| Ref | Part Number | Description |
|---|
| 1 |
532140064 |
Spring, Mower Clutch This part replaces 532122028. Price: $12.99 |
| 2 |
532003145 |
COTTER PIN This part replaces 876020312. Price: $1.40 |
| 2 |
92-5655 |
TUBE-CANOPY Price: $15.47 |
| 3 |
58-3930 |
BUSHING-OILITE Price: $15.24 |
| 3 |
873680600 |
Nut, Crownlock 3/8-16 UNC Price: $1.99 |
| 4 |
58-5330 |
SPACER-HINGE, CANOPY Price: $21.23 |
| 4 |
819131412 |
Washer 13/32 x 7/8 x 12 Ga. Price: $3.99 |
| 5 |
532121316 |
Idler, Flat Price: $22.99 |
| 5 |
58-5350 |
SPACER-HINGE, CANOPY Price: $19.88 |
| 6 |
58-1970-01 |
PLATE-HINGE, LEFT Price: $199.89 |
| 6 |
819132203 |
Washer 13/32 x 1-3/8 x 3 Ga. Price: $3.99 |
| 7 |
532126756 |
Guide, Belt Price: $25.96 |
| 7 |
58-1980-01 |
PLATE-HINGE, RIGHT Price: $199.89 |
| 8 |
532123702 |
Assembly, Mower Idler Arm Price: $8.99 |
| 8 |
86-6130 |
BALL-STUD Price: $7.46 |
| 9 |
872110618 |
Bolt, Carriage 3/8-16 x 2 1/4 Price: $2.99 |
| 9 |
92-6086 |
REAR SCREEN ASM This part replaces 92-4793-03. Price: $2,609.76 |
| 10 |
532122049 |
Rod, Brake Price: $9.39 |
| 10 |
92-5253 |
STRIP-SEALING Price: $59.20 |
| 11 |
532106578 |
Assembly, Brake Price: $32.99 |
| 11 |
58-3910 |
PIN-HINGE, CANOPY Price: $70.69 |
| 12 |
3290-355 |
PIN-HAIR Price: $2.09 |
| 12 |
532124293 |
V-Belt Price: $34.99 |
| 13 |
532124208 |
MANDREL ASS'Y This part replaces 532124207. Price: $109.99 |
| 13 |
77-3620 |
KNOB-RETAINER Price: $15.13 |
| 14 |
873680400 |
Nut, Crownlock 1/4-20 Price: $2.69 |
| 15 |
3234-13 |
SCREW-HHF Price: $0.77 |
| 15 |
532144727 |
This part replaces 532126410. Price: $171.99 |
| 16 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 16 |
872140404 |
Bolt, Carriage 1/4-20 x 1/2 Price: $3.99 |
| 17 |
532100668 |
Support, Plate Jackshaft Price: $2.38 |
| 17 |
88-6760 |
SPRING-GAS Price: $143.68 |
| 18 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 18 |
817490614 |
Screw Hex Thdrol. 3/8-16 x 7/8 Price: Call Us |
| 19 |
105-3330-03 |
BAFFLE-BODY, LOWER Price: $92.45 |
| 19 |
532143969 |
BLADE 36" NONVENT This part replaces 532126338. Price: $14.99 |
| 20 |
3250-25 |
SCREW-PPH Price: $0.23 |
| 20 |
874610624 |
Bolt, Fin. Hex 3/8-24 UNF x 1-1/2 Gr. 5 Price: $3.99 |
| 21 |
3253-2 |
WASHER-LOCK Price: $0.25 |
| 21 |
539990118 |
WASHER.3/8 This part replaces 810030600. Price: $1.49 |
| 22 |
58-5380 |
LATCH-DRAW Price: $43.60 |
| 22 |
819132012 |
Washer 13/32 x 1-1/4 x 12 Ga. Price: $2.99 |
| 23 |
58-7070-03 |
SPACER-LATCH, RH Price: $17.58 |
| 23 |
874760620 |
Bolt Fin Hex 3/8-16 UNC x 1-1/4 This part replaces 817490620. Price: $3.99 |
| 24 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 24 |
872140505 |
Bolt, Carriage 5/16-18 UNC x 5/8 Price: $2.69 |
| 25 |
322-3 |
SCREW-HH Price: $0.79 |
| 25 |
873800500 |
Nut Lock Hex W/Ins. 5/16-18 Unc P This part replaces 873680500. Price: $2.69 |
| 26 |
3250-31 |
SCREW-PPH Price: $0.25 |
| 26 |
872110608 |
Bolt, Carriage 3/8-16 UNC x 1 Gr. 5 Price: $3.99 |
| 27 |
532123439 |
Guide, R.H. Rear Belt Price: $29.99 |
| 27 |
68-6040 |
BRACKET Price: $13.03 |
| 28 |
3256-51 |
WASHER-FLAT Price: $0.19 |
| 28 |
532122051 |
Support, Idler Arm Price: $3.99 |
| 29 |
3296-27 |
NUT-LOCK, NI Price: $0.27 |
| 29 |
532123673 |
Guide, L.H. Belt Price: $8.99 |
| 30 |
98-3822 |
DECAL Price: $78.44 |
| 31 |
106-7074 |
CANOPY-FRONT This part replaces 104-5273. Price: $1,980.37 |
| 32 |
33024-00 |
NUT-LOCK, NI This part replaces 48-9510. Price: $0.75 |
| 33 |
92-5652-03 |
BRACKET Price: $10.46 |
| 34 |
33114-025 |
SCREW-HH Price: $0.70 |
| 35 |
3253-4 |
WASHER-LOCK This part replaces 42-9850. Price: $0.25 |
| 36 |
33094-00 |
WASHER-PLAIN Price: $0.25 |
| 37 |
105-3325 |
CENTER CANOPY ASM Price: $1,680.34 |
| 38 |
237-141 |
GROMMET-RUBBER Price: $2.39 |
| 39 |
92-5678 |
FOAM-HOOD, TOP Price: $239.26 |
| 40 |
92-5679 |
FOAM-HOOD, FRONT Price: $166.50 |
| 41 |
92-5680 |
FOAM-HOOD, RH Price: $187.22 |
| 42 |
92-5681 |
FOAM-HOOD, LH Price: $187.22 |
| 43 |
92-5672-03 |
SUPPORT-FOAM, CANOPY Price: $198.05 |
| 44 |
92-5673-03 |
SUPPORT-FOAM, FRONT Price: $46.11 |
| 45 |
92-6060 |
STRIP-SEALING Price: $59.20 |
| 46 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 47 |
322-4 |
SCREW-HH Price: $0.35 |
| 48 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 49 |
321-2 |
SCREW-HH Price: $2.79 |
| 50 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 54 |
104-5230-03 |
BRACKET-FUEL Price: $59.33 |
| 55 |
94-8226-03 |
BRACKET-CLEANER, AIR Price: $55.22 |
| 56 |
32122-42 |
SCREW Price: $1.69 |
| 57 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 58 |
321-3 |
SCREW-HH Price: $0.28 |
| 59 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 62 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 63 |
105-3301 |
LATCH ASM Price: $44.73 |
| 64 |
99-8970 |
KEY-LATCH, HOOD Price: $15.13 |
| 65 |
98-9321 |
RING-KEY Price: $1.80 |
| 66 |
100-6574 |
DECAL-WARNING Price: $15.80 |
| 67 |
133-8095 |
DECAL-CE This part replaces 93-7252. Price: $3.73 |
