| Ref | Part Number | Description |
|---|
| 1 |
531167901 |
SERVICE KIT IMPELLER WELDMENT This part replaces 532184105. Price: $44.99 |
| 1 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 2 |
104-9325 |
SPEEDOMETER KIT,RM5000 SERIES This part replaces 85-4420. Price: $449.92 |
| 2 |
598831601 |
Service Kit This part replaces 532427148. Price: $199.99 |
| 3 |
3290-489 |
KNOB Price: $46.30 |
| 3 |
532188909 |
BEARING FLANGE Price: $24.99 |
| 4 |
218-498 |
NUT-LOCK Price: $0.68 |
| 4 |
532427146 |
PULLEY.FLANGE.IMPELLER Price: $29.99 |
| 5 |
585056901 |
CHUTE.DISCHARGE.BASE This part replaces 532442438. Price: $9.99 |
| 5 |
74-5950 |
LATCH-SWELL This part replaces 249-48. Price: $21.28 |
| 6 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 6 |
597433002 |
Brackets This part replaces 532184095. Price: $3.99 |
| 7 |
532192199 |
CLEAN OUT TOOL Price: $14.99 |
| 7 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 8 |
532405400 |
CLIP.CLEANOUT.TOOL Price: $2.99 |
| 8 |
98-9308 |
GAUGE-TEMPERATURE This part replaces 63-7430. Price: $112.90 |
| 9 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 873800400. Price: $1.99 |
| 9 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 10 |
218-446 |
NUT-HEX Price: $6.09 |
| 10 |
596322101 |
BOLT HEXAGON BOLT 1/4-20 X 1-5 This part replaces 874780426. Price: $2.99 |
| 11 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 11 |
594944401 |
NUT HEXAGON FLANGE 5/16-18 ST This part replaces 532427942. Price: $5.99 |
| 12 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 12 |
596031601 |
Screws This part replaces 532163183. Price: $2.99 |
| 13 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 13 |
532427145 |
HUB.IMP.PULLEY.D-SHAFT Price: $4.99 |
| 14 |
532427154 |
SLEEVE.IMP.PULLEY.D-SHAFT Price: $3.99 |
| 14 |
75-0591 |
DISCONTINUED Price: Call Us |
| 15 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 15 |
75-6270-03 |
COVER-BOX, CONTROL This part replaces 75-6270. Price: $87.82 |
| 16 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 16 |
75-1010 |
SWITCH-REEL Price: $84.90 |
| 17 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 17 |
532194189 |
SCREW.HWH.13-16-5.8.BZP Price: $4.99 |
| 18 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 18 |
532086447 |
PLUG.AUGER.GEAR.BOX.SNOW This part replaces 532407760. Price: $3.99 |
| 19 |
27-2360 |
SWITCH Price: $46.56 |
| 20 |
532427345 |
GASKET.GEAR.BOX Price: $4.99 |
| 21 |
532174698 |
SEAL, OIL This part replaces 532407770. Price: $4.99 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 22 |
532174701 |
BUSHING FLANGE 1" This part replaces 532407762. Price: $29.99 |
| 23 |
532007396 |
WASHER RACE BEARING THRUST This part replaces 532174697. Price: $3.99 |
| 23 |
85-4450 |
BRKT-FUSE BLOCK Price: $29.51 |
| 24 |
598831601 |
Service Kit This part replaces 532407763. Price: $199.99 |
| 24 |
75-5740-03 |
BOX-CONTROL ASM This part replaces 75-5740. Price: $261.87 |
| 25 |
532174657 |
SHAFT, AUGER This part replaces 532407764. Price: $59.99 |
| 25 |
85-4480 |
KNOB Price: $16.02 |
| 26 |
321-39 |
SCREW-HH Price: $0.42 |
| 26 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 27 |
532174686 |
BUSHING.FLANGE.(.625X.75) This part replaces 532407758. Price: $22.99 |
| 28 |
532174683 |
WASHER, THRUST 5/8 Price: $6.99 |
| 28 |
75-4710 |
HARNESS- WARNING LIGHTS Price: $55.53 |
| 29 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 29 |
532427147 |
SHAFT.IMPELLER.D-SHAFT Price: $74.99 |
| 30 |
218-535 |
NUT-HEX Price: $0.34 |
| 30 |
532001572 |
PIN.ROLL.3/16 X 1" This part replaces 532184205. Price: $3.99 |
| 31 |
139-5984 |
CONTROLLER-ELECTRONIC This part replaces 92-5720. Price: $2,183.63 |
| 31 |
532174681 |
WASHER, THRUST 3/4 Price: $11.99 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 32 |
532174684 |
BEARING TRUST 3/4 NTA-1220 Price: $6.99 |
| 33 |
321-15 |
SCREW-HH Price: $0.61 |
| 33 |
532407769 |
BUSHING, FLANGE 3/4 Price: $7.99 |
| 34 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 34 |
532407768 |
O-RING Price: $3.99 |
| 35 |
322-3 |
SCREW-HH Price: $0.79 |
| 35 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532407767. Price: $4.99 |
| 36 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 37 |
98-2195 |
JOYSTICK This part replaces 75-3420. Price: $520.10 |
| 38 |
111332 |
SWITCH This part replaces 218-590. Price: $10.99 |
| 39 |
3290-93 |
SCREW-HEAD, PAN Price: $0.25 |
| 40 |
3290-488 |
DISCONTINUED Price: Call Us |
| 41 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 42 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 43 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 44 |
104-4235 |
POTENTIOMETER ASM This part replaces 85-4470. Price: $260.80 |
| 45 |
3273-26 |
SCREW-HSH Price: $0.41 |
| 46 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 47 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 50 |
85-4460 |
HOC SELECTOR DECAL Price: $7.84 |
| 53 |
2412-126 |
R-CLAMP This part replaces 2142-126. Price: $2.51 |
| 54 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 55 |
32128-33 |
NUT-HF Price: $0.25 |
| 56 |
92-8752 |
WIRE HARNESS ASSY Price: $1,303.23 |
| 57 |
85-4491 |
LIGHT-INDICATOR (INCLUDES LAMP) Price: $173.84 |
| 58 |
92-8935 |
WIRE ASSY Price: $19.58 |
| 59 |
218-600 |
LIGHT BULB Price: $10.18 |
| 60 |
92-8936 |
DISCONTINUED Price: Call Us |
