| Ref | Part Number | Description |
|---|
| 1 |
125-9618-03 |
HINGE-DOOR, RH Price: $37.15 |
| 1 |
532198417 |
NEEDS DESCRIPTION Price: Call Us |
| 2 |
130-5678 |
RH DOOR ASM Price: $1,318.50 |
| 2 |
585906501 |
KIT.SERVICE.198070 This part replaces 532198070. Price: $49.99 |
| 3 |
121-8570-03 |
FRAME-DOOR, RH Price: $371.09 |
| 3 |
583172901 |
PIN.GROOVE.5/16 This part replaces 532188822. Price: $4.99 |
| 4 |
121-8331 |
GASKET-HANDLE Price: $15.02 |
| 4 |
812000002 |
RETAINING RING LT Price: $3.99 |
| 5 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 5 |
819211621 |
WASHER Price: $4.99 |
| 6 |
125-9982 |
BUSHING-FLANGE Price: $1.76 |
| 6 |
532120183 |
BEARING.NYLON Price: $5.99 |
| 7 |
125-9676 |
WASHER-BACKUP Price: $1.70 |
| 7 |
532125631 |
GRIP HANDLE Price: $6.99 |
| 8 |
532125925 |
PLUNGER BUTTON KIT This part replaces 532122365. Price: $5.99 |
| 9 |
125-9520 |
SCREW-SHOULDER, HSH Price: $1.83 |
| 11 |
532165828 |
LIFT LINK, LH This part replaces 532165829. Price: $17.99 |
| 11 |
98-3104 |
STUD-BALL Price: $4.61 |
| 12 |
121-8390 |
LATCH-RH Price: $63.03 |
| 12 |
532165830 |
LINK ASSY. This part replaces 532165831. Price: $9.99 |
| 13 |
121-8630 |
HANDLE ASM Price: $121.56 |
| 13 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 14 |
33103-025 |
SCREW-HHF Price: $0.54 |
| 15 |
3234-21 |
SCREW-HHF Price: $2.19 |
| 15 |
532173288 |
LINK.SUSPENSION.FRONT Price: $11.99 |
| 16 |
104-7201 |
NUT-HF Price: $0.69 |
| 16 |
596433401 |
Nuts This part replaces 873350800. Price: $2.99 |
| 17 |
532175689 |
TRUNNION Price: $3.99 |
| 18 |
596135601 |
GSPW NUTS This part replaces 873800800. Price: $3.99 |
| 19 |
531165801 |
SERVICE KIT ARM ARM.REAR.SUSPE This part replaces 532139868. Price: $11.99 |
| 20 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 23 |
532110807 |
NUT T Price: $3.99 |
| 24 |
819131016 |
WASHER Price: $2.99 |
| 25 |
532164024 |
SPRING Price: $3.99 |
| 26 |
596029401 |
GSPW Retainers This part replaces 532169484. Price: $3.99 |
| 27 |
532164543 |
ROD ADJ LIFT Price: $6.99 |
| 28 |
873220600 |
NUT.HEX.3/8-16UNC This part replaces 873350600. Price: $4.99 |
| 29 |
532138057 |
KNOB INF 3/8-16 Price: $6.99 |
| 30 |
532150233 |
TRUNNION Price: $9.99 |
| 31 |
532169865 |
BEARING.PIVOT.LIFT Price: $5.99 |
| 32 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 36 |
532155097 |
POINTER, HEIGHT INDICATOR(2 2) Price: $4.99 |
| 38 |
593337601 |
Screws This part replaces 817060516. Price: $3.99 |
| 40 |
819112410 |
WASHER Price: $3.99 |
| 41 |
532123934 |
HEIGHT INDICATOR Price: $2.99 |
| 49 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 532145212. Price: $3.99 |
| 50 |
532110452 |
NUT PUSH M Price: $2.99 |
