| Ref | Part Number | Description |
|---|
| 1 |
532850735 |
CONTROL BAR/BLACK Price: $4.69 |
| 3 |
532157081 |
HANDLE.LOWER.BLACK This part replaces 532157082. Price: $54.99 |
| 4 |
586122501 |
KIT.ROPE.GUIDE.T-KNOB This part replaces 532132001. Price: $7.99 |
| 5 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 532063601. Price: $1.99 |
| 6 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532131959. Price: $9.99 |
| 7 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $7.99 |
| 8 |
532158755 |
SCREW.PAN.HEAD This part replaces 532144929. Price: $4.99 |
| 9 |
532700417 |
THROTTLE CONTROL Price: $17.99 |
| 11 |
532130861 |
CABLE.MZR.51.RT.SP./PU. Price: $10.99 |
| 12 |
817021008 |
SCREW This part replaces 532750097. Price: $3.99 |
| 13 |
532850733 |
BRACKET.UPSTOP This part replaces 532125162. Price: $4.99 |
| 14 |
532183724 |
KIT.KNOB.HANDLE.SERVICE This part replaces 532136376. Price: $9.99 |
| 15 |
532051793 |
HAIRPIN COTTER Price: $5.99 |
| 16 |
532133188 |
DISCHARGE BAFFLE This part replaces 532125378. Price: $4.64 |
| 17 |
532125035 |
REAR BAFFLE Price: $9.99 |
| 18 |
532150050 |
SCREW.HXTAP.10-24 Price: $2.99 |
| 19 |
532700356 |
BACK PLATE This part replaces 532138865. Price: $13.98 |
| 20 |
532700363 |
SIDE BAFFLE This part replaces 532138866. Price: $3.68 |
| 21 |
532188984 |
SKIRT.REAR.20RD This part replaces 532140657. Price: $10.99 |
| 23 |
532147613 |
REAR DOOR ASSEMBLY KIT Price: $20.80 |
| 24 |
596322601 |
Nuts This part replaces 532751592. Price: $2.99 |
| 25 |
532153030 |
HANDLE BRACKET ASSEMBLY - LEFT Price: $2.99 |
| 26 |
532153029 |
HANDLE BRACKET ASSEMBLY-RIGHT Price: $2.42 |
| 27 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 29 |
532410807 |
BRACKET.ADJ.WHEEL.5POS.ADS This part replaces 532139901. Price: $3.99 |
| 30 |
532401629 |
SPACER.HEIGHT.ADJUSTER This part replaces 532146630. Price: $3.99 |
| 32 |
532401621 |
SPRING.SELECTOR.5POS.BZP This part replaces 532141730. Price: $4.99 |
| 33 |
532701037 |
SELECTOR KNOB Price: $4.99 |
| 34 |
532145935 |
ARM.AXLE.ASM.BZP This part replaces 532149857. Price: $4.99 |
| 35 |
532062335 |
WASHER.BELLEVILLE (3 2 LB) Price: $7.99 |
| 36 |
532174719 |
BOLT SHOULDER 3/8 -16X1 This part replaces 532142748. Price: $7.99 |
| 39 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532083923. Price: $3.99 |
| 40 |
532157008 |
HUBCAP.8".GREY Price: $3.99 |
| 41 |
532088652 |
HINGE SCREW Price: $3.99 |
| 43 |
532054583 |
SCREW Price: $4.99 |
| 45 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 46 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532107339. Price: $3.99 |
| 49 |
532428450 |
KIT.O-RING/WASHER This part replaces 532057143. Price: $3.99 |
| 51 |
532170540 |
KIT.BAFFLE.FRT.20RD.FO.PU/FBD. This part replaces 532144961. Price: $22.99 |
| 53 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 54 |
596238701 |
Washers This part replaces 532850263. Price: $3.99 |
| 55 |
532851074 |
WASHER,HARDEN Price: $3.99 |
| 56 |
532145106 |
BLADE.20.MULCH.(50DK,6020MD) Price: $17.99 |
| 57 |
581547901 |
ADAPTOR.BLADE.7/8 This part replaces 532850977. Price: $14.99 |
| 58 |
532157070 |
TRIM PLATE Price: $4.53 |
| 59 |
532701477 |
FASTENER Price: $2.38 |
| 65 |
532083816 |
SCREW.HEX.HEAD.WASHER.10-16 Price: $4.99 |
| 67 |
532134048 |
This part replaces 532800386. Price: $36.95 |
| 68 |
532088614 |
CATCHER.FRAME.WALK Price: $44.99 |
| 72 |
532128415 |
RIVET BLIND Price: $3.99 |
