| Ref | Part Number | Description |
|---|
| 2 |
108-1625 |
HYD MOW BLOCK MANIFOLD ASM Price: $3,194.18 |
| 2 |
589818702 |
MUFFLER.ASM.TWIN.MNTG.BRACKET This part replaces 589818701. Price: $44.99 |
| 3 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 4 |
354-79 |
CAP-DUST Price: $7.81 |
| 5 |
56-7972 |
CLAMP-TUBE Price: $13.55 |
| 6 |
340-9 |
FITTING-HYD, STRAIGHT Price: $67.47 |
| 7 |
340-7 |
FITTING-STRAIGHT Price: $14.00 |
| 8 |
94-5780 |
SCREW-HWH Price: $7.49 |
| 9 |
340-155 |
FITTING-STRAIGHT Price: $28.90 |
| 9 |
596501502 |
Keepers This part replaces 501832602. Price: $9.99 |
| 10 |
3234-14 |
SCREW-HHF Price: $0.61 |
| 11 |
117-0138 |
TUBE ASM Price: $148.55 |
| 11 |
587241401 |
CLUTCH.OGURA.5.0PD.GT1.5A-EH01 Price: $229.99 |
| 12 |
117-0137 |
TUBE ASM Price: $158.39 |
| 12 |
532194343 |
PULLEY ENGINE Price: $39.99 |
| 13 |
117-0139 |
TUBE ASM Price: $126.74 |
| 14 |
110-5286 |
TUBE ASM Price: $225.07 |
| 15 |
2412-4 |
CLAMP-R Price: $4.22 |
| 16 |
114-8888 |
TUBE ASM Price: $157.36 |
| 17 |
340-72 |
FITTING-BULKHEAD, 90 DEG Price: $41.27 |
| 18 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 19 |
32144-57 |
SCREW Price: $1.04 |
| 20 |
340-78 |
NUT-LOCK Price: $1.63 |
| 20 |
532177328 |
CONTROL.THROTTLE.LH.COBRA.KNOB This part replaces 532182937. Price: $24.99 |
| 21 |
340-74 |
NUT-LOCK, BULKHEAD Price: $4.83 |
| 21 |
596321701 |
Screws Price: $2.99 |
| 22 |
532191596 |
CONTROL.CHOKE.ERGO.PUSH-IN.BLA Price: $32.99 |
| 22 |
69-9010 |
WASHER Price: $1.83 |
| 23 |
240-3 |
GROMMET-RUBBER Price: $17.44 |
| 24 |
125-1984 |
SPACER This part replaces 69-9000. Price: $0.68 |
| 25 |
340-126 |
NUT-BULKHEAD Price: $4.61 |
| 26 |
108-1700 |
TUBE ASM Price: $199.55 |
| 27 |
3234-5 |
SCREW-HHF Price: $0.42 |
| 28 |
587044860 |
HOSE.1/4".LOW.PERM.FUEL.LN.60" Price: $17.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR 794945 B&S Price: $109.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $6.99 |
| 42 |
596238901 |
Washers Price: $2.99 |
| 45 |
596133601 |
Hardware Price: $2.99 |
| 62 |
531154901 |
SERVICE KIT HEAT SHIELD This part replaces 532434017. Price: $11.99 |
| 69 |
532186054 |
GASKET.EXHAUST.KOHL.CV18-CV26 Price: $5.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $5.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $14.99 |
| 85 |
501606901 |
BOLT.HEX.7/16-20X3.GR5.YELLOW Price: $3.99 |
| 86 |
532184362 |
NUT.HEX.FLANGE.TOPLOCK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 91 |
532187495 |
BUSHING.1.375OD Price: $4.99 |
| 92 |
817120616 |
SCREW 3/8-16X1 Price: $4.99 |
| 102 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
