| Ref | Part Number | Description |
|---|
| 1 |
132-5205 |
ENGINE-KUBOTA, V1505 Price: $6,711.43 |
| 1 |
532176027 |
DECK.SVC.42".BLACK This part replaces 532165892. Price: $329.99 |
| 2 |
595901601 |
GSPW Bolts This part replaces 872140506. Price: $2.99 |
| 2 |
99-8343 |
GASKET-MUFFLER Price: $14.99 |
| 3 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 4 |
33114-016 |
SCREW-HH Price: $0.27 |
| 4 |
532165460 |
BRACKET SWAY BAR 42" DECK Price: $11.99 |
| 5 |
120-8536 |
MUFFLER Price: $214.30 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
131-3333 |
PIPE-TAIL Price: $256.05 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532178024. Price: $9.99 |
| 7 |
2112-6 |
CLAMP-MUFFLER Price: $7.53 |
| 8 |
119-0503 |
HANGER-MUFFLER Price: $7.21 |
| 8 |
532850857 |
BLADE BOLT Price: $3.99 |
| 9 |
117-0744 |
HANGER-MUFFLER Price: $4.52 |
| 9 |
596238701 |
Washers This part replaces 810030600. Price: $3.99 |
| 10 |
52-2860 |
WASHER Price: $0.84 |
| 10 |
532140296 |
WASHER.BLADE Price: $5.99 |
| 11 |
32128-25 |
NUT-HF Price: $3.19 |
| 12 |
32104-32 |
SCREW-HWH Price: $1.99 |
| 13 |
532137646 |
KIT MANDREL W/NUT This part replaces 532137645. Price: $29.99 |
| 13 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 14 |
119-4036 |
SCREW-HHF Price: $0.53 |
| 14 |
532128774 |
HOUSING.MANDREL.VENTED (MACHD) Price: $29.99 |
| 15 |
120-8557 |
BRACKET-HANGER Price: $13.46 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 16 |
98-4525 |
BRACKET-CLEANER, AIR Price: $52.87 |
| 17 |
106-5277 |
AIR CLEANER ASM Price: $134.07 |
| 18 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
2412-42 |
CLAMP-HOSE Price: $2.65 |
| 20 |
531167001 |
SERVICE KIT BAFFLE.VORTEX BAFF This part replaces 532159770. Price: $11.99 |
| 21 |
139-0686 |
RAIN CAP ASM This part replaces 105-2539. Price: $25.83 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
106-5241 |
HOSE-CLEANER, AIR Price: $95.34 |
| 23 |
2412-130 |
CLAMP-HOSE Price: $2.57 |
| 23 |
529845901 |
SERVICE KIT BRKT This part replaces 532177563. Price: $4.99 |
| 24 |
110-9009-0P |
BRACKET-CABLE, THROTTLE This part replaces 110-9009-03. Price: $13.98 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
112-9919 |
STOP-CABLE, THROTTLE Price: $3.18 |
| 25 |
532123713 |
SPRING TORSION Price: $6.99 |
| 26 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 27 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 27 |
532130968 |
SHIELD.DEFLECTOR.MOWER.42".BLK This part replaces 532171859. Price: $34.99 |
| 28 |
3296-20 |
NUT-LOCK, NI Price: $0.40 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga SD Price: $5.99 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 29 |
63-7790 |
SCREW-CAP Price: $1.46 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532173984. Price: $3.99 |
| 30 |
81-1690 |
CLAMP-CABLE Price: $2.24 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL Price: $3.99 |
| 31 |
98-9311 |
SWIVEL-THROTTLE Price: $28.41 |
| 32 |
139-9940 |
SCREW-HH This part replaces 99-5132. Price: $1.99 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532153535. Price: $14.99 |
| 33 |
117-7950 |
MANIFOLD-EXHAUST Price: $98.51 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 34 |
136-2267 |
HOSE-AIR CLEANER Price: $80.04 |
| 34 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 35 |
2412-102 |
CLAMP-R Price: $6.85 |
| 36 |
131-3319-03 |
BRACKET-MOUNT, AIR INTAKE Price: $12.85 |
| 36 |
597025001 |
CLG This part replaces 532131494. Price: $22.99 |
| 37 |
47-3460 |
U-BOLT Price: $29.53 |
| 38 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 39 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 40 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 40 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 43 |
33-5790 |
BOLT-CARR Price: $3.69 |
| 44 |
532140088 |
GUARD MANDREL LH BLACK Price: $29.99 |
| 45 |
322-13 |
SCREW-HH Price: $2.73 |
| 45 |
532004497 |
RETAINER M This part replaces 532124788. Price: $4.99 |
| 46 |
322-6 |
SCREW-HH Price: $0.45 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
130-7177 |
SHROUD-UNDERCARRIAGE Price: $591.88 |
| 48 |
532133944 |
WASHER Price: $3.99 |
| 49 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 50 |
106-5517 |
DECAL-WARNING Price: $3.49 |
| 52 |
532139888 |
BOLT.SHOULDER.5/16-18 Price: $3.99 |
| 53 |
531168401 |
SERVICE KIT ARM BRAKE ASSY This part replaces 532184907. Price: $19.99 |
| 54 |
532178515 |
WASHER Price: $5.99 |
| 55 |
531166601 |
SERVICE KIT ARM ARM IDLER 42" This part replaces 532155046. Price: $14.99 |
| 56 |
532165723 |
SPACER.RETAINER.MOWER Price: $5.99 |
| 59 |
531165901 |
SERVICE KIT GUARD This part replaces 532141043. Price: $4.99 |
| 67 |
532106932 |
KNOB T (3/8 HOLE) Price: $6.99 |
| 68 |
532144959 |
BELT V SECONDARY Price: $37.99 |
| 92 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 111 |
532181040 |
KIT.BRKT.GAUGE.WHEEL.42" This part replaces 532179292. Price: $32.99 |
| 112 |
532181040 |
KIT.BRKT.GAUGE.WHEEL.42" This part replaces 532179293. Price: $32.99 |
| 113 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $4.99 |
| 116 |
596434402 |
Bolts This part replaces 532124842. Price: $3.99 |
| 117 |
589527401 |
WHEEL.GAUGE.RALLY.NARROW This part replaces 532188606. Price: $9.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 129 |
596134901 |
GSPH This part replaces 819131312. Price: $2.99 |
| 130 |
596564401 |
Bolts This part replaces 874780616. Price: $3.99 |
| 131 |
596728201 |
Bolts This part replaces 872140608. Price: $3.99 |
| 142 |
529845801 |
SERVICE KIT ARM SPRING BRAKE M This part replaces 532165890. Price: $5.99 |
| 143 |
529844301 |
SERVICE KIT BRACKET This part replaces 532157109. Price: $7.99 |
| 144 |
532173441 |
KEEPER BELT 42" CLUTCH This part replaces 532158634. Price: $6.99 |
| 145 |
532173437 |
PULLEY.IDLER.FLAT.PLATED This part replaces 532165888. Price: $24.99 |
| 146 |
532173443 |
BOLT CARRIAGE IDLER This part replaces 532171977. Price: $4.99 |
| 147 |
532179748 |
SPRING This part replaces 532131335. Price: $4.99 |
| 148 |
532169022 |
IDLER RETURN SPRING Price: $4.99 |
| 149 |
532165898 |
SPRING.RETAINER.YELLOW.ZINC Price: $3.99 |
| 150 |
596039801 |
Washers This part replaces 819091210. Price: $2.99 |
| 158 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 159 |
596987501 |
Bolts This part replaces 872140614. Price: $3.99 |
| 184 |
596134901 |
GSPH This part replaces 819131410. Price: $2.99 |
| 185 |
532188234 |
HEAD ASM. CABLE CLUTCH Price: $34.99 |
