| Ref | Part Number | Description |
|---|
| A |
530027389 |
Fuel Tank Decal Price: $3.33 |
| B |
530026999 |
XR-105 & XR-125 (Not a serviceable part) Price: Call Us |
| C |
530027390 |
XR-105 Price: $3.33 |
| C |
530027694 |
XR-125 Right Price: $3.33 |
| 1 |
112-7680-01 |
LH FORK ASM This part replaces 20-9140. Price: $614.00 |
| 1 |
530002582 |
Switch- Plate and Nut This part replaces 530023575. Price: $6.69 |
| 2 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 2 |
530026616 |
Housing Switch Price: $3.33 |
| 3 |
20-9550 |
SPRING-COMPRESSION Price: $7.70 |
| 3 |
530024569 |
Grounding Switch Washer Price: Call Us |
| 4 |
20-9430-01 |
WEIGHT This part replaces 20-9430. Price: $912.11 |
| 4 |
530039122 |
Lead Wire Grouding Switch Price: $2.99 |
| 5 |
530069182 |
Grounding Switch Kit (Inc. 1,3,4,33) Price: $5.48 |
| 5 |
67-1300 |
DECAL This part replaces 18-6900. Price: $29.99 |
| 6 |
119-4162 |
SCREW-CARR This part replaces 323-13. Price: $1.73 |
| 6 |
530027569 |
Handle-Starter This part replaces 530026735. Price: $1.99 |
| 7 |
323-10 |
SCREW-HH Price: $0.89 |
| 7 |
530024371 |
Air Filter Price: $2.99 |
| 8 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 8 |
530015583 |
Screw Price: $1.99 |
| 9 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 10 |
20-9040 |
DISCONTINUED Price: Call Us |
| 10 |
530069236 |
Fan Housing Kit Price: $3.33 |
| 11 |
3217-6 |
NUT-HEX Price: $1.19 |
| 11 |
530024303 |
Choke Knob Price: $5.99 |
| 12 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 12 |
545008009 |
KIT STARTER SPRING This part replaces 530042067. Price: $5.99 |
| 13 |
3230-1 |
BOLT-CARR Price: $1.49 |
| 13 |
530026035 |
Air Baffle Price: $2.99 |
| 14 |
251-253 |
BEARING Price: $22.84 |
| 14 |
530015373 |
Screw Price: $0.04 |
| 15 |
251-255 |
FLANGE Price: $15.34 |
| 15 |
530026048 |
Starter Pulley Price: $9.99 |
| 16 |
32151-44 |
RING-RETAINING Price: $2.99 |
| 16 |
530015596 |
Screw Price: $0.08 |
| 17 |
20-9490 |
WASHER Price: $8.14 |
| 17 |
530016141 |
Screw This part replaces 530015036. Price: $1.99 |
| 18 |
20-7400 |
SPACER-END Price: $11.87 |
| 18 |
530015123 |
Washer Price: $1.99 |
| 19 |
20-7380-01 |
BLADE-SPIKE, PROFILED This part replaces 20-7380. Price: $36.82 |
| 19 |
530001543 |
Nut Price: Call Us |
| 20 |
20-9480 |
SPACER Price: $12.27 |
| 20 |
530015582 |
Screw Price: $1.99 |
| 21 |
530069247 |
Line Kit Price: $3.99 |
| 21 |
92-7196 |
SHAFT This part replaces 20-9470. Price: $440.72 |
| 22 |
20-9460 |
KEY-SQUARE Price: $75.81 |
| 22 |
530091878 |
XR-105-T 1 Price: $5.99 |
| 22 |
530095646 |
Assy-Fuel Pickup This part replaces 530010897. Price: $2.99 |
| 23 |
20-9500 |
WASHER Price: $3.53 |
| 23 |
530015168 |
Screw Price: $1.46 |
| 24 |
251-253 |
BEARING This part replaces 251-254. Price: $22.84 |
| 25 |
20-9540 |
KEY-SQUARE Price: $4.74 |
| 26 |
112-7690-01 |
HUB ASM This part replaces 20-9980. Price: $197.32 |
| 26 |
530015123 |
Lockwasher Price: $1.99 |
| 27 |
20-9530 |
WASHER-END Price: $28.36 |
| 28 |
323-7 |
SCREW-HH Price: $0.65 |
| 29 |
530010838 |
Fuel Tank Ass'y. Price: $12.40 |
| 31 |
530014347 |
Assy-Fuel Cap This part replaces 530010729. Price: $4.99 |
| 32 |
530069181 |
Ignition Module Kit Price: $3.33 |
| 33 |
530025995 |
Electrical Tab Price: $0.99 |
| 34 |
530015816 |
Screw This part replaces 530015128. Price: $1.99 |
| 35 |
530024435 |
Plug Wire Grommet Price: $1.99 |
| 36 |
530039082 |
High Tension Lead Wire Price: Call Us |
| 37 |
530039103 |
High Tension Lead Ass'y. (Inc.36,38,39) Price: Call Us |
| 38 |
530003934 |
Spark Plug Boot Price: Call Us |
| 39 |
507475326 |
Spark Plug Boot This part replaces 530003933. Price: $3.99 |
| 40 |
530030077 |
Spark Plug (CJ-14) Price: $2.27 |
| 41 |
530026658 |
Air Deflector Price: $3.33 |
| 42 |
530015376 |
Screw Price: $3.33 |
| 43 |
530093802 |
Bolt Price: $3.13 |
| 45 |
530010763 |
XR-105 Price: $3.33 |
| 45 |
530010931 |
XR-125 Price: $3.33 |
| 46 |
530093959 |
Throttle Cable Price: $4.99 |
| 47 |
530015305 |
Screw Price: $1.99 |
| 48 |
530026122 |
Spacer Price: $1.99 |
| 49 |
530069232 |
Rope Kit Price: $3.99 |
| 51 |
530026741 |
Indicating Switch Plate Price: $1.99 |
| 52 |
530015598 |
Screw Price: $1.99 |
