| Ref | Part Number | Description |
|---|
| 1 |
231-95 |
TIRE(23X10.5X12) 4-PLY WIDE WHEEL OPT. Price: $142.43 |
| 1 |
530015899 |
Screw Price: $1.99 |
| 2 |
217-116 |
WHEEL This part replaces 242-62. Price: $258.19 |
| 2 |
530095646 |
Assy-Fuel Pickup This part replaces 530014362. Price: $2.99 |
| 3 |
534790500 |
Nut Price: $1.99 |
| 4 |
530069247 |
Fuel Line Price: $3.99 |
| 5 |
545057701 |
Filter-Air This part replaces 530036141. Price: $2.99 |
| 6 |
530015970 |
Screw Price: $1.99 |
| 7 |
530059738 |
Filter-Air This part replaces 530037478. Price: $7.99 |
| 8 |
530071987 |
CARBURETOR W-29 This part replaces 530035330. Price: $29.99 |
| 9 |
530019172 |
Carb. Gasket Price: $1.99 |
| 10 |
530037464 |
Carb. Grommet This part replaces 530037530. Price: $1.99 |
| 11 |
530015814 |
Screw-Line Limiter This part replaces 530015905. Price: $1.99 |
| 12 |
530037465 |
Carb. Adaptor Price: $4.99 |
| 13 |
530029814 |
Intake Sleeve Price: $7.99 |
| 14 |
530019177 |
Turbo Clean Seal Price: $2.99 |
| 15 |
530029813 |
Turbo Air Cleaner Ass'y. Price: $1.99 |
| 16 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.99 |
| 17 |
530016154 |
Screw Price: $0.99 |
| 18 |
530069577 |
Cylinder Shield Kit Price: $2.60 |
| 19 |
530015406 |
Screw Price: $1.99 |
| 20 |
530047382 |
Handguard Price: $7.99 |
| 21 |
530053435 |
IMPULSE PIPE This part replaces 530019171. Price: $1.99 |
| 22 |
530015895 |
Screw Price: $1.99 |
| 23 |
530037467 |
Switch Wire Ass'y. This part replaces 530036129. Price: $19.99 |
| 24 |
545199901 |
IGNITION MODULE This part replaces 530039143. Price: $22.99 |
| 25 |
530016170 |
Muffler Bolt This part replaces 530015938. Price: $1.99 |
| 26 |
530037249 |
Muffler Cover This part replaces 530036099. Price: $3.99 |
| 27 |
530037813 |
Spark Screen Price: $1.99 |
| 28 |
530036102 |
Diffuser Price: $1.99 |
| 29 |
530015902 |
Bolt Price: $1.99 |
| 30 |
530037248 |
Muffler Body Price: $6.99 |
| 31 |
530029982 |
Piston Ring Price: $3.99 |
| 32 |
530015697 |
Piston Pin Retainer Price: $1.99 |
| 34 |
503920801 |
ASSY-CRANKSHAFT & ROD This part replaces 530029794. Price: $129.99 |
| 35 |
530032117 |
Piston Pin Bearing Price: $4.99 |
| 36 |
530015897 |
Screw Price: $1.99 |
| 37 |
530019170 |
C'shaft Seal Price: $1.99 |
| 38 |
530032118 |
C'shaft Bearing Price: Call Us |
| 41 |
530037652 |
Heat Insulator Price: $1.99 |
| 42 |
530037640 |
Muffler Plate Price: $1.99 |
| 43 |
530019205 |
Muffler Gasket Price: $1.99 |
