| Ref | Part Number | Description |
|---|
| 1 |
98-7993 |
SCREW-HHF Price: $3.05 |
| 2 |
149723 |
Muffler Price: Call Us |
| 3 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 4 |
110-0009 |
JOINT ARM ASM This part replaces 108-0630-03. Price: $199.32 |
| 5 |
104-9319 |
PIN-GROOVED Price: $6.58 |
| 6 |
282-4 |
SHACKLE Price: $32.98 |
| 7 |
104-0028 |
GUIDE-HOSE Price: $46.21 |
| 9 |
194320 |
Keeper Belt Engine Price: Call Us |
| 10 |
105-7512 |
PIN-TIE, BOW Price: $4.27 |
| 11 |
283-6 |
PIN-CLEVIS Price: $1.70 |
| 12 |
405472 |
Pulley Engine Price: Call Us |
| 12 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 15 |
400021 |
Tank Fuel 3.0 Price: Call Us |
| 15 |
93-0142 |
BUSHING-STRAIGHT Price: $3.21 |
| 16 |
94-4919-03 |
BRACKET-CLAMP, HOSE Price: $19.76 |
| 17 |
322-13 |
SCREW-HH Price: $2.73 |
| 18 |
195951 |
Cap Asm Price: Call Us |
| 18 |
75-4520 |
SPRING-TORSION, RH Price: $25.31 |
| 19 |
75-4530 |
SPRING-TORSION, LH Price: $25.31 |
| 20 |
175437X421 |
Control Throttle Price: Call Us |
| 21 |
416358 |
Screw #10 x 0.750 BOS Thread Price: Call Us |
| 22 |
187767X428 |
Control Choke Price: Call Us |
| 22 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 23 |
100-3828 |
DISCONTINUED Price: Call Us |
| 24 |
100-3827 |
LH REAR LIFT ARM ASM Price: $720.05 |
| 25 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 26 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 27 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 28 |
32136-4 |
NUT-HEX,SLOTTED This part replaces 322-12. Price: $1.56 |
| 28 |
401135 |
Fuel Line Price: Call Us |
| 29 |
137180 |
Spark Arrester Kit Price: Call Us |
| 29 |
84-2451 |
CHAIN-STRAIGHT, 5 LINK Price: $9.25 |
| 30 |
100-3834-03 |
ROD-PIVOT Price: $69.13 |
| 37 |
123487X |
Clamp Hose Price: Call Us |
| 42 |
10040700 |
Washer Lock 7/16 Price: Call Us |
| 45 |
73510400 |
Nut Keps Hex 1/4-20 unc Price: Call Us |
| 62 |
146629 |
Shield Heat Muffler Price: Call Us |
| 69 |
165391 |
Gasket Price: Call Us |
| 70 |
159955 |
Exhaust Tube RH Price: Call Us |
| 71 |
160589 |
Exhaust Tube LH Price: Call Us |
| 79 |
183906 |
Screw Socket Head 5/16-18 x 1 Price: Call Us |
| 81 |
148456 |
Tube Drain Oil Easy Price: Call Us |
| 82 |
181654 |
Plug Drain Oil Price: Call Us |
| 84 |
17060620 |
Screw 3/8-16 x 1-1/4 Price: Call Us |
| 85 |
173937 |
Bolt Hex 7/16-20 x 4 x 5 Ga.-1.5 Price: Call Us |
| 87 |
171877 |
Bolt 5/16-18 x 3/4 Price: Call Us |
