| Ref | Part Number | Description |
|---|
| 1 |
5-0743-03 |
SPRING-MOWER This part replaces 5-0743. Price: $188.53 |
| 1 |
539109374 |
SEED BOX CHARCOAL GREY Price: $99.99 |
| 2 |
539106661 |
AGITATOR Price: $129.99 |
| 2 |
62-7240 |
DISCONTINUED Price: Call Us |
| 3 |
539108495 |
SCREW - #8-32 X 3/8 This part replaces 540000113. Price: $2.99 |
| 4 |
596230901 |
Screws This part replaces 539990580. Price: $2.99 |
| 5 |
3272-11 |
PIN-COTTER Price: $0.99 |
| 5 |
597338501 |
Washers This part replaces 539990598. Price: $12.99 |
| 6 |
539106677 |
GUIDE Price: $39.99 |
| 6 |
93-6912 |
DISCONTINUED Price: Call Us |
| 7 |
283-75 |
PIN-CLEVIS Price: $1.56 |
| 7 |
582478602 |
NUT FLG, NYLOCK, 1/4-20 GR G C This part replaces 539976978. Price: $1.99 |
| 8 |
539106678 |
GATE Price: $59.99 |
| 9 |
3272-10 |
PIN-COTTER Price: $0.25 |
| 9 |
539109375 |
SHIELD Price: $29.99 |
| 10 |
539990639 |
SCW 1/4-20 X 1-1/2 HEX Price: $2.99 |
| 10 |
92-1818-01 |
ARM-SPRING, TENSION This part replaces 92-1818. Price: $13.39 |
| 11 |
323-9 |
SCREW-HH Price: $1.29 |
| 11 |
539052551 |
CONTROL, PUSH/PULL ASSEMBLY This part replaces 540052551. Price: $43.99 |
| 12 |
32144-109 |
SCREW-THD Price: $1.29 |
| 12 |
539106680 |
MOUNT Price: $8.99 |
| 13 |
32144-14 |
SCREW-HWHTF Price: $4.29 |
| 13 |
539107357 |
SEED DIAL Price: $8.99 |
| 14 |
539977761 |
HCS 1/4C X 1 Price: $2.99 |
| 14 |
93-6893 |
PIN-PIVOT, RAM Price: $49.13 |
| 15 |
539106684 |
SEED DOOR ORANGE Price: $35.99 |
| 15 |
92-1812 |
SHAFT-PIVOT, LIFT Price: $51.90 |
| 16 |
539990548 |
HCS 1/4 X 1 Price: $2.99 |
| 17 |
3296-39 |
NUT-LOCK, NI Price: $2.29 |
| 17 |
539106806 |
SEED WINDOW Price: $11.99 |
| 18 |
302-60 |
FITTING-GREASE Price: $2.26 |
| 18 |
540200141 |
DECAL, SEED DIAL Price: $9.99 |
| 19 |
596238401 |
BOLT CUP HEAD SQUARE NECK BOLT This part replaces 539990074. Price: $2.99 |
| 19 |
94-5009 |
HOSE ASM Price: $102.32 |
| 20 |
539990997 |
WING NUT 1/4 Price: $2.99 |
| 20 |
94-5008 |
HOSE ASM Price: $102.26 |
| 21 |
340-103 |
FITTING-HYD, 45 DEG Price: $36.92 |
| 21 |
539107246 |
WINDOW CLIP Price: $2.99 |
| 22 |
340-92 |
FITTING-STRAIGHT Price: $12.29 |
| 22 |
540200140 |
DECAL, SEED APPL Price: $9.99 |
| 23 |
540200143 |
DECAL, OPEN/CLOSE Price: $4.99 |
| 23 |
93-6869 |
HYD CYLINDER ASM Price: $638.61 |
| 24 |
125-5196 |
BUSHING This part replaces 3-0348. Price: $6.00 |
| 24 |
539052931 |
BRACKET, PUSH/PULL This part replaces 540052931. Price: $3.99 |
| 26 |
93-6696 |
DECAL-WARNING Price: $14.78 |
| 28 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 29 |
93-6926 |
PIN-CLEVIS Price: $33.72 |
| 30 |
322-4 |
SCREW-HH Price: $0.35 |
| 31 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 32 |
322-26 |
SCREW-HH Price: $2.36 |
| 33 |
3253-4 |
WASHER-LOCK Price: $0.25 |
| 34 |
3256-57 |
WASHER-FLAT Price: $0.41 |
| 35 |
94-3635 |
CENTER LIFT ARM ASM Price: $280.94 |
| 36 |
256-115 |
WASHER-THRUST Price: $1.90 |
| 37 |
99-2338 |
SHAFT-PIVOT Price: $101.09 |
| 38 |
3256-6 |
WASHER-FLAT Price: $0.34 |
| 39 |
3234-32 |
SCREW-HHF Price: $8.48 |
| 40 |
237-78 |
O-RING Price: $3.85 |
| 41 |
237-21 |
O-RING Price: $0.70 |
| 42 |
98-3445 |
SPACER Price: $6.02 |
| 43 |
98-3446 |
PLATE-REINFORCEMENT Price: $11.38 |
| 44 |
323-4 |
SCREW-HH Price: $1.02 |
