| Ref | Part Number | Description |
|---|
| 1 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 1 |
603-04305 |
THROTTLE TAB ASSEMBLY Not Available This part replaces 603-0711. Price: |
| 2 |
532122047 |
BRKT,STAB LINK Price: $3.99 |
| 2 |
629-3061 |
DASH PANEL HARNESS Not Available Price: |
| 3 |
631-0076 |
STEERING TILT BOOT ASSEMBLY Not Available Price: |
| 3 |
819171713 |
WASHER STEEL Price: $2.99 |
| 4 |
532003146 |
SPRING RETAINER This part replaces 532124660. Price: $2.99 |
| 4 |
631-04007 |
DASH PANEL Not Available Price: |
| 5 |
532124636 |
STABILIZER MOWER Price: $24.99 |
| 5 |
703-3479 |
THROTTLE CABLE MOUNT PLATE Not Available Price: |
| 6 |
532122045 |
BRKT,FRT LIFT RH Price: $3.99 |
| 6 |
710-0578 |
Screw, Truss Hd, 1/4-20 x 1.5 Price: $3.93 |
| 7 |
532123661 |
GUIDE,FRT MAN RH Price: $5.33 |
| 7 |
710-0604A |
Screw, Hex Wash. Hd. Tapp 5/16-18 x .625 Price: $3.96 |
| 8 |
532123713 |
SPRING TORSION Price: $6.99 |
| 8 |
710-0924 |
Screw, Pan Hd., 1/4-20 x .75 Price: $4.02 |
| 9 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 9 |
710-3013 |
Screw, Hex Cap, 1/4-20 x .5 GR5 Price: $4.02 |
| 10 |
532136631 |
BRACKET ASM DEFLECTOR This part replaces 532126361. Price: $9.99 |
| 10 |
712-0237 |
Nut, Hex Lock, 5/16-24 Price: $4.37 |
| 11 |
712-0292 |
Nut, Speed, 1/4-20 Price: $8.97 |
| 11 |
819111016 |
Washer 11/32 x 5/8 Ga. Price: $5.99 |
| 12 |
593885101 |
Rods This part replaces 532121980. Price: $5.99 |
| 12 |
712-3006 |
HEX NUT Price: $4.05 |
| 13 |
532110452 |
NUT PUSH M Price: $2.99 |
| 13 |
712-3061 |
Nut, Hex Nylon Insert Lock, 3/8-24 Price: $5.94 |
| 14 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 14 |
723-3013 |
FRICTION DISC Not Available Price: |
| 15 |
532136244 |
DISCHARGE GUARD This part replaces 532126370. Price: $20.64 |
| 15 |
725-2017 |
SWITCH HOLE COVER Not Available Price: |
| 16 |
532125629 |
DEFL SUPT ASS'Y Price: $19.37 |
| 16 |
725-3265 |
Panel, Instrument Price: Call Us |
| 17 |
725-3274 |
SWITCH-HEADLAMP NLAUD Not Available Price: |
| 17 |
817051007 |
Screw, Pan Hd. PLT-30 Price: $3.99 |
| 18 |
596030501 |
SCREW HEXAGON HEAD SCREW 5/16- This part replaces 874760512. Price: $3.99 |
| 18 |
725-3276 |
PTO SWITCH Not Available Price: |
| 19 |
532122043 |
BRKT,REAR LIFT RH Price: $5.60 |
| 19 |
925-3277 |
IGNITION SWITCH This part replaces 725-3277. Price: $96.07 |
| 20 |
532122044 |
BRKT,REAR LIFT LH Price: $9.99 |
| 20 |
725-3279B |
HAZARD LAMP SWITCH Not Available This part replaces 725-3279. Price: |
| 21 |
731-3209 |
STEERING WHEEL Not Available Price: |
| 22 |
731-06459 |
Cover, Steering Wheel This part replaces 731-3210. Price: $18.55 |
| 23 |
731-3298 |
THROTTLE HANDLE Not Available Price: |
| 24 |
731-3344 |
DASH PANEL INSERT Not Available Price: |
| 25 |
736-0242 |
Washer, Belleville, .34 x .872 x .06 Price: $3.75 |
| 26 |
936-0329 |
L-Wash. 1/4" I.D. This part replaces 736-0329. Price: $3.90 |
| 27 |
936-0356 |
BELL WASHER Not Available This part replaces 736-0356. Price: |
| 28 |
936-3022 |
BELL WASHER Not Available This part replaces 736-3022. Price: |
| 29 |
736-3052 |
Washer, Flat, .406 x 1.0 x .105 Price: $4.02 |
| 30 |
746-3086A |
THROTTLE CABLE Not Available Price: |
| 532105814 |
DECAL |
LT NLA Price: $5.53 532105814 |
| 532109820 |
DECAL |
YT Price: $5.46 532109820 |
| 532123658 |
DECAL |
WARNING Price: $3.08 532123658 |
