| Ref | Part Number | Description |
|---|
| 1 |
322-3 |
SCREW-HH Price: $0.79 |
| 2 |
32107-11 |
NUT-SQUARE Price: $0.22 |
| 3 |
27-7170 |
MOUNTING BAND ASM Price: $48.11 |
| 4 |
3258-19 |
SCREW Price: $0.42 |
| 5 |
27-7100 |
AIR CLEANER ASM Price: $323.10 |
| 6 |
20-4840 |
CLAMP-MUFFLER Price: $15.06 |
| 7 |
43-3810-03 |
TUBE-CLEANER, AIR This part replaces 43-3810. Price: $89.59 |
| 8 |
27-7180 |
CAP Price: $70.51 |
| 9 |
82-5590 |
HOSE-CLEANER, AIR Price: $79.73 |
| 10 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 11 |
3217-6 |
NUT-HEX Price: $1.19 |
| 12 |
27-7160 |
DECAL-INSTALLATION Price: $19.89 |
| 13 |
32128-20 |
NUT-HF Price: $0.99 |
| 14 |
108-3833 |
FILTER-AIR This part replaces 27-7110. Price: $26.73 |
| 15 |
27-7120 |
NUT AND GASKET ASM Price: $15.55 |
| 16 |
27-7140 |
SKIRT-BAFFLE Price: $85.92 |
| 17 |
27-7130 |
CLAMP ASM Price: $49.80 |
| 18 |
80-3330 |
GASKET Price: $18.48 |
| 19 |
27-7150 |
A/C CUP ASM Price: $82.89 |
| 501768302 |
581756103 |
FUEL HOSE This part replaces 501768302. Price: $4.99 |
| 501819602 |
537215207 |
TANK CAP This part replaces 501819602. Price: $9.99 |
| 501873101 |
501873101 |
FUEL TANK VENT Price: $7.99 |
| 503210525 |
503210525 |
SCREW Price: $4.99 |
| 503210616 |
503214972 |
SCREW IHSCFT PW5.5X16 8.8 ZN/ This part replaces 503210616. Price: $4.99 |
| 503210625 |
503214925 |
SCREW This part replaces 503210625. Price: $3.99 |
| 503263017 |
503263017 |
O-RING Price: $3.99 |
| 503443201 |
591375401 |
KIT FUEL FILTER This part replaces 503443201. Price: $8.99 |
| 503497401 |
503497401 |
TANK UNIT CPL. Price: $168.99 |
| 503509302 |
503509302 |
THROTTLE LOCK Price: $7.99 |
| 503509401 |
503509401 |
SPRING Price: $4.99 |
| 503514801 |
503514801 |
ABSORBER Price: $12.99 |
| 503524101 |
503524101 |
ABSORBER Price: $11.99 |
| 503533303 |
503533303 |
THROTTLE LEVER Price: $10.99 |
| 503540103 |
503540103 |
FRONT HANDLE Price: $59.99 |
| 503540701 |
503540701 |
ABSORBER Price: $27.99 |
| 503541001 |
503541001 |
MOVEMENT LIMITER Price: $6.99 |
| 503546102 |
503546102 |
SUPPORT Price: $4.82 |
| 503735801 |
503735801 |
FUEL TANK BUSHING Price: $5.99 |
| 720131420 |
720131520 |
PIN This part replaces 720131420. Price: $4.99 |
| 725532305 |
725532555 |
SCREW MC6S 5X10 This part replaces 725532305. Price: $3.99 |
