| Ref | Part Number | Description |
|---|
| 1 |
7-3900 |
PAD-BRAKE Price: $27.35 |
| 2 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7580. Price: $27.95 |
| 3 |
3218-5 |
NUT-JAM Price: $0.27 |
| 4 |
21-2850-01 |
MOUNT-PEDAL, RH This part replaces 21-2850. Price: $69.64 |
| 4 |
532427071 |
PULLEY.IMPELLER.SNOW This part replaces 532191079. Price: $27.99 |
| 5 |
32144-102 |
SCREW-HWH This part replaces 11-0590. Price: $3.19 |
| 5 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 6 |
256-156 |
BUSHING-FLANGE Price: $12.99 |
| 6 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 7 |
3272-5 |
PIN-COTTER Price: $1.39 |
| 7 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 8 |
3256-22 |
WASHER-FLAT Price: $0.39 |
| 8 |
596039401 |
BOLT ROUND HEAD SQUARE NECK BO This part replaces 872270505. Price: $2.99 |
| 9 |
596031601 |
Screws This part replaces 532163183. Price: $2.99 |
| 9 |
95-1821 |
SPRING-COMPRESSION This part replaces 3-3251. Price: $6.71 |
| 10 |
27-7660 |
DISCONTINUED Price: Call Us |
| 10 |
581708369 |
KIT.AUGER.HOUSING.404930X668 This part replaces 532407721. Price: $279.99 |
| 11 |
233-17 |
KNOB Price: $10.58 |
| 11 |
532435830 |
BAR.SCRAPER.30.BLACK This part replaces 532416270. Price: $17.99 |
| 12 |
597433002 |
Brackets This part replaces 532184095. Price: $3.99 |
| 12 |
66-6190 |
DECAL - PARKING BRAKE Price: $6.35 |
| 13 |
3-7243 |
SPRING-EXTENSION Price: $11.23 |
| 13 |
585056901 |
CHUTE.DISCHARGE.BASE This part replaces 532175322. Price: $9.99 |
| 14 |
283-58 |
PIN-CLEVIS Price: $3.87 |
| 14 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 15 |
108-1380 |
LH BRAKE CABLE ASM This part replaces 21-3380. Price: $162.33 |
| 15 |
819111507 |
WASHER, FLAT Price: $4.99 |
| 16 |
23-2270 |
BUSHING-RUBBER Price: $17.07 |
| 16 |
874940516 |
CAPSCREW.HX.HD.5/16-18X1.00.NY Price: $3.99 |
| 17 |
23-2240-03 |
PUMP CONTROL TUBE ASM This part replaces 23-2240. Price: $209.72 |
| 17 |
532405637 |
GREASE FITTING Price: $3.99 |
| 18 |
28-5190 |
DISCONTINUED Price: Call Us |
| 18 |
532179582 |
SCREW, HEX HD 5/16X1 Price: $3.99 |
| 19 |
28-5130 |
TRACTION PEDAL PAD Price: $33.21 |
| 19 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 20 |
28-5240 |
DISCONTINUED Price: Call Us |
| 20 |
596039201 |
GSPW Hardware This part replaces 532155377. Price: $2.99 |
| 21 |
3272-6 |
PIN-COTTER Price: $0.25 |
| 21 |
532401347 |
WASHER.12021.438X.75X.06.PLS Price: $2.99 |
| 22 |
28-5210 |
TRACT PEDAL SHAFT Price: $48.49 |
| 22 |
532407834 |
SKID PLATE Price: $17.99 |
| 23 |
28-5160-01 |
DISCONTINUED This part replaces 28-5160. Price: Call Us |
| 24 |
32121-16 |
PIN-SPRING Price: $0.41 |
| 24 |
532128638 |
NUT WING PM Price: $3.99 |
| 25 |
28-5220 |
FRICTION WHEEL ASM Price: $108.15 |
| 25 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 This part replaces 872270506. Price: $3.99 |
| 26 |
532188170 |
BEARING RETAINER, PLASTIC Price: $7.99 |
| 26 |
99-5686 |
RH SOCKET ASM This part replaces 21-0140. Price: $99.81 |
| 27 |
3220-5 |
NUT-JAM Price: $0.65 |
| 27 |
532007396 |
WASHER RACE BEARING THRUST This part replaces 532174697. Price: $3.99 |
| 28 |
3217-7 |
NUT-HEX Price: $0.28 |
| 28 |
588077502 |
BOLT SHEAR HX HD 1/4-20 CLEAR This part replaces 532198636. Price: $1.00 |
| 29 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 29 |
532407834 |
SKID PLATE Price: $17.99 |
| 30 |
532435545 |
AUGER.WELDMENT.RH.30.BB This part replaces 532407722. Price: $139.99 |
| 30 |
603773 |
LOCKNUT This part replaces 32153-2. Price: $2.09 |
| 31 |
3231-21 |
SCREW-CARR Price: $0.76 |
| 31 |
532435544 |
KIT.AUGER.30.LH.BB This part replaces 532407723. Price: $139.99 |
| 32 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 32 |
532407768 |
O-RING Price: $3.99 |
| 33 |
3274-47 |
SCREW-HSFH Price: $0.53 |
| 33 |
532407769 |
BUSHING, FLANGE 3/4 Price: $7.99 |
| 34 |
27-7590-01 |
BRAKE MT WA This part replaces 27-7590. Price: $239.14 |
| 34 |
532174681 |
WASHER, THRUST 3/4 Price: $11.99 |
| 35 |
27-9270-01 |
PIVOT SHAFT MOUNT ASM This part replaces 27-9270. Price: $81.41 |
| 35 |
532174684 |
BEARING TRUST 3/4 NTA-1220 Price: $6.99 |
| 36 |
27-7640-01 |
SHAFT-BRAKE LATCH ASM This part replaces 27-7640. Price: $62.42 |
| 36 |
532407757 |
SHAFT, IMPELLER Price: $89.99 |
| 37 |
32149-2 |
NUT-KEPS Price: $2.39 |
| 37 |
532174683 |
WASHER, THRUST 5/8 Price: $6.99 |
| 38 |
532174686 |
BUSHING.FLANGE.(.625X.75) This part replaces 532407758. Price: $22.99 |
| 38 |
93-8743 |
FOOTPAD-TURN This part replaces 27-7570. Price: $27.95 |
| 39 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 39 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $4.99 |
| 40 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 40 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW This part replaces 532407760. Price: $3.99 |
| 41 |
27-7490 |
LH BRAKE PEDAL ASM Price: $347.33 |
| 41 |
532174688 |
HOUSING.GEARBOX.RH.SNOW This part replaces 532407761. Price: $22.99 |
| 42 |
27-7510 |
RH BRAKE PEDAL ASM Price: $321.91 |
| 42 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $4.99 |
| 43 |
256-10 |
BUSHING-FLANGE Price: $3.68 |
| 43 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $29.99 |
| 44 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 44 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 45 |
598831601 |
Service Kit This part replaces 532407763. Price: $199.99 |
| 46 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $59.99 |
| 47 |
532407765 |
HOUSING.GEARBOX.LH(SERVICE) Price: $22.99 |
| 48 |
531167901 |
SERVICE KIT IMPELLER WELDMENT This part replaces 532184105. Price: $44.99 |
| 49 |
596322101 |
BOLT HEXAGON BOLT 1/4-20 X 1-5 This part replaces 874780426. Price: $2.99 |
| 50 |
532175311 |
GASKET.AUGER.GEARBOX This part replaces 532407766. Price: $7.99 |
| 51 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532184205. Price: $3.99 |
| 52 |
532435832 |
BAR.DRIFT.CUTTER.BLACK This part replaces 532184747. Price: $19.99 |
| 53 |
872110506 |
BOLT.CARR.SQNK.5/16-18UNC.X3/4 This part replaces 872270506. Price: $3.99 |
| 54 |
532198709 |
STOP.11261.PLASTIC.30X50L.RED Price: $5.99 |
| 55 |
532198638 |
SPACER.3943.SLEEVE.250X.47 Price: $5.99 |
| 56 |
532429112 |
WRENCH.SNOWTHROWER.ZINC.YZ This part replaces 532180684. Price: $3.99 |
| 57 |
598831601 |
Service Kit This part replaces 532196710. Price: $199.99 |
