| Ref | Part Number | Description |
|---|
| 1 |
66-6370 |
LIFT ARM ASM Price: $430.43 |
| 2 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 3 |
32136-2 |
NUT-SHH Price: $3.55 |
| 4 |
21-3020-01 |
MOUNT-BALLJOINT, RH This part replaces 21-3020. Price: $178.87 |
| 5 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 6 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 7 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 8 |
3217-8 |
NUT-HEX Price: $1.34 |
| 9 |
66-7150 |
ARM-PUSH, RH Price: $536.26 |
| 10 |
3272-24 |
PIN-COTTER Price: $0.54 |
| 11 |
24-9510 |
PIN Price: $77.49 |
| 12 |
55-4300 |
DECAL-WARNING Price: $13.99 |
| 13 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 14 |
46-8840-01 |
SPRING-LIFT ARM This part replaces 46-8840. Price: $35.71 |
| 15 |
5-1754 |
WASHER-FLAT Price: $2.17 |
| 16 |
256-126 |
BUSHING Price: $9.36 |
| 17 |
3272-33 |
PIN-COTTER Price: $0.54 |
| 18 |
23-1950-01 |
SUPPORT-REINFORCEMENT This part replaces 23-1950. Price: $69.64 |
| 19 |
324-4 |
SCREW-HH Price: $0.95 |
| 20 |
3-7292 |
PIN-CLEVIS Price: $44.11 |
| 21 |
5-3126 |
PIN-LYNCH Price: $0.73 |
| 22 |
324-11 |
SCREW-HH Price: $3.05 |
| 24 |
21-2860-01 |
PUSH ARM BRACKET ASM This part replaces 21-2860. Price: $154.46 |
| 25 |
32121-84 |
PIN-SPIRAL Price: $1.29 |
| 26 |
21-2990 |
SHAFT-PIVOT Price: $227.21 |
| 27 |
32128-42 |
NUT-HF Price: $0.98 |
| 28 |
302-33 |
FITTING-GREASE Price: $2.31 |
| 29 |
21-2960 |
ARM-PUSH, LH Price: $519.38 |
| 30 |
21-2900-01 |
SPRING-TORSION, LH This part replaces 21-2900. Price: $566.83 |
| 31 |
21-2890-01 |
SPRING-TORSION, RH This part replaces 21-2890. Price: $566.83 |
| 32 |
21-3050-01 |
LH BALL JOUNT MOUNT ASM This part replaces 21-3050. Price: $153.41 |
| 33 |
86-8100-01 |
BALL JOINT ASM This part replaces 86-8100. Price: $137.53 |
| 34 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 35 |
21-3000-01 |
NUT-JAM, PUSH ARM This part replaces 21-3000. Price: $37.02 |
| 36 |
3-1365 |
CHAIN Price: $72.97 |
| 37 |
68-3270 |
BUMPER-RUBBER This part replaces 67-9800. Price: $37.99 |
| 38 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 39 |
5-2942 |
SHACKLE Price: $16.99 |
| 295646601 |
295646601 |
HEIGHT GAUGE Price: $27.99 |
| 295646602 |
295646602 |
HEIGHT GAUGE Price: $49.99 |
| 295646701 |
295646701 |
BRACKET Price: $29.32 |
| 295646702 |
295646702 |
BRACKET Price: $29.76 |
| 295646801 |
295646801 |
SPRING Price: $14.99 |
| 295646901 |
295646901 |
BRACKET Price: $18.38 |
| 295646902 |
295646902 |
BRACKET Price: $18.38 |
| 295647101 |
295647101 |
SPRING Price: $3.99 |
| 295647201 |
295647201 |
BOLT Price: $5.26 |
| 295647301 |
295647301 |
SHAFT Price: $7.95 |
| 295647401 |
295647401 |
KNOB Price: $7.99 |
| 295647601 |
295647601 |
SPACER Price: $2.49 |
| 295647701 |
295647701 |
LOWER HANDLE Price: $24.99 |
| 295648101 |
531007890 |
FLANGE/BOSS This part replaces 295648101. Price: $19.99 |
| 295651501 |
295651501 |
P/N NOT AVAILABLE Price: $64.62 |
| 295655801 |
295655801 |
BEARING Price: $14.99 |
| 295656901 |
295656901 |
ROLLER Price: $27.99 |
| 295700001 |
295700001 |
HANDLE Price: $9.99 |
| 295708301 |
295708301 |
WHEEL ASSY Price: $25.55 |
| 295710901 |
510252901 |
WHEEL HUB CAP This part replaces 295710901. Price: $7.99 |
| 371379101 |
371379101 |
PAWL Price: $3.99 |
| 371379603 |
371379603 |
HANDLE Price: $22.99 |
| 371396303 |
371396303 |
FRAME Price: $18.62 |
| 371397522 |
371397522 |
CUTTING REEL Price: $94.42 |
| 371900101 |
371900101 |
P/N NOT AVAILABLE Price: $4.00 |
| 371900701 |
371900701 |
BOLT Price: $2.81 |
| 371902101 |
371902101 |
LOCKING WASHER Price: $5.99 |
| 371906101 |
371906101 |
GEAR ** Price: $17.99 |
| 371906201 |
371906201 |
GEAR ** Price: $27.99 |
| 371913322 |
371913322 |
BLADE Price: $54.99 |
| 371914201 |
371914201 |
SPRING Price: $3.99 |
| 371914401 |
371914401 |
WASHER Price: $2.99 |
| 371926415 |
371926415 |
PROTECTOR Price: $20.77 |
| 725236651 |
725236651 |
SCREW Price: $2.99 |
| 725237951 |
725237951 |
SCREW Price: $4.99 |
| 725238051 |
725238051 |
SCREW M6X50 Price: $2.99 |
| 727737401 |
727737401 |
SCREW Price: $6.99 |
| 729527901 |
729527901 |
SCREW Price: $2.99 |
| 731231601 |
731231601 |
NUT Price: $2.99 |
| 732211601 |
732211601 |
LOCKNUT M6 Price: $4.99 |
| 735311321 |
735311321 |
P/N NOT AVAILABLE Price: $3.94 |
