| Ref | Part Number | Description |
|---|
| 1 |
184704X428 |
Wheel Steering Price: Call Us |
| 2 |
184706 |
Axle Asm Cast Iron LT Price: Call Us |
| 2 |
3220-2 |
NUT-JAM Price: $0.50 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 3 |
76-7010 |
RING-RETAINING Price: $3.66 |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 4 |
76-7000 |
RING-RETAINING Price: $7.46 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
121748X |
Washer 25/32 x 1-5/8 x 16 Ga. Price: Call Us |
| 6 |
94-3027 |
WASHER-SEAL Price: $32.38 |
| 7 |
3274-81 |
SCREW-HSH Price: $0.74 |
| 8 |
105-9851 |
ROTATING KIT Price: $1,864.08 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 9 |
105-4572 |
SERVO PISTON ASM Price: $640.29 |
| 10 |
175121 |
Link Drag Price: Call Us |
| 10 |
94-3032 |
FOLLOWER-PISTON This part replaces 105-9852. Price: $574.71 |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 11 |
105-9853 |
PLATE-COVER Price: $142.29 |
| 12 |
73940800 |
Nut Hex Jam Toplock 1/2-20 unf Price: Call Us |
| 13 |
136518 |
Spacer Brg Axle Front Price: Call Us |
| 15 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 17 |
105-9853 |
PLATE-COVER This part replaces 94-3034. Price: $142.29 |
| 17 |
180641 |
Shaft Asm Steering Price: Call Us |
| 18 |
94-3026 |
CAMPLATE ASM Price: $1,164.81 |
| 19 |
76-6950 |
RACE-THRUST Price: $25.65 |
| 20 |
76-6960 |
BEARING-THRUST Price: $23.23 |
| 21 |
105-2857 |
VALVE-RELIEF Price: $1,042.90 |
| 22 |
105-2857 |
VALVE-RELIEF Price: $1,042.90 |
| 23 |
323-45 |
SCREW-HH Price: $0.68 |
| 26 |
126847X |
Bushing Link Drag Price: Call Us |
| 26 |
3274-59 |
SCREW-HSH Price: $1.15 |
| 27 |
105-9854 |
PLATE-VALVE Price: $441.04 |
| 28 |
105-9855 |
HOUSING ASM Price: $1,494.14 |
| 28 |
19131416 |
Washer 13/32 x 7/8 x 16 Ga. Price: Call Us |
| 29 |
105-9856 |
BACKPLATE ASM Price: $1,111.73 |
| 29 |
17000612 |
Screw 3/8-16 x .75 Price: Call Us |
| 30 |
76020412 |
Pin Cotter 1/8 x 3/4 Price: Call Us |
| 31 |
105-2861 |
SHAFT-DRIVE Price: $431.22 |
| 32 |
130465 |
Rod Tie Price: Call Us |
| 34 |
3217-5 |
NUT-HEX Price: $0.25 |
| 36 |
155099 |
Bushing Strg Price: Call Us |
| 36 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 37 |
152927 |
Screw Price: Call Us |
| 37 |
60-6240 |
WASHER This part replaces 94-3007. Price: $15.20 |
| 38 |
159946X428 |
Insert Cap Strg Wh Price: Call Us |
| 39 |
19182411 |
Washer 9/16 x 1 1/20 x 11 Ga. Price: Call Us |
| 40 |
73540600 |
Crownlock nut Price: Call Us |
| 41 |
159945 |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054X428 |
Boot Steering Dash Price: Call Us |
| 43 |
105-3331 |
SEAL-SHAFT Price: $35.63 |
| 43 |
121749X |
Washer 25/32 x 1 1/4 x 16 Ga. Price: Call Us |
| 44 |
180640 |
Extension Steering Shaft Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 47 |
94-3031 |
ARM-CONTROL Price: $32.40 |
| 48 |
93-6306 |
CONTROL ASM Price: $1,822.55 |
| 51 |
105-2909 |
ORIFICE-CONTROL, .036 DIA Price: $20.39 |
| 51 |
73540400 |
Nut Crownlock 1/4-28 Price: Call Us |
| 52 |
94-3041 |
ORIFICE-CONTROL (.028 DIA) Price: $26.81 |
| 54 |
71130420 |
Bolt Hex 1/4-28 unf x 1-1/4 Gr. 8 Price: Call Us |
| 57 |
105-2864 |
VALVE-BYPASS Price: $126.09 |
| 60 |
94-3030 |
WASHER Price: $6.24 |
| 61 |
3256-77 |
WASHER-FLAT Price: $1.60 |
| 65 |
160367 |
Spacer Brace Axle Price: Call Us |
| 67 |
72110618 |
Bolt RDHD SQNK 3/8-16 x 2 1/4 Price: Call Us |
| 68 |
169827 |
Axle, Brace Price: Call Us |
| 71 |
175146 |
Steering Asm Price: Call Us |
| 82 |
169835 |
Bracket Susp Chassis Front Price: Call Us |
| 87 |
173966 |
Washer Flat .781 x 1-1/2 x .14 Price: Call Us |
| 88 |
175118 |
Bolt Shoulder 7/16-20 unc Price: Call Us |
| 91 |
175553 |
Clip Steering Price: Call Us |
