| Ref | Part Number | Description |
|---|
| 1 |
120-4072 |
LEFT DECK ASM This part replaces 110-3296. Price: $2,840.39 |
| 2 |
100-8125-01 |
LH SKID ASM Price: $136.18 |
| 3 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 4 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 5 |
3296-56 |
NUT-LOCK, NI Price: $2.09 |
| 6 |
99-5493 |
PULLEY-IDLER Price: $78.45 |
| 7 |
100-3102 |
WASHER-FLAT Price: $3.70 |
| 8 |
108-8076 |
V-BELT, DECK Price: $29.86 |
| 9 |
3234-42 |
SCREW-HHF Price: $1.10 |
| 10 |
139-1039 |
LOW DRIVEN SPINDLE ASM This part replaces 104-3532. Price: $589.65 |
| 11 |
32108-103 |
SCREW-FH Price: $0.68 |
| 12 |
69-9290 |
PAD-BUMPER Price: $9.52 |
| 13 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 14 |
104-2250-01 |
SKID-SIDE Price: $116.02 |
| 15 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 16 |
325-5 |
SCREW-HH Price: $1.20 |
| 17 |
3256-3 |
WASHER-FLAT Price: $0.49 |
| 18 |
3290-343 |
PIN-HAIR Price: $0.76 |
| 19 |
104-7529-01 |
BRACKET-CASTOR Price: $225.46 |
| 20 |
104-3579 |
DECAL-HOC Price: $23.95 |
| 21 |
100-5569 |
PIN-CLEVIS Price: $22.34 |
| 22 |
104-7524 |
SHIM Price: $5.30 |
| 23 |
121-1720-01 |
BRACKET-FORK This part replaces 104-7525-01. Price: $36.79 |
| 24 |
3234-24 |
SCREW-HHF Price: $3.19 |
| 25 |
3233-4 |
SCREW-CARR Price: $1.90 |
| 26 |
106-2047 |
ROD-TENSION Price: $9.83 |
| 27 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 28 |
104-0858 |
BOLT-SHOULDER Price: $4.69 |
| 29 |
920242 |
WASHER-FLAT This part replaces 9202424. Price: $5.19 |
| 30 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 31 |
325-7 |
SCREW-HH Price: $1.53 |
| 32 |
32120-72 |
RING-SNAP Price: $2.09 |
| 33 |
3-6498 |
WASHER-THRUST Price: $4.58 |
| 34 |
110-6129 |
IDLER ARM ASM This part replaces 110-3276. Price: $113.06 |
| 35 |
32128-14 |
NUT-HF Price: $0.41 |
| 36 |
68-0090 |
SCREW-ADJUSTING Price: $7.49 |
| 37 |
3230-32 |
SCREW-CARR Price: $15.26 |
| 38 |
107938 |
SPRING-EXTENSION Price: $9.99 |
