| Ref | Part Number | Description |
|---|
| 1 |
710-0599 |
SCREW 1/4-20 X.500 This part replaces 9552. Price: $3.86 |
| 2 |
N/A |
REF. NO. 2 IS NOT USED |
| 3 |
1904547 |
DECAL-TINE HOOD Not Available Price: |
| 3 |
55101 |
DECAL-HOOD OPER INST Not Available Price: |
| 4 |
N/A |
REF. NO. 4 IS NOT USED |
| 5 |
686-04076A-0638 |
Tine Shield Assembly This part replaces 55076. Price: $78.33 |
| 6 |
1100088 |
SCREW-HH Not Available Price: |
| 7 |
712-04054 |
NUT-HFLK 5/16-18 ZP This part replaces 1186391. Price: $3.95 |
| 8 |
786-04292A-0638 |
Depth Adjuster Bar This part replaces 55074. Price: $58.80 |
| 8A |
715-0108 |
Pin, Sprg, 1/4 Dia x 1.00 This part replaces 9308. Price: $4.38 |
| 9 |
732-04320 |
Torsion Spring This part replaces 9384. Price: $3.85 |
| 10 |
GW-9534 |
Spacer This part replaces 9534. Price: $3.70 |
| 11 |
1100069 |
SCR-HH 1/4-20X1.0 Price: $3.66 |
| 12 |
712-0324 |
Hex Ins. L-Nut 1/4-20 Thd. This part replaces 1817146. Price: $3.38 |
| 13 |
55072-2 |
BRACKET-HOOD, RIGHT HAND Not Available Price: |
| 14 |
55072-1 |
BRACKET-HO Not Available Price: |
| 15 |
936-0119 |
LOCK WASHER 5/16 This part replaces 1100242. Price: $4.29 |
| 16 |
710-04048 |
SCREW 5/16-18 x 1 GR5 This part replaces 1186331. Price: $4.19 |
| 17 |
712-3010 |
HEX NUT 5/16-18 This part replaces 1186230. Price: $3.89 |
| 18 |
1100808 |
SCREW-HH Not Available Price: |
| 19 |
GW-55088 |
BUSHING Not Available This part replaces 55088. Price: |
