| Ref | Part Number | Description |
|---|
| 1 |
120-9140 |
TRANSMISSON ASM This part replaces 120-0030. Price: $5,935.33 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT Price: $69.99 |
| 2 |
87-1910 |
PIN-DOWEL Price: $1.22 |
| 3 |
33115-050 |
SCREW-HH Price: $1.36 |
| 4 |
33115-035 |
SCREW-HH Price: $1.15 |
| 5 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 6 |
120-0239 |
SUPPORT-TUBE Price: $10.36 |
| 7 |
114-4060 |
BRACKET-THROTTLE Price: $24.26 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK This part replaces 580962301. Price: $7.99 |
| 8 |
33104-035 |
SCREW-HHF Price: $0.88 |
| 9 |
115-0339 |
CABLE-THROTTLE/CHOKE Price: $30.24 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 10 |
701197 |
E-RING Price: $2.99 |
| 11 |
114-4088 |
SHIELD-SEAL Price: $23.99 |
| 12 |
33115-016 |
SCREW-HH Price: $0.75 |
| 13 |
110-3575 |
DRIVESHAFT ASM Price: $841.45 |
| 14 |
322-9 |
SCREW-HH Price: $3.09 |
| 15 |
3296-29 |
NUT-LOCK, NI Price: $2.09 |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 88 |
532410710 |
SPRING.LIFT.ASSIST Price: $9.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 91 |
589464807 |
Links This part replaces 589464803. Price: $14.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 |
581506903 |
Links Price: $9.99 |
| 100 |
595305901 |
Nuts Price: $2.99 |
| 101 |
532407003 |
LINK.ASM.LIFT.FIXE.38/42/46" Price: $11.99 |
