| Ref | Part Number | Description |
|---|
| 1 |
04001-190 |
Bolt, Hex Head 1/2-13 x 2-3/4" (48V & 52V - One Weight) Price: Call Us |
| 1 |
3-7390 |
DISCONTINUED Price: Call Us |
| 2 |
04003-12 |
Bolt, 5/16-18 x .75 RHSN Carriage Price: Call Us |
| 2 |
256-121 |
WASHER-THRUST Price: $4.55 |
| 3 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 3 |
5-3993 |
DISCONTINUED Price: Call Us |
| 4 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 4 |
5-3063 |
DISCONTINUED Price: Call Us |
| 5 |
04001-45 |
Capscrew, Hex Head 3/8-16 x 2.0" Price: Call Us |
| 5 |
3296-50 |
NUT-LOCK, NI Price: $2.68 |
| 6 |
486365 |
Switch, Plunger, Double Pole, Snap Price: Call Us |
| 6 |
5-3990 |
DISCONTINUED Price: Call Us |
| 7 |
3296-6 |
NUT-LOCK Price: $1.49 |
| 7 |
429195 |
Bracket, Height Switch Price: Call Us |
| 8 |
04003-21 |
Carriage Bolt, 3/8-16 x 2-1/2" Price: Call Us |
| 8 |
3-7254-01 |
DRAW BAR BRACKET This part replaces 3-7254. Price: $227.92 |
| 9 |
3211-5 |
SCREW-HH Price: $0.88 |
| 9 |
431183 |
Spacer, Wheel Mount Price: Call Us |
| 10 |
04001-30 |
Bolt, Hex Head 3/8-16 x 4.00 Price: Call Us |
| 10 |
302-5 |
FITTING-GREASE Price: $0.59 |
| 11 |
283-10 |
PIN-CLEVIS Price: $7.43 |
| 11 |
487321 |
Chain, Tine Drive Price: Call Us |
| 12 |
32121-15 |
PIN-ROLL Price: $1.60 |
| 12 |
487320 |
Chain, Wheel Drive Price: Call Us |
| 13 |
453356 |
Sprocket, Motor Price: Call Us |
| 13 |
5-1111 |
CASTOR WHEEL BUSHING Price: $10.11 |
| 14 |
3-7410 |
DISCONTINUED Price: Call Us |
| 14 |
487439 |
Bolt, Ilder Sprocket Price: Call Us |
| 15 |
487270 |
Sprocket, Idler 15T Price: Call Us |
| 15 |
5-3982 |
DISCONTINUED Price: Call Us |
| 16 |
04063-44 |
Key, 5/16 x 5/16 x 1.437 Price: Call Us |
| 16 |
3213-8 |
SCREW-HH Price: $2.58 |
| 17 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 17 |
5-1091 |
SPACER Price: $4.98 |
| 18 |
3219-4 |
NUT-HEX Price: $2.65 |
| 18 |
431182 |
Bushing, Idler Sprocket Price: Call Us |
| 19 |
04019-06 |
Nut, Hex Serrated Flange 1/2-13 Price: Call Us |
| 19 |
5-1090 |
DRAWBAR CLAMP -PLT Price: $41.53 |
| 20 |
04024-03 |
Nut, Push-On 5/16-18 Price: Call Us |
| 20 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 21 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 21 |
428949 |
Bracket RH, Wheel Mount Price: Call Us |
| 22 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 22 |
3219-5 |
NUT-HEX Price: $1.22 |
| 23 |
04063-07 |
KEY, WOODRUFF #9, 3/16 X 3/4" Price: Call Us |
| 23 |
3212-10 |
SCREW-HH Price: $2.92 |
| 24 |
5-1112 |
DRAWBAR PIN Price: $9.77 |
| 25 |
453346 |
Shaft, Wheel Price: Call Us |
| 25 |
5-3987 |
DISCONTINUED Price: Call Us |
| 26 |
3256-30 |
WASHER-FLAT Price: $5.73 |
| 26 |
487330 |
Bearing, Ball 30mm Bore x 62mm OD Price: Call Us |
| 27 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 27 |
453345 |
Hub, Wheel Price: Call Us |
| 28 |
431180 |
Spacer, Wheel Bearing Price: Call Us |
| 28 |
8-0280 |
DISCONTINUED Price: Call Us |
| 29 |
3272-9 |
PIN-COTTER Price: $0.20 |
| 29 |
481035 |
Nut , Spec ial 1 -1/ 1 6 - 1 8 Price: Call Us |
| 30 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 31 |
04008-01 |
Bolt, Serr. Flange 1/2-20 x 4.563" Price: Call Us |
| 32 |
422214 |
Lock Washer, Wheel Motor Price: Call Us |
| 33 |
04027-01 |
Hex Castle Nut, 3/4-28 UNEF Price: Call Us |
| 34 |
487462 |
Wheel Assy., 18 x 6.5 - 8 Price: Call Us |
| 35 |
04028-02 |
Wheel Nut, 1/2-20 x 13/16 Price: Call Us |
| 36 |
04001-20 |
Bolt, Hex Head 3/8-16 x 1-1/2" B&S 32BV Price: Call Us |
| 37 |
04050-01 |
RETAINING RING, 5/8" EXTERNAL "E" Price: Call Us |
| 38 |
04017-16 |
Capscrew, 5/16-18 x .75 Serrated Flange Hex Head Price: Call Us |
| 39 |
429025 |
Stop Plate, Pivot Bearing Price: Call Us |
| 40 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 41 |
43086 |
BUSHING, SPEED ADJUSTMENT LEVER Price: Call Us |
| 42 |
453381 |
Pivot Bearing Wlmt RH Price: Call Us |
| 43 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 44 |
487280 |
Pivot Bearing Price: Call Us |
| 45 |
453353 |
Pivot Bearing Wlmt Price: Call Us |
| 46 |
04014-07 |
Capscrew, 3/8-16 x 1-1/4" Price: Call Us |
| 47 |
04019-05 |
HEX NUT, 7/16-14 SERRATED FLANGE Price: Call Us |
| 48 |
487259 |
Bearing, 1" Flange Price: Call Us |
| 49 |
04001-117 |
BOLT, HEX HEAD, 7/16-14 X 1-3/4 Price: Call Us |
| 50 |
453337 |
Pivot Arm Wlmt Price: Call Us |
| 51 |
04042-05 |
Flatwasher, 1" (1.062 x 1.75 x .10) Price: Call Us |
| 52 |
48100-08 |
Bushing, 1.003 ID This part replaces 48100-17. Price: Call Us |
| 53 |
453335 |
Tine Wlmt, Idler Price: Call Us |
| 54 |
485553 |
Clamp Collar, 1.25 Bore 2 Piece Price: Call Us |
| 55 |
04001-178 |
Bolt, Hex Head 7/16-20 x 1" Price: Call Us |
| 56 |
453338 |
Tine Wlmt, RH Drive Price: Call Us |
| 57 |
463506 |
Tine Height Assembly Price: Call Us |
| 484683 |
RIM |
WLMT, PAINTED - 18 X 4.56 Price: Call Us 484683 |
