| Ref | Part Number | Description |
|---|
| 1 |
237-21 |
O-RING Price: $0.70 |
| 2 |
92-7637 |
HOSE ASM Price: $92.60 |
| 3 |
32151-36 |
RING-RETAINING Price: $1.73 |
| 4 |
98-2438 |
SUPPORT ARM WA - LH This part replaces 93-2717. Price: $1,174.09 |
| 5 |
93-2699 |
PIN Price: $48.15 |
| 6 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 7 |
2412-93 |
CLAMP-R Price: $1.02 |
| 8 |
32144-11 |
SCREW-THD ROLL, HWH Price: $6.99 |
| 9 |
92-7643 |
HYD HOSE ASM Price: $118.39 |
| 10 |
237-78 |
O-RING Price: $3.85 |
| 11 |
92-7632 |
HARNESS - WIRE Price: $758.90 |
| 12 |
67-1750 |
BUSHING Price: $0.92 |
| 13 |
33105-040 |
SCREW-HHF Price: $1.49 |
| 14 |
53-6380 |
WASHER-FLAT Price: $8.62 |
| 15 |
75-6370 |
CAP-SENSOR Price: $8.87 |
| 16 |
32104-76 |
SCREW-HWHTF Price: $2.29 |
| 17 |
94-1449 |
FITTING-STR,ORIF Price: $112.90 |
| 18 |
138-6956 |
CYLINDER ASM-HYDRAULIC This part replaces 93-2631. Price: $692.61 |
| 19 |
93-2700 |
ROLLER-PLASTIC Price: $30.55 |
| 20 |
33029-00 |
NUT-LOCK, NI Price: $2.92 |
| 21 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 22 |
93-2705 |
LINK REAR *B Price: $9.45 |
| 23 |
93-2704-03 |
LINK-LEFT This part replaces 93-2704. Price: $23.18 |
| 24 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 25 |
94-8949 |
BUSHING-FLANGE Price: $2.51 |
| 26 |
93-2710 |
DISCONTINUED Price: Call Us |
| 27 |
93-6687 |
DECAL-NO STEP This part replaces 36-3400. Price: $14.45 |
| 27 |
94-4584 |
DECAL-DANGER, JAPAN Price: $38.17 |
| 28 |
93-4234 |
SCREW-HSH Price: $6.08 |
| 29 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 30 |
94-8948 |
BUSHING - STRAIGHT Price: $7.56 |
| 31 |
94-8947 |
BUSHING-FLANGE Price: $4.54 |
| 32 |
93-7524 |
DISCONTINUED Price: Call Us |
| 33 |
93-9181 |
KNUCKLE - PIVOT *B Price: $573.32 |
| 34 |
99-5610 |
PIN This part replaces 93-9161. Price: $40.16 |
| 35 |
94-8946 |
WASHER-THRUST Price: $1.96 |
| 36 |
82-8170 |
CLAMP Price: $17.27 |
| 37 |
93-7961 |
CLAMP-DRAIN, CASE Price: $12.42 |
| 38 |
93-7960 |
SPACER Price: $5.67 |
| 39 |
60-6700 |
BOLT-HH Price: $1.29 |
| 40 |
92-8754 |
DISCONTINUED Price: Call Us |
| 41 |
92-8002 |
SWITCH-LIFT, BACK BIASED Price: $105.67 |
| 42 |
98-8188 |
PIN WA W/NUT This part replaces 95-3461. Price: $9.33 |
| 43 |
93-2707 |
LINK WA Price: $175.04 |
| 44 |
93-4248 |
DISCONTINUED Price: Call Us |
| 45 |
256-172 |
BUSHING Price: $4.57 |
| 46 |
33108-035 |
SCREW-HHF Price: $24.13 |
| 47 |
33025-00 |
NUT-LOCK, NI Price: $0.54 |
| 48 |
69-8980 |
WASHER Price: $0.58 |
| 49 |
94-1430 |
DISCONTINUED Price: Call Us |
| 50 |
340-78 |
NUT-LOCK Price: $1.63 |
| 51 |
94-1444 |
UNION-BULKHEAD Price: $33.59 |
| 52 |
92-7635 |
DISCONTINUED Price: Call Us |
| 53 |
340-75 |
BULKHEAD-TEE Price: $45.10 |
| 539101175 |
594944601 |
Bolts This part replaces 539101175. Price: $2.99 |
| 539101331 |
596135601 |
GSPW NUTS This part replaces 539101331. Price: $3.99 |
| 539101733 |
539101733 |
BLADE OEM 21" (61" DECK) Price: $18.99 |
| 539102243 |
596437501 |
Washers This part replaces 539102243. Price: $8.99 |
| 539102582 |
596577901 |
Nuts This part replaces 539102582. Price: $2.99 |
| 539102612 |
539102612 |
SCREW 3/8C X 2 3/4 HEX CAP Price: $4.99 |
| 539102641 |
594722002 |
LIFT This part replaces 539102641. Price: $4.99 |
| 539103230 |
539103230 |
IDLER ARM Price: $159.99 |
| 539103257 |
539103257 |
IDLER PULLEY Price: $49.99 |
| 539103258 |
539103258 |
IDLER PULLEY (TALL) Price: $44.99 |
| 539103295 |
539103295 |
IDLER BUSHING Price: $12.99 |
| 539103299 |
539103299 |
HCS 5/8F X 1 1/4 Price: $5.99 |
| 539103303 |
596770301 |
Washers This part replaces 539103303. Price: $4.99 |
| 539103427 |
539103427 |
PIVOT BUSHING Price: $7.99 |
| 539103433 |
539103433 |
HCS 1/2C X 3 1/4 Price: $5.99 |
| 539105192 |
539105192 |
DECK SPRING Price: $13.99 |
| 539106504 |
596770301 |
Washers This part replaces 539106504. Price: $4.99 |
| 539107278 |
539112125 |
PULLEY, 61 This part replaces 539107278. Price: $29.99 |
| 539107627 |
532105304 |
CAP-SLEEVE LT This part replaces 539107627. Price: $3.99 |
| 539108449 |
539108449 |
BOTTOM DUST CAP Price: $3.99 |
| 539108450 |
539108450 |
TOP DUST CAP Price: $4.99 |
| 539108754 |
539108754 |
SHAFT SEAL Price: $6.99 |
| 539108758 |
539108758 |
SPACER Price: $1.55 |
| 539108760 |
539112122 |
SPINDLE 52/61 This part replaces 539108760. Price: $27.99 |
| 539108766 |
539112120 |
HCS 7/16-20 GD 8 SPEC This part replaces 539108766. Price: $24.99 |
| 539108773 |
966956101 |
KIT HSG ASM 52/61 This part replaces 539108773. Price: $129.99 |
| 539109660 |
539109660 |
DRAW LATCH Price: $13.99 |
| 539109693 |
594722001 |
Chains This part replaces 539109693. Price: $3.99 |
| 539110734 |
539110734 |
DISCHARGE CHUTE 61" Price: $44.99 |
| 539110735 |
596646001 |
Springs This part replaces 539110735. Price: $3.99 |
| 539110736 |
595935501 |
Pins This part replaces 539110736. Price: $2.99 |
| 539111378 |
539111378 |
DECK W/DECALS 61" HUS Price: $5,499.99 |
| 539111561 |
539111561 |
DECAL, TUNNEL RAM 8" Price: $6.99 |
| 539976979 |
596240901 |
GSPW Nuts This part replaces 539976979. Price: $2.99 |
| 539976998 |
596899901 |
GSPW Zerks This part replaces 539976998. Price: $2.99 |
| 539977326 |
539977326 |
PLUG-VENTED Price: $8.99 |
| 539990247 |
596238901 |
Washers This part replaces 539990247. Price: $2.99 |
| 539990333 |
539990333 |
LOCKWASHER 5/8 Price: $2.99 |
| 539990365 |
596029501 |
Pins This part replaces 539990365. Price: $2.99 |
| 539990517 |
596433701 |
GSPW Washers This part replaces 539990517. Price: $2.99 |
| 539990550 |
595316401 |
Washers This part replaces 539990550. Price: $2.99 |
| 539990582 |
596583101 |
Screws This part replaces 539990582. Price: $3.99 |
| 539990627 |
539990627 |
HCS 5/16C X 1 1/4 Price: $3.99 |
| 539990692 |
596134901 |
GSPH This part replaces 539990692. Price: $2.99 |
| 539990717 |
596583702 |
Nuts This part replaces 539990717. Price: $2.99 |
