| Ref | Part Number | Description |
|---|
| 1 |
127-3769 |
GASKET-MANIFOLD, INTAKE Price: $13.07 |
| 1 |
532121006 |
LEVER ROD LT Price: $24.99 |
| 2 |
127-3770 |
INTAKE MANIFOLD ASM Price: $332.09 |
| 2 |
532159188 |
Shaft Assembly, Lift Price: Call Us |
| 3 |
127-3771 |
MANIFOLD-INTAKE, AIR Price: $332.09 |
| 4 |
127-3180 |
STUD Price: $3.41 |
| 5 |
127-3031 |
SENSOR-TEMP, AIR Price: $1,039.57 |
| 6 |
125-7220 |
BOLT Price: $4.99 |
| 6 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 874780624. Price: $6.99 |
| 7 |
127-3772 |
DUCT SUCTION Price: $162.00 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
127-3096 |
JOINT-RUBBER Price: $332.63 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532124526. Price: $5.99 |
| 9 |
127-3773 |
JOINT, RUBBER Price: $75.60 |
| 9 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532122364. Price: $5.99 |
| 10 |
125-7189 |
CLAMP-HOSE Price: $4.61 |
| 10 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 11 |
127-3170 |
CLAMP-HOSE Price: $23.69 |
| 11 |
532145537 |
LIFT LINK LH Price: $22.99 |
| 12 |
125-7190 |
CLAMP-HOSE Price: $12.29 |
| 12 |
532145536 |
LIFT LINK RH Price: $22.99 |
| 13 |
127-3171 |
CLAMP-HOSE Price: $6.48 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
127-3034 |
GASKET-COLLECTOR Price: $9.66 |
| 14 |
532159189 |
LEVER ASSY-LIFT RH Price: $79.99 |
| 15 |
127-3093 |
INTAKE COLLECTOR ASM Price: $584.00 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 16 |
127-3092 |
COLLECTOR-INTAKE Price: $203.81 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
127-3139 |
VALVE-REED Price: $187.29 |
| 17 |
532175689 |
TRUNNION This part replaces 532130171. Price: $3.99 |
| 18 |
127-3080 |
JOINT-HOSE Price: $52.33 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
127-3081 |
JOINT-HOSE Price: $79.17 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
127-3166 |
WASHER-SEAL Price: $6.77 |
| 20 |
532003146 |
SPRING RETAINER This part replaces 532163552. Price: $2.99 |
| 21 |
127-3168 |
SCREW Price: $2.67 |
| 22 |
127-3181 |
STUD Price: $3.97 |
| 23 |
127-3045 |
SPACER-VALVE, E G R Price: $34.81 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
127-3046 |
GASKET-E G R Price: $4.88 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
125-7220 |
BOLT Price: $4.99 |
| 25 |
532002876 |
SPRING This part replaces 532124874. Price: $3.99 |
| 26 |
127-3178 |
BOLT Price: Call Us |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
127-3182 |
STUD Price: $2.86 |
| 27 |
532126971 |
ROD ADJ LIFT Price: $5.99 |
| 28 |
125-7229 |
NUT Price: $3.12 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
127-3035 |
BEND-INLET Price: Call Us |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
127-3036 |
BODY-THROTTLE Price: $1,205.87 |
| 31 |
127-3037 |
GASKET-THROTTLE Price: $2.87 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
125-7209 |
BOLT Price: $2.74 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 33 |
125-7211 |
BOLT Price: $3.48 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 37 |
532123935 |
PLUG,HOLE Price: $4.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 39 |
532142992 |
MOWER STOP Price: $4.99 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532123934 |
HEIGHT INDICATOR Price: $2.99 |
| 42 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 43 |
596140201 |
Washers This part replaces 819131612. Price: $2.99 |
| 44 |
872240608 |
BOLT Price: $3.99 |
| 46 |
812000022 |
E-RING Price: $3.99 |
| 47 |
819292016 |
Washer 29/32 x 1 - 1/4 x 16 Ga. Price: $6.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
| 51 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
