| Ref | Part Number | Description |
|---|
| 1 |
188705 |
Seat Price: Call Us |
| 2 |
180166 |
Bracket Pivot Fender Price: Call Us |
| 2 |
KH-25-153-02-S |
O-Ring, Dipstick Price: $2.29 |
| 3 |
71110616 |
Bolt Fin Hex 3/8-16 unc x 1 Price: Call Us |
| 3 |
KH-M-545013-S |
Screw, Flnge Thrd. Frmng M5 x .8 x 13 Price: $2.09 |
| 4 |
19131610 |
Washer 13/32 x 1 x 10 Ga. Price: Call Us |
| 5 |
145006 |
Clip Push-In Price: Call Us |
| 5 |
KH-12-153-02-S |
O-RING-DIPSTICK Not Available Price: |
| 6 |
73800600 |
Nut Hex w/Ins. 3/8-16 unc Price: Call Us |
| 6 |
KH-12-153-01-S |
O-ring, Lower Fill Tube Price: $4.54 |
| 7 |
124181X |
Spring Seat Cprsn 2 250 Blk Zi Price: Call Us |
| 7 |
KH-24-126-243-S |
Lifting Strap This part replaces KH-24-126-19. Price: $9.30 |
| 8 |
17000616 |
Screw 3/8-16 x 1.5 Smgml Price: Call Us |
| 8 |
KH-24-032-19-S |
Oil Seal, 1.78 x 1.26 This part replaces KH-24-032-01-S. Price: $6.93 |
| 9 |
None |
Crankcase - Use Short Block |
| 9 |
19131614 |
Washer 13/32 x 1 x 14 Ga. Price: Call Us |
| 9 |
KH-32-522-07 |
SHORT BLOCK Not Available This part replaces KH-32-522-03. Price: |
| 10 |
180186 |
Pan Seat Price: Call Us |
| 10 |
KH-24-018-04 |
REED RETAINER Not Available Price: |
| 11 |
166369 |
Knob Seat Price: Call Us |
| 11 |
KH-12-402-02 |
Reed, Breather Price: $3.50 |
| 12 |
121246X |
Bracket Mounting Switch Price: Call Us |
| 12 |
KH-24-380-16-S |
Pin, Locating Price: $4.02 |
| 13 |
121248X |
Bushing Snap Blk Nyl 50 Id Price: Call Us |
| 13 |
KH-25-067-04-S |
CONNECTING ROD ASSEMBLY This part replaces KH-24-067-24-S. Price: $57.73 |
| 14 |
72050412 |
Bolt Rdhd Sqnk 1/4-20 x 1-1/2 Price: Call Us |
| 14 |
KH-25-874-07-S |
PISTON KIT (+0.08) Not Available This part replaces KH-32-874-09-S. Price: |
| 14 |
KH-25-874-13-S |
Piston Kit w/ Ring (STD) (Inc. 4 & 5) This part replaces KH-32-874-06-S. Price: $262.86 |
| 14 |
KH-32-874-28-S |
Kit, Piston w/Ring Set (.25) Price: Call Us |
| 15 |
134300 |
Spacer Split 28x 88 Price: Call Us |
| 15 |
KH-24-018-01-S |
Retainer, Piston Pin Price: $2.29 |
| 16 |
121250X |
Spring Cprsn Price: Call Us |
| 16 |
KH-24-108-16-S |
RING SET(.25)STYLE A-1.5mm Tp RING THICK Not Available This part replaces KH-24-108-06-S. Price: |
| 16 |
KH-24-108-22-S |
PISTON RING SET STD Not Available This part replaces KH-24-108-11-S. Price: |
| 17 |
123976X |
Nut Lock 1/4 Lge Flg Gr. 5 Zinc Price: Call Us |
| 17 |
KH-12-422-07-S |
SHIM, CAMSHAFT (WHITE .028") Price: $4.23 |
| 17 |
KH-12-422-08-S |
SHIM, CAMSHAFT (BLUE .03") Not Available Price: |
| 17 |
KH-12-422-09-S |
SHIM, CAMSHAFT (RED .032") Not Available Price: |
| 17 |
KH-12-422-10-S |
SHIM, CAMSHAFT (YELLOW .034") Not Available Price: |
| 17 |
KH-12-422-11-S |
CAMSHAFT SHIM Not Available Price: |
| 17 |
KH-12-422-12-S |
SHIM, CAMSHAFT (GRAY .038") Not Available Price: |
| 17 |
KH-12-422-13-S |
CAMSHAFT SHIM Not Available Price: |
| 18 |
KH-32-012-01-S |
CAMSHAFT Not Available Price: |
| 19 |
KH-28-032-09-S |
Seal, Governor Cross Shaft Price: $3.19 |
| 20 |
KH-24-018-09-S |
Retaining Ring Price: $2.11 |
| 21 |
171852 |
Bolt Shoulder 5/16-18 unc Price: Call Us |
| 21 |
KH-M-931010-S |
Washer, Flat, 9mm Price: $2.11 |
| 22 |
73800500 |
Nut Hex Lock W/Ins 5/16-18 Price: Call Us |
| 22 |
KH-24-468-15-S |
Washer, Flat, 11/32 Price: $2.29 |
| 23 |
KH-24-144-39-S |
GOVERNOR SHAFT CRO Not Available This part replaces KH-24-144-38-S. Price: |
| 25 |
KH-52-139-09-S |
PLUG-CUP Price: $4.72 |
