| Ref | Part Number | Description |
|---|
| 1 |
106-3239 |
SCREW-LOCK Price: $48.99 |
| 2 |
107-1644 |
CAP-LOCK Price: $36.99 |
| 2 |
532149723 |
MUFFLER.TWIN.CYL.LOW.TONE Price: $49.99 |
| 3 |
107-1664 |
LEVER ASM This part replaces 106-3241. Price: $71.99 |
| 9 |
584908001 |
KEEPER BELT ENGINE This part replaces 532194320. Price: $2.99 |
| 11 |
532414737 |
KIT.SVC.CLTCH.OG.1.125" This part replaces 532179335. Price: $229.99 |
| 12 |
532194343 |
PULLEY ENGINE Price: $44.99 |
| 15 |
532438081 |
TANK.ASM.4.GAL.EPA.ONE.PORT Price: $219.99 |
| 18 |
532430214 |
CAP ASM.FL.RTCHT.3"GRY.E10 Price: $24.99 |
| 20 |
532175437 |
CONTROL.THROTTLE.BLACK This part replaces 532178385. Price: $27.99 |
| 21 |
532416358 |
SCREW.#10 X 0.750.BOS (2 2) Price: $2.99 |
| 22 |
532191596 |
CONTROL CHOKE Price: $24.99 |
| 28 |
532401135 |
LINE.FUEL.64"REAR.EMIS Price: $19.99 |
| 29 |
532137180 |
KIT.SPARK ARRESTOR(392390 B&S) Price: $129.99 |
| 37 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 41 |
532126197 |
WASHER Price: $4.99 |
| 42 |
539990247 |
WASHER 7/16 LOCK This part replaces 810040700. Price: $1.99 |
| 45 |
873680400 |
NUT.CROWNLOCK.1/4 This part replaces 873510400. Price: $2.99 |
| 62 |
532434017 |
SHIELD.HEAT.MUFFLER Price: $11.99 |
| 69 |
532165391 |
GASKET.MUFFLER Price: $9.99 |
| 79 |
532183906 |
SCREW.SOCKET.HEAD.5/16-18 Price: $3.99 |
| 81 |
532148456 |
TUBE, DRAIN OIL ASM. Price: $2.99 |
| 82 |
532428287 |
VALUE.OIL.DRAIN Price: $11.99 |
| 84 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 85 |
532179953 |
BOLT HEX 7/16-20 X 3.75 GR. 5 Price: $3.99 |
| 87 |
532198239 |
BOLT.5/16-18UNCX1.W/SEMS.BLK Price: $3.99 |
| 90 |
817000616 |
SCREW 3/8-16X1 Price: $3.99 |
