| Ref | Part Number | Description |
|---|
| 1 |
21-1880 |
GRIP-HANDLE Price: $11.67 |
| 1 |
548102301 |
SERVICE DECK KIT 42" NON-TEX This part replaces 532165894. Price: $379.99 |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 2 |
84-8500-01 |
LEVER-PTO This part replaces 84-8500. Price: $107.85 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 3 |
72-4320 |
SWITCH-BALL Price: $90.18 |
| 4 |
237-30 |
O-RING Price: $2.50 |
| 4 |
532165460 |
BRACKET SWAY BAR 42" DECK Price: $11.99 |
| 5 |
43-8610 |
GUIDE Price: $23.35 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 6 |
84-8520-01 |
BRACKET-SWITCH, PTO This part replaces 84-8520. Price: $11.07 |
| 7 |
283-42 |
PIN-CLEVIS Price: $40.05 |
| 8 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 9 |
43-3860 |
SHAFT-PIVOT, PTO Price: $55.10 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
302-10 |
FITTING-GREASE Price: $2.64 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
3257-5 |
KEY-WOODRUFF Price: $5.13 |
| 12 |
106-4383 |
BELT-V, BANDED This part replaces 53-9660. Price: $40.02 |
| 13 |
21-0230 |
PULLEY-PTO Price: $409.71 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 14 |
3256-28 |
WASHER-FLAT Price: $0.48 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 15 |
3254-7 |
WASHER-LOCK, INT Price: $4.82 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
3219-7 |
NUT-HEX Price: $1.53 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
3272-22 |
PIN-COTTER Price: $0.61 |
| 18 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
3-8812 |
SPACER-SPRING, ANCHOR Price: $15.47 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
5-1747 |
SPRING-ADJUSTMENT Price: $5.76 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
532134753 |
STIFFENER BRACKET Price: $5.99 |
| 22 |
92-5727 |
SCREW-LOCK, PATCH Price: $0.92 |
| 23 |
529845901 |
SERVICE KIT BRKT This part replaces 532131267. Price: $4.99 |
| 23 |
92-5723 |
BUSHING-FORK, PTO Price: $4.74 |
| 24 |
110-9681-03 |
FORK-PTO This part replaces 92-4060. Price: $195.34 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
27-7370 |
PTO BRAKE ASM Price: $218.20 |
| 25 |
532123713 |
SPRING TORSION Price: $6.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
93-3769 |
PIN-CLEVIS Price: $4.14 |
| 27 |
3296-28 |
NUT-LOCK, NI Price: $0.61 |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK This part replaces 532171859. Price: $34.99 |
| 28 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 29 |
3246-3 |
SCREW-HSH Price: $12.70 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
92-4058-01 |
ARM PTO This part replaces 92-4058. Price: $136.94 |
| 31 |
100-6599 |
PTO PIVOT ASM This part replaces 43-5500. Price: $780.32 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 32 |
43-5550 |
SHAFT-ACTUATOR, PTO Price: $143.65 |
| 32 |
532173436 |
PULLEY MANDREL Price: $14.99 |
| 33 |
3219-3 |
NUT-HEX Price: $0.34 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 34 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 34 |
87211064 |
Bolt Price: Call Us |
| 35 |
27-7900 |
SCREW-ADJUSTING Price: $21.70 |
| 36 |
3256-41 |
WASHER Price: $1.18 |
| 36 |
597025001 |
CLG This part replaces 532173438. Price: $22.99 |
| 37 |
5-0652 |
SPACER Price: $5.35 |
| 37 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 38 |
43-5570-01 |
ARM-ACTUATOR This part replaces 43-5570. Price: $164.96 |
| 39 |
302-2 |
FITTING-GREASE Price: $1.89 |
| 40 |
251-252 |
BEARING Price: $98.35 |
| 40 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 41 |
251-234 |
COLLAR-LOCKING Price: $17.04 |
| 42 |
32120-22 |
RING-SNAP, INTERNAL Price: $2.29 |
| 43 |
43-5540 |
SHAFT-PTO Price: $846.33 |
| 44 |
532140088 |
GUARD MANDREL LH BLACK Price: $29.99 |
| 45 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 46 |
3245-1 |
SCREW-SET, HSH Price: $0.54 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
256-113 |
BUSHING-FLANGE Price: $5.58 |
| 48 |
21-0400-01 |
SPRING-COMPRESSION This part replaces 21-0400. Price: $20.88 |
| 49 |
32121-9 |
PIN-ROLL, SLOTTED Price: $2.56 |
| 50 |
21-1830 |
SPRING-EXTENSION Price: $34.62 |
| 51 |
43-5630 |
YOKE-PTO Price: $80.75 |
| 52 |
5-0701 |
ANCHOR Price: $4.07 |
| 53 |
212-93 |
CLAMP-CASING Price: $3.46 |
| 54 |
21-1600 |
CLAMP-LEVER, PTO Price: $279.65 |
| 54 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 55 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 55 |
531166601 |
SERVICE KIT ARM ARM IDLER 42" This part replaces 532155046. Price: $14.99 |
| 56 |
32104-6 |
SCREW-HH, TAP Price: $3.19 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532173442. Price: $4.99 |
| 61 |
532174882 |
SPRING EXT ELEC CLUTCH Price: $14.99 |
| 66 |
43-8600 |
SPRING-COMPRESSION Price: $3.03 |
| 67 |
43-8860 |
PLUNGER-SWITCH Price: $11.85 |
| 68 |
43-8620 |
PIN-GUIDE, SWITCH Price: $88.57 |
| 68 |
532174883 |
V-BELT PRIMARY 42" Price: $39.99 |
| 69 |
237-7 |
O-RING Price: $8.82 |
| 70 |
218-461 |
NUT-HH Price: $2.50 |
| 71 |
43-8870 |
BOOT-SWITCH Price: $47.92 |
| 72 |
321-4 |
SCREW-HH Price: $0.99 |
| 73 |
86-7050 |
BRACKET-SWITCH, ACTUATOR Price: $16.28 |
| 74 |
3296-16 |
NUT-LOCK, NI Price: $1.39 |
| 75 |
75-9890 |
WASHER-SHIM Price: $3.18 |
| 90 |
596580801 |
Bolts This part replaces 874760516. Price: $2.99 |
| 91 |
532175746 |
BRACKET ASM, ROLLER (L) This part replaces 532132274. Price: $7.99 |
| 92 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 93 |
819171416 |
Washer Price: $3.99 |
| 94 |
532132264 |
NOSE ROLLER Price: $29.99 |
| 95 |
531154101 |
SERVICE KIT BRACKET BRACKET AS This part replaces 532132273. Price: $12.99 |
| 101 |
532136420 |
COVER MULCH 42" Price: $13.99 |
| 102 |
596039001 |
Screws This part replaces 871081010. Price: $2.99 |
| 103 |
819061216 |
WASHER Price: $3.99 |
| 104 |
810071000 |
LOCKWASHER #10 Price: $3.99 |
| 105 |
597000601 |
LATCH.ASM.MULCH/BAGGER This part replaces 532160793. Price: $5.99 |
| 106 |
596987401 |
Nuts This part replaces 532125004. Price: $2.99 |
| 113 |
532171877 |
BOLT.5/16-18UNCX3/4 W/SEMS.BLK This part replaces 817060512. Price: $4.99 |
| 116 |
596434404 |
Bolts This part replaces 532137644. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 129 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 130 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 131 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 134 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 135 |
532159765 |
BRACKET ASSY This part replaces 532178074. Price: $12.99 |
| 136 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL Price: $17.99 |
| 137 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872110505. Price: $2.99 |
| 138 |
532437046 |
BRACKET.ASM.WHL.GA.R.RH.42"BLK This part replaces 532178075. Price: $14.99 |
| 139 |
532159767 |
BRACKET.WHEEL.GAUGE.FRONT.42 This part replaces 532178077. Price: $17.99 |
| 140 |
532159768 |
BRKT.ASM.WHL.GA.FRONT.LH This part replaces 532178076. Price: $14.99 |
| 143 |
529844301 |
SERVICE KIT BRACKET This part replaces 532157109. Price: $7.99 |
| 144 |
532173441 |
KEEPER BELT 42" CLUTCH Price: $6.99 |
| 145 |
532173437 |
PULLEY.IDLER.FLAT.PLATED Price: $24.99 |
| 146 |
532173443 |
BOLT CARRIAGE IDLER This part replaces 532171977. Price: $4.99 |
| 148 |
532169022 |
IDLER RETURN SPRING Price: $4.99 |
| 149 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 150 |
596204201 |
Washers This part replaces 819091216. Price: $2.99 |
| 159 |
596987501 |
Bolts This part replaces 872140614. Price: $3.99 |
