| Ref | Part Number | Description |
|---|
| 1 |
137-6120 |
LONG REAR ROLLER ASM (3IN DIA)(27IN) This part replaces 112-8915. Price: $448.76 |
| 1 |
530035007 |
Clip-Throttle Shaft Price: Call Us |
| 2 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 2 |
530035003 |
Cover-Metering Diaphragm Price: $3.99 |
| 3 |
119-0626 |
SHIM-ROLLER Price: $3.23 |
| 3 |
530035004 |
Cover-Fuel Pump Price: $3.33 |
| 4 |
530035005 |
Shaft-Throttle Price: $3.33 |
| 5 |
106-3924 |
BRACKET-ROLLER, REAR Price: $23.58 |
| 5 |
530035006 |
Shutter-Throttle Price: Call Us |
| 6 |
3230-26 |
SCREW-CARR Price: $3.99 |
| 6 |
530035008 |
Valve-Inlet Needle Price: $3.33 |
| 7 |
117-0960 |
PLASTIC WIEHLE ROLLER ASM Price: $482.64 |
| 7 |
530035009 |
Gasket-Fuel Pump Price: $1.99 |
| 8 |
530035012 |
Gasket-Circuit Plate Price: $3.33 |
| 9 |
32128-20 |
NUT-HF Price: $0.99 |
| 9 |
530035011 |
Gasket-Metering Diaphragm Price: Call Us |
| 10 |
322-16 |
SCREW-HH Price: $3.39 |
| 10 |
530035013 |
Diaphragm-Fuel Pump Price: $3.33 |
| 11 |
323-14 |
SCREW-HH Price: $1.34 |
| 11 |
503896701 |
DIAPHRAGM This part replaces 530035014. Price: $4.99 |
| 12 |
120-0404 |
BRACKET-HIGH HOC (LH) Price: $71.73 |
| 12 |
120-0405 |
BRACKET-HIGH HOC (RH) Price: $71.73 |
| 12 |
530035015 |
Screw-Throttle Shutter Price: $1.99 |
| 13 |
104-8301 |
NUT-HF, NI Price: $1.09 |
| 13 |
530035016 |
Screw-Metering Lever Pin Price: $2.99 |
| 14 |
48-9220 |
WASHER-PLAIN Price: $0.87 |
| 14 |
530035019 |
Screw-Idle Adj. Price: $3.33 |
| 15 |
107-4026 |
SCREW-HH Price: $5.28 |
| 15 |
530035018 |
Screw-Circuit Plate Price: $3.33 |
| 16 |
530035021 |
Screw-Metering Cover Price: $1.99 |
| 16 |
94-6936 |
WASHER-HARDENED Price: $0.58 |
| 17 |
530035017 |
Screw-Pump Cover Price: $0.99 |
| 18 |
530035023 |
Spring-Idle Adj. Needle Price: $0.99 |
| 19 |
530035022 |
Spring-Idle Adj. Screw Price: $3.33 |
| 20 |
530035025 |
Spring-Metering Lever Price: $3.33 |
| 21 |
530035024 |
Spring-Throttle Return Price: Call Us |
| 22 |
530035026 |
Needle-Idle Price: $3.33 |
| 23 |
530035027 |
Screen-Inlet Price: $1.99 |
| 24 |
505520125 |
Pin This part replaces 530035028. Price: $1.99 |
| 25 |
530035029 |
Plate-Circuit (Standard) Price: $3.33 |
| 25 |
530035044 |
Plate-Circuit (High altitude above 5,000 feet) Price: $3.33 |
| 26 |
505520127 |
Metering Lever This part replaces 530035031. Price: $3.99 |
