| Ref | Part Number | Description |
|---|
| 1 |
237-80 |
O-RING Price: $6.10 |
| 1 |
532401042 |
SEAT.XG090.BLK.KB/BLT.NO-LOG This part replaces 532140838. Price: $149.99 |
| 2 |
44-7612 |
BOLT-HWH Price: $24.50 |
| 2 |
531152401 |
SERVICE KIT BRACKET SEAT PIVOT This part replaces 532140551. Price: $8.99 |
| 3 |
354-74 |
PLUG-HH Price: $17.90 |
| 3 |
871110616 |
BOLT, HEX 3/8-16X1 Price: $3.99 |
| 4 |
3219-3 |
NUT-HEX Price: $0.34 |
| 4 |
819131610 |
WASHER PM Price: $4.99 |
| 5 |
353-799 |
CONVERSION PLUG ASM Price: $87.60 |
| 5 |
532145006 |
PUSH CLIP Price: $2.99 |
| 6 |
353-798 |
PLATE-COVER, RIGHT Price: $451.34 |
| 6 |
596322601 |
Nuts This part replaces 873800600. Price: $2.99 |
| 7 |
587613301 |
SPRING.COMPRESSION.SEAT.BLACK This part replaces 532124181. Price: $5.99 |
| 8 |
817000616 |
SCREW 3/8-16X1 Price: $5.99 |
| 9 |
44-7621 |
COVER-END Price: $522.95 |
| 9 |
596140201 |
Washers This part replaces 819131614. Price: $2.99 |
| 10 |
353-952 |
SEAL-BACK-UP Price: $7.89 |
| 10 |
532195530 |
PAN.ASM.SEAT.1SLOT This part replaces 532174894. Price: $17.99 |
| 11 |
353-758 |
O-RING Price: $18.26 |
| 12 |
353-331 |
O-RING Price: $16.66 |
| 12 |
532174648 |
BRKT.MNTNG.SWITCH.SEAT.BLACK This part replaces 532121246. Price: $8.99 |
| 13 |
353-760 |
RELIEF-BODY Price: $239.97 |
| 13 |
532121248 |
BUSHING Price: $4.99 |
| 14 |
353-531 |
POPPET AND RING ASM Price: $229.51 |
| 14 |
872050412 |
BOLT.ROUND.HEAD.SQUARE.NECK Price: $4.99 |
| 15 |
353-328 |
SHIM (.040) Price: $3.53 |
| 15 |
532134300 |
SPACER SPLIT 28X.96 Price: $3.99 |
| 16 |
353-329 |
SHIM (.020) Price: $2.10 |
| 17 |
353-330 |
SHIM (.010) Price: $3.60 |
| 17 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 532123976. Price: $3.99 |
| 18 |
46-2380 |
SPRING Price: $24.81 |
| 19 |
353-334 |
CAP-RELIEF Price: $55.48 |
| 20 |
84-2190 |
SECTION SEAL KIT Price: $167.00 |
| 21 |
587907801 |
BOLT.5/16-18X5/8.SHOULDER This part replaces 532171852. Price: $2.99 |
| 22 |
106-4190 |
PLUG-HOLLOW, HEX Price: $63.34 |
| 22 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 23 |
871110814 |
BOLT.HEX.BLACK Price: $8.99 |
| 24 |
819171912 |
WASHER Price: $3.99 |
| 25 |
532127018 |
BOLT,SHOULD Price: $4.99 |
| 26 |
810040800 |
LOCKWASHER Price: $5.99 |
