| Ref | Part Number | Description |
|---|
| 1 |
703-2144 |
BULKHEAD, UPPER Not Available Price: |
| 1 |
94-3131 |
SCREW-HH Price: $1.06 |
| 2 |
532422027 |
SHAFT.ASM.CROSS.LIFT Price: $69.99 |
| 2 |
703-2142 |
BULKHEAD BRACKET Not Available Price: |
| 2 |
94-3208 |
STUB-OUTLET Price: $184.75 |
| 3 |
710-3039 |
SCREW 5/16-18 x .50 GR5 Not Available Price: |
| 3 |
94-3205 |
DISCONTINUED Price: Call Us |
| 4 |
736-0242 |
Washer, Bell, .345 x .88 x .060 Thk Price: $3.75 |
| 4 |
94-3207 |
RING Price: $10.14 |
| 5 |
94-3214 |
CAPSCREW Price: $4.42 |
| 6 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .50 Lg GR5 Price: $4.02 |
| 6 |
94-3211 |
TEMP SENDING UNIT BLUE Price: $82.56 |
| 7 |
532411555 |
GRIP.HANDLE.LIFT.PVC.BLACK This part replaces 580962301. Price: $7.99 |
| 7 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 7 |
94-3212 |
PLUG Price: $10.14 |
| 8 |
712-3006 |
HEX NUT Price: $4.05 |
| 8 |
94-3213 |
CAPSCREW Price: $30.93 |
| 9 |
703-2143 |
BULKHEAD-LOWER Not Available Price: |
| 9 |
76-5410 |
COLLECTOR GASKET This part replaces 94-3206. Price: $7.82 |
| 10 |
532196314 |
SPRING.TORSION.LIFT.HANDLE Price: $3.99 |
| 10 |
94-3210 |
GASKET Price: $11.64 |
| 11 |
723-3042 |
SNAP BUSHING 7/8 Not Available Price: |
| 12 |
703-1827 |
TRAY ASSEMBLY- Not Available Price: |
| 13 |
710-3012 |
BOLT-J TYPE 1/4-20 Not Available Price: |
| 14 |
710-0751 |
SCREW 1/4-20 x .620 GR5 Price: $3.63 |
| 15 |
723-3062 |
SEALING RING Not Available Price: |
| 16 |
736-0270 |
SPRING WASHER BELL Price: $3.63 |
| 17 |
712-3051 |
HEX NUT TOP LOCK Not Available Price: |
| 87 |
532194209 |
PIN.COTTER.7/16.BOW TI. Price: $2.99 |
| 89 |
819191912 |
WASHER.CLEAR.ZINC Price: $2.99 |
| 90 |
532194208 |
PIN.COTTER.5/16.BOW TI Price: $2.99 |
| 97 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 98 |
581506903 |
Links This part replaces 532195270. Price: $9.99 |
| 100 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 101 |
532407003 |
LINK.ASM.LIFT.FIXE.38/42/46" Price: $11.99 |
