| Ref | Part Number | Description |
|---|
| 1 |
108-9956 |
TIRE AND WHEEL ASM Price: $237.80 |
| 1 |
532170551 |
CONTROL TH/CH FLAG Price: $22.99 |
| 2 |
1-633959 |
SPACER-CASTER, FRONT Price: $16.99 |
| 2 |
539990071 |
HCS.1/4-20.X1/2 This part replaces 817720408. Price: $1.99 |
| 3 |
1-633581 |
SPACER-BEARING Price: $4.09 |
| 4 |
325-39 |
SCREW-HH Price: $16.99 |
| 4 |
532179758 |
MUFFLER Price: $70.99 |
| 5 |
3296-25 |
NUT-LOCK, NI Price: $1.34 |
| 6 |
1-633585 |
BEARING-CONE, TAPER Price: $20.99 |
| 13 |
532272293 |
Gasket Eng 1 313 Id Tin Plated This part replaces 532165291. Price: $7.99 |
| 23 |
532169837 |
SHEILD.BROWNING.DBR.GUARD Price: $7.99 |
| 25 |
532190695 |
Price: $2.99 |
| 29 |
532137180 |
ARRESTER SPARK (OPTIONAL) Price: $128.99 |
| 31 |
532407516 |
Price: Call Us |
| 32 |
581075501 |
CAP.FUEL.TANK.SS/SNO.EPA.DOME This part replaces 532430220. Price: $14.99 |
| 33 |
532123487 |
HOSE CLAMP Price: $3.99 |
| 37 |
532137040 |
LINE.FUEL.20 Price: $3.99 |
| 40 |
532124028 |
GROMMET T Price: $3.99 |
| 44 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $2.99 |
| 45 |
817000612 |
SCREW, 3/8-16X3/4 Price: $2.99 |
| 46 |
819091416 |
WASHER Price: $3.99 |
| 72 |
532192334 |
SCREW.SOCKET HD.5/16-1 Price: $2.99 |
| 78 |
817060620 |
SCREW.3/8-16 Price: $3.99 |
| 81 |
873680400 |
Nut Crownlock 1/4-20 unc This part replaces 873510400. Price: $2.69 |
