| Ref | Part Number | Description |
|---|
| 1 |
1105620 |
PLUG-PIPE SQ HD 1/ Price: $3.66 |
| 2 |
1901439 |
SPRING-REV PLUNGER Price: $10.67 |
| 3 |
1901440 |
RING-KLIP Price: $4.79 |
| 4 |
1902004 |
SCREW 3/8-16X1.5 UNC Price: $7.46 |
| 5 |
1911372 |
SPRING PIN .188X1. Not Available Price: |
| 6 |
611-04003 |
ECCENTRIC SHAFT Price: $78.82 |
| 7 |
714-04014 |
KEY:HI-PRO Price: $18.36 |
| 7 |
911-04077 |
HORSE WHEEL SHAFT ASSEMBLY W/KEY Price: $163.83 |
| 8 |
619-04000-0637 |
ECCENTRIC ARM Price: $53.27 |
| 9 |
N/A |
NOT SERVICEABLE |
| 10 |
710-0376 |
SCREW 5/16-18 x 1.0 GR5 Price: $3.66 |
| 11 |
1186310 |
SCREW 1/4-20 x .75 GR5 Price: $3.11 |
| 12 |
710-0489 |
SCREW 1/2-13 x 2 GR5 Price: $6.24 |
| 13 |
710-0520 |
SCREW 3/8-16 x 1.50 Price: $3.93 |
| 14 |
712-04065 |
NUT Price: $3.68 |
| 15 |
712-3010 |
HEX NUT 5/16-18 This part replaces 912-3010. Price: $3.89 |
| 16 |
715-0121 |
SPRING PIN1/4 x 2.00 Price: $5.95 |
| 17 |
716-0101 |
Retaining Ring-external This part replaces 916-0101. Price: $3.37 |
| 18 |
716-04102 |
RETAINING RING Price: $3.85 |
| 19 |
716-04104 |
RETAINING RING Price: $3.85 |
| 20 |
716-04119 |
RETAINING RING Price: $12.96 |
| 21 |
718-04006 |
BEARING RETAINING PLUG Price: $43.49 |
| 22 |
718-04007 |
FRONT BEARING COVER Price: $16.60 |
| 23 |
718-04615 |
PTO TRANS CLUTCH Price: $46.92 |
| 24 |
719-04015P |
TRANS COVER Price: $204.95 |
| 26 |
921-04030 |
OIL SEAL .750 SHF x 1.783 Price: $11.33 |
| 27 |
921-04031 |
OIL SEAL 1.0 SHF x 1.499 Price: $9.58 |
| 28 |
921-04034 |
OIL SEAL .625 SHF x 1.000 Price: $9.37 |
| 29 |
921-04044 |
OIL SEAL Price: $8.80 |
| 31 |
736-04257 |
FLAT WASHER: 1.015 x 1.375 x .005 Price: $3.48 |
| 32 |
736-04258 |
FLAT WASHER 1.015 x 1.375 x .010 Price: $3.48 |
| 33 |
736-04259 |
FLAT WASHER 1.015 x 1.375 x .015 Price: $5.94 |
| 34 |
736-04260 |
FLAT WASHER 1.015 x 1.375 x .030 Price: $5.94 |
| 35 |
736-04305 |
FLAT WASHER 1.500X1.750X.062 Price: $3.52 |
| 36 |
736-04306 |
FLAT WASHER 1.500X1.750X.005 Price: $3.85 |
| 37 |
736-04307 |
FLAT WASHER 1.500X1.750X.030 Price: $3.85 |
| 38 |
736-04308 |
FLAT WASHER 1.500X1.750X0.010 Price: $3.85 |
| 39 |
736-04309 |
FLAT WASHER 1.015X1.375X.062 Price: $3.85 |
| 40 |
736-04310 |
FLAT WASHER 1.015X1.234X.062 Price: $3.95 |
| 43 |
741-04008 |
ECCENTRIC BUSHING Price: $25.38 |
| 44 |
941-04298 |
BEARING CONE Price: $14.84 |
| 45 |
941-04299 |
BEARING CUP Price: $6.01 |
| 46 |
941-04300 |
BUSHING 1.005 x 1.25 x 1.5 Price: $15.25 |
| 47 |
GW-1035 |
NEUTRAL PLUNGE AS Price: $33.23 |
| 48 |
GW-1112 |
PIN-CLUTCH Price: $4.06 |
| 49 |
GW-1123 |
TRANSMISSION COVER GASKET Price: $7.44 |
| 50 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces 936-0272. Price: $4.37 |
| 51 |
736-04386 |
Washer, 1.00 x 1.50 x .03, SS This part replaces GW-1132-1. Price: $6.01 |
| 52 |
GW-1132-3 |
SHIM Price: $5.95 |
| 53 |
GW-1222 |
SPLINE GEAR 10 TEETH Price: $122.90 |
| 54 |
GW-1223 |
SPUR GEAR 56 TEETH Price: $196.25 |
| 55 |
GW-1232 |
SPUR GEAR Price: $135.63 |
| 56 |
GW-1233 |
SPUR GEAR 20 TEETH Price: $125.18 |
| 57 |
GW-1237 |
CLUTCH DOG Price: $142.70 |
| 58 |
GW-1441 |
SPRING Price: $3.61 |
| 59 |
738-04448 |
PIN Price: $7.14 |
| 60 |
GW-2126 |
POST Price: $27.91 |
| 61 |
GW-2461 |
SGAFT-WELD ECCENTR Price: $34.31 |
| 62 |
GW-2655 |
SHAFT-WHEEL DRIVE Price: $193.24 |
| 63 |
GW-2656 |
WORM GEAR Price: $129.55 |
| 64 |
GW-9122 |
PLUG-CAP (RED) Price: $8.93 |
| 65 |
GW-9300 |
KEY Price: $3.22 |
| 66 |
GW-9301 |
Key, 3/16 sq. x 1 This part replaces GW-9301099. Price: $3.46 |
| 67 |
GW-9359 |
PIN-DRIVE Price: $3.22 |
| 68 |
GW-9404 |
BALL BEARING Price: $24.30 |
| 69 |
GW-9516 |
RETAINING RING Price: $3.56 |
| 70 |
GW-9604 |
O-RING Price: $4.62 |
| 71 |
710-04354 |
SCREW-SOCKET HE Price: $3.38 |
| 72 |
GW-9911 |
LOCK WASHER Price: $5.23 |
