| Ref | Part Number | Description |
|---|
| 1 |
532443344 |
BRACKET.SHIFT.HYDRO Price: $3.99 |
| 1 |
75-3480 |
FRAME-UPPER Price: $323.32 |
| 2 |
108-6703 |
ADJUSTER-SEAT This part replaces 66-8530. Price: $183.47 |
| 2 |
817501010 |
SCREW #10-24 X 5/8 Price: $4.99 |
| 3 |
66-8520 |
BUMPER-DOWNSTOP Price: $37.56 |
| 3 |
874760552 |
SCREW 5/16-18 X 3.25 Price: $3.99 |
| 4 |
532179246 |
WASHER, NYLON FRICTION Price: $3.99 |
| 4 |
82-9060 |
DISCONTINUED Price: Call Us |
| 5 |
532425596 |
CONTROL.WLD.HYD.II Price: $49.99 |
| 5 |
76-1960 |
KNOB KIT This part replaces 77-2870. Price: $357.33 |
| 6 |
532155415 |
WASHER.20X8.5 Price: $4.99 |
| 6 |
76-1910 |
DISCONTINUED Price: Call Us |
| 7 |
532192195 |
SRPING.FRICTION.HYDRO Price: $3.99 |
| 7 |
66-8560 |
NUT-PUSH Price: $5.97 |
| 8 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
| 8 |
76-1940 |
SPRING-EXTENSION Price: $66.03 |
| 9 |
532443347 |
BRACKET.CABLE.PNT.HYDRO Price: $3.99 |
| 9 |
76-1920 |
SLEEVE-BEARING Price: $22.50 |
| 10 |
106-1031 |
TENSION ADJUSTER KNOB ASM This part replaces 76-1930. Price: $68.93 |
| 10 |
532428867 |
BOLT.HEX.HD.WASHER.5/16-18X.75 Price: $4.99 |
| 11 |
532405485 |
ARM, AUGER CONTROL Price: $6.99 |
| 11 |
66-8610 |
DISCONTINUED Price: Call Us |
| 12 |
532198580 |
CLEVIS PIN Price: $4.99 |
| 12 |
66-9290 |
SPACER-SUSPENSION Price: $3.60 |
| 13 |
532437151 |
PLATE.REAR.HYDRO.PNT.ORANGE Price: $7.99 |
| 13 |
75-3580 |
PLATE-SEAT Price: $213.06 |
| 14 |
532057079 |
THRUST WASHER Price: $1.99 |
| 14 |
75-3510 |
BOLT-SHOULDER Price: $14.55 |
| 15 |
532429668 |
KIT.CONTROL.SHAFT.SNOW This part replaces 532427542. Price: $29.99 |
| 15 |
80-4860 |
PIN-CLEVIS Price: $6.13 |
| 16 |
532443350 |
LEVER.STEER.CABLE.PNT.SNOW Price: $3.99 |
| 16 |
75-3530 |
SPRING-COMPRESSION Price: $31.98 |
| 17 |
3285-19 |
PIN-GROOVE This part replaces 75-3540. Price: $1.79 |
| 17 |
532443349 |
BRACKET.SPEED.PIVOT.YZP Price: $7.99 |
| 18 |
532443348 |
BRACKET.SPEED.PIVOT.YZP Price: $6.99 |
| 18 |
75-3550 |
BUMPER-SEAT Price: $18.48 |
| 19 |
532198249 |
ARM.HYD.CLUTCH Price: $6.99 |
| 19 |
76-2940 |
BUMPER Price: $9.73 |
| 20 |
532428288 |
E-RING.RETAINER.REINFORCED.375 Price: $3.99 |
| 20 |
75-3570 |
TIP-VINYL Price: $2.48 |
| 21 |
3253-6 |
WASHER-LOCK Price: $0.39 |
| 21 |
532402881 |
BOLT.SHOULDER.3/X.25 Price: $3.99 |
| 22 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 22 |
532191730 |
NUT.HEX.FLANGE.1/4 Price: $3.99 |
| 23 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 23 |
532065322 |
COTTER PIN (3 2)(2 2MC) Price: $3.99 |
| 24 |
3296-44 |
NUT-LOCK, NI Price: $2.46 |
| 24 |
532425496 |
ROD.STEER.HYD Price: $22.99 |
| 25 |
32128-26 |
NUT-FLANGE Price: $5.89 |
| 25 |
532194124 |
SPRING.RETURN Price: $4.99 |
| 26 |
3256-46 |
WASHER-FLAT Price: $5.77 |
| 26 |
532443346 |
BRACKET.HYDRO.STABILIZER Price: $6.99 |
| 27 |
3256-5 |
WASHER-FLAT Price: $0.27 |
| 27 |
532443345 |
BRACKET.TRANSMISSION.MOUNT Price: $7.99 |
| 28 |
874880432 |
BOLT.HEX.1/4-20X2.00.HEX.HD. Price: $3.99 |
| 28 |
93-3164 |
CAP Price: $11.64 |
| 29 |
596580801 |
Bolts This part replaces 874760516. Price: $2.99 |
| 29 |
93-3163 |
SPRING Price: $26.01 |
| 30 |
532751153 |
NUT.LOCK.5/16-18 Price: $2.99 |
| 30 |
93-3165 |
BRACKET Price: $37.47 |
| 31 |
322-6 |
SCREW-HH Price: $0.45 |
| 31 |
532198251 |
SHAFT.HYD.CLUTCH Price: $17.99 |
| 32 |
3253-33 |
WASHER-LOCK Price: $1.19 |
| 32 |
532446293 |
ROD.HYDRO CLUTCH This part replaces 532198250. Price: $7.99 |
| 33 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 34 |
532425499 |
ROD.SPEED.CONT.HYD.SNOW Price: $8.99 |
| 35 |
532169675 |
SPRING RETAINER Price: $4.99 |
| 36 |
532429803 |
BRACKET.HYD.CLUTCH. Price: $4.99 |
| 37 |
532180355 |
BOLT.CARRIAGE.5/16-18X Price: $3.99 |
| 38 |
591388201 |
TRANSMISSION.HYDRO 2 This part replaces 532425394. Price: $1,199.99 |
| 39 |
532178828 |
SPRING, BRAKE Price: $4.99 |
| 40 |
532425498 |
PAN.BOTTOM.PLASTIC.SNOW Price: $27.99 |
| 41 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 42 |
819091214 |
WASHER This part replaces 532053847. Price: $8.99 |
