501221101. Price: $3.99 |
| 501221201 |
501221201 |
FUEL PUMP DIAPHRAGM Price: $7.99 |
| 501221301 |
501221301 |
GASKET, PUMP SIDE Price: $3.99 |
| 501221401 |
501221401 |
CAP Price: $27.99 |
| 501221501 |
501221501 |
SCREW Price: $3.99 |
| 501221701 |
501221701 |
SPRING Price: $3.99 |
| 501221801 |
501221801 |
SCREW Price: $3.99 |
| 501221901 |
501221901 |
SPRING Price: $2.99 |
| 501222001 |
501222001 |
LEVER Price: $4.99 |
| 501222101 |
501222101 |
SHAFT Price: $6.99 |
| 501222201 |
501222201 |
SCREW Price: $1.30 |
| 501222401 |
578004601 |
FILTER This part replaces 501222401. Price: $0.99 |
| 501222501 |
501222501 |
SPRING Price: $3.99 |
| 501222901 |
501222901 |
CLIP NLA Price: $2.28 |
| 501223001 |
503652701 |
SCREW This part replaces 501223001. Price: $4.99 |
| 501238801 |
503534001 |
NIPPLE This part replaces 501238801. Price: $14.99 |
| 501254601 |
501254601 |
SLEEVE Price: $7.99 |
| 501268501 |
501268501 |
IDLE ADJ. SCREW Price: $17.99 |
| 501268901 |
501268901 |
NEEDLE H Price: $6.99 |
| 501269001 |
501269001 |
SPRING Price: $4.99 |
| 501417504 |
501417502 |
CARBURETOR NLA This part replaces 501417504. Price: $94.97 |
| 501426901 |
501426901 |
Price: $18.38 |
| 501427001 |
501427001 |
Price: $2.00 |
| 501427101 |
501427101 |
Bushing Price: $1.00 |
| 501466701 |
503117001 |
VALVE/INLET. This part replaces 501466701. Price: $19.99 |
| 501552101 |
501815801 |
SPRING This part replaces 501552101. Price: $2.07 |
| 501691001 |
501691001 |
THROTTLE SHAFT Price: $13.83 |
| 502012201 |
502012201 |
CHOKE FLAP Price: $2.62 |
