| Ref | Part Number | Description |
|---|
| 1 |
117-8982 |
TANK-HYDRAULIC This part replaces 104-9254. Price: $1,846.02 |
| 1 |
530016153 |
Screw Price: $1.99 |
| 2 |
530039232 |
Module-Ignition Price: $16.40 |
| 2 |
68-6150 |
BREATHER Price: $27.22 |
| 3 |
530016432 |
Screw Price: $1.99 |
| 3 |
61-2790 |
FILTER-SCREEN Price: $49.91 |
| 4 |
530058661 |
Strap-Ground Price: $1.99 |
| 4 |
94-9411 |
DIPSTICK Price: $42.51 |
| 5 |
354-73 |
FITTING Price: $27.56 |
| 5 |
530057943 |
Assy-Wire Harness Price: $5.99 |
| 6 |
530055698 |
Reflector-Tape Price: $1.99 |
| 6 |
93-7498 |
PLUG-PLASTIC Price: $25.26 |
| 7 |
340-8 |
FITTING-STRAIGHT Price: $9.70 |
| 8 |
340-87 |
FITTING-ELBOW, 45 DEG Price: $18.39 |
| 8 |
530016080 |
Screw Price: $1.99 |
| 9 |
530057891 |
Lever-Ignition Switch Price: $4.99 |
| 9 |
99-6932 |
FITTING-STR Price: $118.43 |
| 10 |
321-24 |
SCREW-HH This part replaces 321-23. Price: $2.31 |
| 10 |
530057908 |
Spring-Ignition Switch Price: $2.99 |
| 11 |
530059399 |
Knob-Choke Price: $1.99 |
| 11 |
92-9098 |
MANIFOLD-TANK Price: $297.10 |
| 12 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 12 |
530059001 |
Cover-Air Filter Price: $3.99 |
| 13 |
354-74 |
PLUG-HH Price: $17.90 |
| 13 |
530057869 |
Filter-Air Price: $1.99 |
| 14 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 14 |
530016425 |
Screw Price: $1.99 |
| 15 |
2412-34 |
CLAMP-HOSE Price: $2.14 |
| 15 |
530150029 |
Housing-Air Filter w/cable Price: $4.24 |
| 16 |
545070601 |
Carb-Zama W-26B This part replaces 530035590. Price: $27.99 |
| 16 |
75-5720 |
HOSE-RETURN Price: $39.38 |
| 17 |
530069247 |
Kit-Fuel Line (Small) Price: $3.69 |
| 17 |
75-6870 |
HOSE-INLET, PUMP Price: $50.00 |
| 18 |
530047721 |
Bulb-Purge "snap-in" Price: $3.99 |
| 19 |
104-7546 |
TANK STRAINER ASM Price: $170.48 |
| 20 |
2412-93 |
CLAMP-R Price: $1.02 |
| 20 |
530071894 |
Gasket-cyl. o-ring (kit) Price: $6.99 |
| 21 |
503235111 |
BPMR7A NGK SPARK PLUG This part replaces 952030150. Price: $3.69 |
| 21 |
75-1300 |
OIL FILTER ASM Price: $427.40 |
| 22 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 23 |
340-139 |
FITTING-ELBOW 90 Price: $117.76 |
| 23 |
530058660 |
Clip-High Tension Lead Price: $1.99 |
| 24 |
33105-025 |
SCREW-HHF Price: $1.56 |
| 25 |
530057942 |
Backplate-Muffler Price: $5.99 |
| 25 |
63-8410 |
WASHER Price: $1.76 |
| 26 |
530071894 |
Gasket-Muffler (kit) Price: $6.99 |
| 26 |
75-6130 |
HOSE ASM Price: $158.19 |
| 27 |
240-11 |
BUSHING-FLANGE Price: $5.32 |
| 27 |
545006056 |
Kit-Spark Arrestor Price: $6.99 |
| 28 |
3256-24 |
WASHER-FLAT Price: $0.28 |
| 28 |
530016338 |
Bolt-Muffler Price: $1.99 |
| 29 |
3253-21 |
WASHER-LOCK Price: $0.28 |
| 29 |
545015301 |
Insert-Left (black) Cyl. This part replaces 530057885. Price: $2.99 |
| 30 |
323-4 |
SCREW-HH Price: $1.02 |
| 30 |
545112901 |
Assy-Crankshaft/Rod This part replaces 530012537. Price: $46.99 |
| 31 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 31 |
530016417 |
Bolt Price: $1.99 |
| 32 |
340-82 |
FITTING-ELBOW, 90 DEG Price: $20.57 |
| 32 |
530057941 |
Cap-Crankcase Price: $5.99 |
| 33 |
100-3739 |
RETURN DRAIN HOSE ASM Price: $149.42 |
| 33 |
530056363 |
Assy-Bearing/Seal Price: $11.99 |
| 34 |
93-7499 |
GASKET Price: $5.91 |
| 35 |
237-101 |
O-RING Price: $2.80 |
| 35 |
530015697 |
Retainer-Piston Pin Price: $1.99 |
| 36 |
545160401 |
Ring-Piston This part replaces 530038729. Price: $2.99 |
| 36 |
93-7588 |
COVER-TANK Price: $37.60 |
| 37 |
545015401 |
Insert-Right (gray) Cyl. This part replaces 530057886. Price: $2.99 |
| 37 |
92-8020 |
ADAPTER-BREATHER Price: $10.50 |
| 38 |
33104-020 |
SCREW-HHF Price: $2.07 |
| 38 |
530071894 |
Seal-Adaptor (kit) Price: $6.99 |
| 39 |
353-508 |
PLUG-HH Price: $7.96 |
| 39 |
530016426 |
Screw Price: $1.99 |
| 40 |
530071894 |
Gasket-Carb. (kit) Price: $6.99 |
| 41 |
530057926 |
Tube-Intake Price: $1.99 |
| 42 |
530016101 |
Nut-Carb. Price: $1.99 |
| 44 |
530031163 |
Wrench-Bar Price: $4.99 |
