| Ref | Part Number | Description |
|---|
| 1 |
07001731 |
HOSE, OIL DRAIN Price: $22.45 |
| 2 |
08201424 |
ENGINE, KAWASAKI - FX 850 EFI W/VOLT REG Price: Call Us |
| 3 |
09374300 |
WLDMT, TRANSAXLE DRIVE PULLEY Price: $67.45 |
| 4 |
09386000 |
MUFFLER, KAWASAKI FX850 Price: $164.95 |
| 5 |
05501240 |
SPACER, .474/.459X2.00X.350 Price: $13.45 |
| 6 |
05501427 |
SPCR, 1.125 x 1.750 x 1.147 Price: $6.45 |
| 7 |
09653700 |
CLUTCH- OGURA GT2.75-DC03(D) Price: $329.95 |
| 8 |
05901804 |
BLT, HEX .31-18X1.75 G5 ZCC Price: $2.95 |
| 9 |
05901808 |
BLT, HEX .38-16X1.25 G5 ZCC NT Price: $1.95 |
| 10 |
05901819 |
BLT, HEX 0.4375-20X3 G8 ZCC NT Price: $5.45 |
| 11 |
30290651 |
BRKT, CLUTCH STOP (BLACK) This part replaces 09674051. Price: $16.95 |
| 12 |
06400927 |
WASHER, 3/8" SPRING DISC Price: $3.45 |
| 13 |
06400936 |
WASHER, 7/16" SPRING DISK Price: $10.45 |
| 14 |
06401023 |
WSHR-FLT .375X.875X.083 ZCC Price: $1.45 |
| 15 |
06500840 |
NUT,LK-CTR-FLG .31-18 GF ZCC Price: $0.95 |
| 16 |
06604300 |
KEY-SQ .25 X 1.50 X .25 SAE Price: $3.95 |
| 17 |
06916000 |
J-CLAMP Price: $2.45 |
| 18 |
07400129 |
SCR,TAP .375-16X.75 HWH TR ZCC Price: $1.45 |
| 19 |
07500007 |
BUMPER,RUBBER .62X1.0X.88 LG Price: $5.45 |
| 20 |
07517300 |
CABLE TIE LG 5-1/2 Price: $2.95 |
| 21 |
08833400 |
BUSH.,S.391X.622X.950 ST Price: $5.45 |
