| Ref | Part Number | Description |
|---|
| 1 |
17060408 |
SCREW.1/4-20X1/2 Price: Call Us |
| 1 |
94-6765 |
FITTING-BARBED, 90 DEG Price: $10.99 |
| 2 |
133025 |
SUB= 532133025 Price: Call Us |
| 3 |
94-1349 |
HOSE-FUEL Price: $7.38 |
| 4 |
110-4113 |
HOSE-FUEL This part replaces 63-7627. Price: $9.44 |
| 4 |
71070512 |
SCREW Price: Call Us |
| 5 |
10040500 |
LOCKWASHER Price: Call Us |
| 5 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 6 |
272293 |
GASKET ENG 1 313 LD TIN PLATED Price: Call Us |
| 6 |
324-5 |
SCREW-HH Price: $0.54 |
| 7 |
11050600 |
LOCKWASHER Price: Call Us |
| 7 |
3256-25 |
WASHER-FLAT Price: $0.25 |
| 8 |
121094X |
BOLT T Price: Call Us |
| 8 |
3296-48 |
NUT-LOCK, NI Price: $0.37 |
| 9 |
19101216 |
WASHER Price: Call Us |
| 9 |
3256-67 |
WASHER Price: $0.49 |
| 10 |
10040400 |
LOCKWASHER Price: Call Us |
| 10 |
23-7270 |
NUT-LUG Price: $10.37 |
| 11 |
86-9640-03 |
FRONT AXLE ASM Price: $2,641.21 |
| 12 |
137437 |
MUFFLER Price: Call Us |
| 13 |
101326L |
DEFLECTOR.222573 Price: Call Us |
| 14 |
17030808 |
SUB= 17030814 Price: Call Us |
| 14 |
321-5 |
SCREW-HH Price: $0.22 |
| 15 |
137180 |
SUB= 532137180 Price: Call Us |
| 15 |
237-136 |
GROMMET Price: $3.52 |
| 16 |
66-3060 |
DISCONTINUED Price: Call Us |
| 17 |
17490624 |
SCREW LT Price: Call Us |
| 17 |
98-5002 |
TANK-FUEL Price: $289.09 |
| 18 |
115-5304 |
CAP-FUEL This part replaces 93-7170. Price: $26.87 |
| 18 |
73510600 |
NUT Price: Call Us |
| 19 |
2751R |
CLIP T Price: Call Us |
| 19 |
3253-8 |
WASHER-LOCK Price: $0.47 |
| 20 |
3253-15 |
WASHER-LOCK Price: $1.49 |
| 21 |
32122-24 |
SCREW-PTH Price: $0.27 |
| 22 |
63-7640 |
SENDER-FUEL Price: $94.22 |
| 23 |
42-6080 |
SHIM-AXLE Price: $29.45 |
| 24 |
3273-38 |
SCREW-HSH Price: $6.65 |
| 26 |
110-9678 |
BRACKET-CARRIER This part replaces 98-2328-03. Price: $160.63 |
| 27 |
62-7650 |
GASKET Price: $4.28 |
| 28 |
2412-108 |
CLAMP-WORM Price: $1.29 |
| 30 |
46-6560 |
BUSHING Price: $2.94 |
| 31 |
2412-36 |
CLAMP-HOSE Price: $1.28 |
| 34 |
92-5083 |
HOSE-HYD Price: $25.27 |
| 35 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 36 |
92-5088 |
FITTING-ELBOW, 45 DEG Price: $124.81 |
| 37 |
354-71 |
DISCONTINUED Price: Call Us |
| 38 |
77-0550 |
DISCONTINUED Price: Call Us |
| 39 |
2810-1 |
COUPLING-PIPE Price: $4.55 |
| 40 |
289-6 |
NIPPLE-PIPE Price: $6.96 |
| 41 |
2412-119 |
CLAMP-HOSE, WORM DRIVE Price: $1.83 |
| 42 |
2412-98 |
CLAMP-HOSE Price: $1.39 |
| 43 |
321-6 |
SCREW-HH Price: $0.25 |
| 44 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 45 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 46 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 47 |
94-6821 |
CLAMP-WIRE Price: $3.32 |
| 48 |
32128-20 |
NUT-HF Price: $0.99 |
| 49 |
32128-14 |
NUT-HF Price: $0.41 |
| 50 |
95-0655 |
BRACKET-FUEL PUMP Price: $14.35 |
| 51 |
1-603954 |
HOSE-LINE, FUEL This part replaces 94-7420. Price: $5.83 |
| 52 |
321-4 |
SCREW-HH Price: $0.99 |
| 53 |
109-0299 |
HOSE-FUEL This part replaces 95-6269. Price: $12.99 |
