| Ref | Part Number | Description |
|---|
| 1 |
532414557 |
SPRING.TRACTION.IDLER This part replaces 532181044. Price: $4.99 |
| 1 |
66-2940 |
GAUGE-FUEL Price: $178.34 |
| 2 |
104-9325 |
SPEEDOMETER KIT,RM5000 SERIES This part replaces 85-4420. Price: $449.92 |
| 2 |
532180522 |
PULLEY.W/SPACER.2.25 Price: $22.99 |
| 3 |
3290-489 |
KNOB Price: $46.30 |
| 4 |
218-498 |
NUT-LOCK Price: $0.68 |
| 4 |
595305701 |
Screws This part replaces 874780520. Price: $3.99 |
| 5 |
74-5950 |
LATCH-SWELL This part replaces 249-48. Price: $21.28 |
| 6 |
44-2210 |
LIGHT-INDICATOR, RED Price: $57.97 |
| 6 |
532059289 |
STEEL WASHER Price: $3.99 |
| 7 |
66-2960 |
WARNING LAMP CLUSTER Price: $210.90 |
| 7 |
873930500 |
NUT.CENTERLOCK.5/16- Price: $3.99 |
| 8 |
532175330 |
PIN, IDLER PIVOT Price: $4.99 |
| 8 |
98-9308 |
GAUGE-TEMPERATURE This part replaces 63-7430. Price: $112.90 |
| 9 |
532416954 |
V-BELT.TRACTION This part replaces 532179092. Price: $27.99 |
| 9 |
63-8360 |
KEY-IGNITION Price: $5.29 |
| 10 |
218-446 |
NUT-HEX Price: $6.09 |
| 10 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 11 |
218-447 |
WASHER-LOCK Price: $3.79 |
| 11 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 532150078. Price: $4.99 |
| 12 |
3258-166 |
SCREW-PRH Price: $0.28 |
| 13 |
3256-1 |
WASHER-FLAT Price: $0.39 |
| 13 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 14 |
532178828 |
SPRING, BRAKE Price: $4.99 |
| 14 |
75-0591 |
DISCONTINUED Price: Call Us |
| 15 |
532408010 |
BELT.V.IMPELLER.DRIVE This part replaces 532183533. Price: $34.99 |
| 15 |
75-6270-03 |
COVER-BOX, CONTROL This part replaces 75-6270. Price: $87.82 |
| 16 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $4.99 |
| 16 |
75-1010 |
SWITCH-REEL Price: $84.90 |
| 17 |
32105-13 |
SCREW-HWH Price: $1.59 |
| 17 |
585238401 |
ARM.ASM.TRACTION.IDLER. This part replaces 532184804. Price: $27.99 |
| 18 |
3296-2 |
NUT-LOCK, NI Price: $1.89 |
| 18 |
596582201 |
Bolts This part replaces 874780524. Price: $2.99 |
| 19 |
27-2360 |
SWITCH Price: $46.56 |
| 19 |
587343701 |
BUSHING.BRAKE.ARM This part replaces 532175331. Price: $5.99 |
| 20 |
594095301 |
Pulleys This part replaces 532180523. Price: $9.99 |
| 21 |
874610516 |
SCREW Price: $3.99 |
| 22 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 22 |
532179371 |
SPACER, ENGINE PULLEY Price: $7.99 |
| 23 |
595926601 |
PULLEY This part replaces 532180478. Price: $27.99 |
| 23 |
85-4450 |
BRKT-FUSE BLOCK Price: $29.51 |
| 24 |
532426491 |
PULLEY.IMPELER. This part replaces 532179157. Price: $14.99 |
| 24 |
75-5740-03 |
BOX-CONTROL ASM This part replaces 75-5740. Price: $261.87 |
| 25 |
532062735 |
WASHER Price: $3.99 |
| 25 |
85-4480 |
KNOB Price: $16.02 |
| 26 |
321-39 |
SCREW-HH Price: $0.42 |
| 26 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 27 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.50 |
| 28 |
532155452 |
BELT.GUIDE.RH Price: $4.99 |
| 28 |
75-4710 |
HARNESS- WARNING LIGHTS Price: $55.53 |
| 29 |
218-536 |
WASHER-LOCK Price: $1.09 |
| 29 |
532443030 |
COVER.ASM.BELT.EURO.TRIMMED This part replaces 532180465. Price: $27.99 |
| 30 |
218-535 |
NUT-HEX Price: $0.34 |
| 30 |
532178830 |
COVER.STORAGE.SNOW Price: $2.99 |
| 31 |
596437001 |
Screws This part replaces 817490408. Price: $2.99 |
| 32 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 32 |
532179256 |
BOLT, SHOULDER 5/16-18 Price: $2.99 |
| 33 |
321-4 |
SCREW-HH Price: $0.99 |
| 33 |
532187853 |
BELLCRANK SHIFTER This part replaces 532179250. Price: $12.99 |
| 34 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 34 |
532180401 |
SCREW Price: $2.99 |
| 35 |
322-3 |
SCREW-HH Price: $0.79 |
| 35 |
532179240 |
ARM, AUGER CONTROL Price: $3.99 |
| 36 |
3290-354 |
NUT-SPEED Price: $9.99 |
| 36 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 37 |
532184086 |
BRACKET, PIVOT Price: $3.99 |
| 37 |
98-2195 |
JOYSTICK This part replaces 75-3420. Price: $520.10 |
| 38 |
111332 |
SWITCH This part replaces 218-590. Price: $10.99 |
| 38 |
532187101 |
LINK, SPEED CONTROL This part replaces 532179251. Price: $64.99 |
| 39 |
3290-93 |
SCREW-HEAD, PAN Price: $0.25 |
| 39 |
532179064 |
TRUNION, PIVOT BRACKET Price: $4.40 |
| 40 |
3290-488 |
DISCONTINUED Price: Call Us |
| 40 |
532178820 |
NUT, CAGE 3/8-16 This part replaces 532178890. Price: $5.99 |
| 41 |
32144-1 |
SCREW-TAPTITE Price: $3.19 |
| 41 |
876020208 |
COTTER PIN Price: $8.99 |
| 42 |
532179065 |
PIN, PIVOT BRACKET Price: $8.99 |
| 42 |
69-4780 |
CLAMP-GAUGE Price: $73.28 |
| 43 |
32105-1 |
SCREW-SHH Price: $3.19 |
| 43 |
532184085 |
BRACKET Price: $2.69 |
| 44 |
874930624 |
Bolt, Hex Head 3/8-16 UNC x 1-1/2 This part replaces 874780624. Price: $6.99 |
| 45 |
3273-26 |
SCREW-HSH Price: $0.41 |
| 46 |
32144-18 |
SCREW-HWH Price: $1.80 |
| 46 |
532178624 |
PAN, FRAME BOTTOM This part replaces 532184084. Price: $17.99 |
| 47 |
120-2244 |
HOURMETER This part replaces 75-6820. Price: $48.06 |
| 47 |
871020512 |
Screw, Hex Head 5/16-18 x 3/4 Price: $2.99 |
| 48 |
532181156 |
NUT.SPEED.5/16-18 Price: $3.99 |
| 49 |
532404431 |
FRAME.WELDMENT.SNOW.ORANGE This part replaces 532184073. Price: $64.99 |
| 50 |
532184083 |
PLATE, FRAME END Price: $10.99 |
| 50 |
85-460 |
Decal-HOC Selector Price: Call Us |
| 51 |
532419877 |
KIT.CONTROL.SHAFT. This part replaces 532184082. Price: $76.99 |
| 52 |
532057079 |
THRUST WASHER Price: $1.99 |
| 53 |
532179062 |
ROLLER.ACTUATOR Price: $6.99 |
| 54 |
812000010 |
RETAINING RING Price: $2.99 |
