| Ref | Part Number | Description |
|---|
| 1 |
532406480 |
NEEDS DESCRIPTION Price: Call Us |
| 1 |
HY3225 |
DISCONTINUED This part replaces 322-5. Price: Call Us |
| 2 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 2 |
532193542 |
AXLE.ASM.LT.CAST.LGHTWGHT This part replaces 532184706. Price: $119.99 |
| 3 |
13-6520 |
SEAL Price: $9.22 |
| 4 |
596873601 |
SPINDLE.WELDED.LH.15"TEX.X431 This part replaces 532403087. Price: $14.99 |
| 4 |
70-2420 |
DISCONTINUED-SEE SVC BULLETIN Price: Call Us |
| 5 |
13-6610 |
DISCONTINUED This part replaces 13-6490. Price: Call Us |
| 5 |
538691201 |
SPINDLE.WLDMT.RH.15INTIRE.X431 This part replaces 532403088. Price: $19.99 |
| 6 |
13-6610 |
DISCONTINUED Price: Call Us |
| 6 |
532006266 |
WASHER THRUST This part replaces 532124931. Price: $4.99 |
| 7 |
13-6600 |
DISCONTINUED Price: Call Us |
| 8 |
13-6590 |
GASKET Price: $17.53 |
| 8 |
812000029 |
RING CLIP Price: $3.99 |
| 9 |
254-57 |
BEARING CUP F/W Price: $17.38 |
| 9 |
532121232 |
CAP.SPINDLE.BLACK Price: $3.99 |
| 10 |
254-58 |
BEARING CONE Price: $48.61 |
| 11 |
70-2440 |
THRUST COLLAR Price: $63.13 |
| 12 |
93-4430 |
DISCONTINUED Price: Call Us |
| 13 |
13-6650 |
DISCONTINUED Price: Call Us |
| 13 |
532121749 |
WASHER Price: $2.99 |
| 14 |
596238701 |
Washers This part replaces 810040600. Price: $3.99 |
| 15 |
70-2450 |
DISCONTINUED Price: Call Us |
| 15 |
873540600 |
NUT CROWNLOCK 3/8-24 Price: $3.99 |
| 16 |
532196074 |
SHAFT STEERING Price: $34.99 |
| 16 |
70-2380 |
DISCONTINUED Price: Call Us |
| 17 |
70-2360 |
BLANK CAP Price: $157.29 |
| 18 |
115-9471 |
BEARING-CUP This part replaces 254-61. Price: $6.46 |
| 19 |
254-62 |
BEARING-ROLLER, CONE Price: $12.61 |
| 19 |
531169101 |
SERVICE KIT PLATE PLATE.STEER. This part replaces 532194729. Price: $19.99 |
| 20 |
13-6540 |
SHIM Price: $4.22 |
| 20 |
532441425 |
STEERING.BOOT.HUSQ.LT This part replaces 532411139. Price: $7.99 |
| 21 |
13-6630 |
SHIM Price: $9.29 |
| 21 |
587738905 |
KIT.SRVC.STEERINGSHAFT.ADAPTER This part replaces 532186737. Price: $7.99 |
| 22 |
587738901 |
KIT.SRVC.STEERINGSHAFT.LWRBSHG This part replaces 532194845. Price: $14.99 |
| 23 |
70-2370 |
DISCONTINUED Price: Call Us |
| 24 |
70-2390 |
DISCONTINUED Price: Call Us |
| 25 |
70-2410 |
DISCONTINUED Price: Call Us |
| 26 |
532439743 |
INSERT.CAP.WHL.STRG.HUSQ.PREM This part replaces 532415987. Price: $8.99 |
| 28 |
817000612 |
SCREW, 3/8-16X3/4 Price: $3.99 |
| 33 |
596238801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040500. Price: $2.99 |
| 35 |
532194732 |
GEAR.SECTOR.PLATE.DDL. Price: $27.99 |
| 45 |
596040001 |
Washers This part replaces 819113812. Price: $6.99 |
| 50 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT This part replaces 873900600. Price: $3.99 |
| 53 |
532188967 |
WASHER.HARDENED Price: $3.99 |
| 54 |
874760636 |
BOLT Price: $4.99 |
| 55 |
532414736 |
SPACER.BRACE.AXLE Price: $5.99 |
| 57 |
532407465 |
BRACKET.UPSTOP.TEX Price: $5.99 |
| 58 |
532194747 |
BOLT.SHOULDER.SECTOR.P Price: $7.99 |
| 59 |
532194748 |
WASHER.THURST.SECTOR.S Price: $4.99 |
| 60 |
583612801 |
NUT.FLANGE.LOCK.5/8-11 This part replaces 873971000. Price: $3.99 |
| 61 |
597047802 |
Links This part replaces 532194740. Price: $11.99 |
| 62 |
597047902 |
Links This part replaces 532194741. Price: $11.99 |
| 63 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 This part replaces 817000512. Price: $4.99 |
| 64 |
532199849 |
RETAINER.CLIP.SPRING.S Price: $4.99 |
| 65 |
532194734 |
BRACE.AXLE.FRONT.NLT/N Price: $37.99 |
| 66 |
871020748 |
BOLT HEX FGHD 7/16-14 X 3 SERR Price: $4.99 |
| 67 |
529496302 |
BUSHING, AXLE This part replaces 532194737. Price: $2.99 |
| 68 |
873900700 |
NUT.LOCK.FLANGE.7/16 Price: $3.99 |
| 69 |
532199162 |
WASHER.1.5X.505X.118 Price: $4.99 |
| 70 |
585338802 |
BRACKET FRONT DECK SUSPENSION This part replaces 532196197. Price: $14.99 |
| 71 |
532196075 |
SHAFT EXTENSION STEERING Price: $14.99 |
| 72 |
874780580 |
BOLT.FIN.HEX.5/16-18 This part replaces 874780572. Price: $4.99 |
| 78 |
532057079 |
THRUST WASHER Price: $1.99 |
| 118 |
532406013 |
BUSHING, AXLE CAST Price: $4.99 |
