| Ref | Part Number | Description |
|---|
| 1 |
76-5070 |
OIL PUMP ASM Price: $729.22 |
| 1 |
903-04032 |
LIFT HANDLE CONTROL Not Available This part replaces 603-04032. Price: |
| 2 |
903-04033 |
VALVE LINK PLATE Not Available This part replaces 603-04033. Price: |
| 2 |
94-3176 |
VALVE-RELIEF Price: $5.60 |
| 3 |
603-04035-0637 |
VALVE MOUNTING BRACKET Not Available This part replaces 603-04035. Price: |
| 3 |
76-5090 |
SPRING-PISTON Price: $4.54 |
| 4 |
703-05038 |
BRACKET, HANDLE PIVOT Not Available Price: |
| 4 |
94-3179 |
WASHER-SPRING Price: $1.50 |
| 5 |
710-0514 |
Screw, Hex Cap, 3/8-16 x 1.0 GR5 Price: $3.78 |
| 5 |
76-5100 |
BOLT-SHOULDER Price: $5.63 |
| 6 |
710-0564 |
Screw, Hex Cap, 1/4-20 x 2.75 GR5 Price: $6.07 |
| 7 |
710-1260A |
Screw, Hex Wash, Hd Tapp 5/16-18 x .75 Price: $3.34 |
| 7 |
76-5010 |
WASHER-SPRING Price: $0.33 |
| 8 |
711-04214 |
Pin, Clevis, .25 x .9375 Price: $5.44 |
| 8 |
94-3124 |
SCREW-HH Price: $1.30 |
| 9 |
711-1614 |
VALVE CONNECT LINK Not Available Price: |
| 9 |
94-3178 |
STRAINER Price: $99.33 |
| 10 |
77-3470 |
SCREW Price: $3.37 |
| 10 |
912-0298 |
Jam Nut, 1/4-20 This part replaces 712-0298. Price: $5.38 |
| 11 |
77-3490 |
SCREW Price: $4.42 |
| 11 |
912-0431 |
Nut, Hex Flange Lock, 3/8-16 This part replaces 7120431. Price: $4.29 |
| 12 |
712-0266A |
Nut, Jam Lock, 3/8-16 This part replaces 712-0266. Price: $3.43 |
| 12 |
94-3177 |
PLUG Price: $7.38 |
| 13 |
712-0324 |
Nut, Hex Nylon Insert Lock 14-20 GR8 Price: $3.38 |
| 14 |
714-0127 |
COTTER PIN-1/16 DIA x .75 Not Available Price: |
| 15 |
715-0120 |
Pin, Spirol, 3/16 x 1.0 Price: $9.14 |
| 16 |
718-3130 |
HYDRAULIC LIFT VALVE Not Available Price: |
| 17 |
731-3321 |
Grip, Handle Price: $18.83 |
| 18 |
736-0258 |
Washer, Flat, .385 x 1.0 x .135 Price: $3.93 |
| 19 |
738-0137A |
Screw, Shoulder, .34 x .285 Price: $9.83 |
| 20 |
738-0215A |
Screw, Shoulder, .498 x 2.99 Not Available Price: |
| 503712201 |
503712201 |
BEARING Price: $11.99 |
| 503909501 |
503909501 |
CUP Price: $8.62 |
| 503910701 |
503913401 |
BEARING This part replaces 503910701. Price: $22.99 |
| 503913401 |
503913401 |
BEARING Price: $22.99 |
| 738220125 |
738220125 |
Ball Bearing 6201-C3 Price: $11.99 |
