| Ref | Part Number | Description |
|---|
| 1 |
3296-42 |
NUT-LOCK, NI Price: $0.28 |
| 2 |
56-3340-01 |
TENSION ADJ BRKT WA This part replaces 56-3340. Price: $23.64 |
| 3 |
321-4 |
SCREW-HH Price: $0.99 |
| 4 |
56-3330-01 |
TENSION ADJ CONT WA This part replaces 56-3330. Price: $51.05 |
| 5 |
283-26 |
PIN Price: $3.73 |
| 8 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 9 |
56-3360-01 |
PULLEY BRKT This part replaces 56-3360. Price: $8.81 |
| 10 |
3256-23 |
WASHER-PLAIN Price: $0.28 |
| 11 |
56-2780 |
CABLE RETAINER Price: Call Us |
| 12 |
59-5390 |
SPRING BRACKET Price: $45.02 |
| 13 |
56-3350 |
CABLE Price: $49.86 |
| 14 |
59-5400 |
BOLT-SHOULDER Price: $50.99 |
| 15 |
256-159 |
BUSHING Price: $24.63 |
| 16 |
3-8775 |
DISCONTINUED Price: Call Us |
| 17 |
56-3380-01 |
DISCONTINUED This part replaces 56-3380. Price: Call Us |
| 18 |
1-806003 |
PIN-COTTER This part replaces 3290-307. Price: $1.39 |
| 19 |
56-2770 |
EXTENSION SPRING Price: $17.95 |
| 20 |
32128-13 |
NUT-HF Price: $1.79 |
| 300 |
601001487 |
GEAR CASE, RH Price: $55.99 |
| 301 |
601001488 |
GEAR CASE, LH Price: $55.99 |
| 303 |
601001443 |
SCREW Price: $2.88 |
| 304 |
601000823 |
NUT 5/16-24 HXWDFLLK Price: $3.99 |
| 305 |
601001607 |
SCREW, 5/16-24X1.50 HHC Price: $3.99 |
| 306 |
601001490 |
PIPE PLUG Price: $1.99 |
| 310 |
601002324 |
OIL SEAL This part replaces 601001491. Price: $14.99 |
| 311 |
601001492 |
BEARING Price: $10.99 |
| 312 |
601001493 |
WASHER Price: $2.36 |
| 313 |
601001494 |
SHAFT NLA Price: $37.68 |
| 314 |
601001495 |
GASKET Price: $1.58 |
| 315 |
601001496 |
WORM GEAR Price: $107.76 |
| 316 |
601001497 |
WOODRUFF KEY Price: $2.98 |
| 320 |
601001498 |
RING Price: $2.62 |
| 321 |
601001499 |
FLANGE BEARING Price: $13.99 |
| 322 |
601001500 |
WASHER Price: $4.63 |
| 323 |
601001501 |
ROLLER BEARING Price: $5.27 |
| 324 |
601001500 |
WASHER Price: $4.63 |
| 326 |
601001502 |
HI-PRO KEY Price: $2.88 |
| 327 |
601001503 |
WORM GEAR Price: $65.42 |
| 330 |
601001504 |
BEARING Price: $4.12 |
