| Ref | Part Number | Description |
|---|
| 1 |
159944X428 |
Wheel Steering Price: Call Us |
| 2 |
165854 |
Axle Asm Stmp Dropped STLT Price: Call Us |
| 2 |
74-0720 |
TUBE-MANUAL Price: $22.99 |
| 3 |
169840 |
Spindle Asm LH Price: Call Us |
| 3 |
2412-133 |
CLAMP-R Price: $3.19 |
| 4 |
169839 |
Spindle Asm RH Price: Call Us |
| 4 |
32144-10 |
SCREW-HWH Price: $4.29 |
| 5 |
3-6657 |
CLIP-SKID Price: $22.64 |
| 5 |
6266H |
Bearing Race Thrust Harden Price: Call Us |
| 6 |
121748X |
Washer 25/32 X 1-5/8 X 16 Ga Price: Call Us |
| 6 |
86-7040 |
ROD-PROP, SEAT Price: $29.51 |
| 8 |
12000029 |
Ring Klip #t5304-75 Price: Call Us |
| 10 |
169832 |
Link Drag Price: Call Us |
| 11 |
10040600 |
Washer, Lock Hvy. Hlcl. Spr. 3/8 Price: Call Us |
| 13 |
163518 |
Spacer Brg. Axle Front Price: Call Us |
| 15 |
145212 |
Nut Hex Flange Lock Price: Call Us |
| 15 |
62-3010-01 |
BRACKET-RH This part replaces 62-3010. Price: $11.57 |
| 16 |
3234-17 |
SCREW-HHF Price: $0.72 |
| 17 |
156546 |
Shaft Asm Strg Price: Call Us |
| 17 |
62-3020-01 |
BRACKET-LH This part replaces 62-3020. Price: $12.72 |
| 18 |
57079 |
Washer Thrust 515x 750x 033 Price: Call Us |
| 18 |
70-1890-03 |
GUARD-FLYWHEEL This part replaces 70-1890. Price: $29.13 |
| 19 |
160395 |
Support Shaft Price: Call Us |
| 19 |
3234-6 |
SCREW-HHF Price: $3.19 |
| 20 |
67-8190-01 |
BRACKET-SUPPORT, ENGINE This part replaces 67-8190. Price: $50.66 |
| 21 |
3234-11 |
SCREW-HHF Price: $1.23 |
| 22 |
165857 |
Screw Hex Wsh Hd Torx Price: Call Us |
| 23 |
165851 |
Shaft Asm Pittman Price: Call Us |
| 25 |
154406 |
Bracket Steering Price: Call Us |
| 27 |
136874 |
Gear Sector Price: Call Us |
| 28 |
19131416 |
Washer 13/32 x 7/8 x 16 Ga. Price: Call Us |
| 29 |
17060612 |
Screw 3/8-16x.75 Price: Call Us |
| 32 |
130465 |
Rod Tie Price: Call Us |
| 33 |
19111216 |
Washer 11/32 x 3/4 x 16 Ga. Price: Call Us |
| 34 |
10040500 |
Washer Lock Hvy Hlcl Spr 5/16 Price: Call Us |
| 35 |
73540500 |
Crownlock Nut 5/16-24 Price: Call Us |
| 36 |
155099 |
Bushing Strg Price: Call Us |
| 37 |
152927 |
Screw Price: Call Us |
| 38 |
159946X428 |
Insert Cap Strg Wh Au Price: Call Us |
| 39 |
19132411 |
Washer 13/32 X 2-3/8 X 12 Ga Price: Call Us |
| 40 |
7810H |
Lock nut Price: Call Us |
| 41 |
159945 |
Adaptor Wheel Strg Price: Call Us |
| 42 |
145054X428 |
Boot Steering Dash Price: Call Us |
| 43 |
121749X |
Washer 25/32 X 1 1/4 X 16 Ga Price: Call Us |
| 44 |
153720 |
Extension Steering Shaft LR/LT Price: Call Us |
| 46 |
121232X |
Cap Spindle Fr Top Blk Price: Call Us |
| 47 |
6855M |
Fitting Grease Price: Call Us |
| 51 |
73800500 |
Nut Lock Hex w/Ins 5/16-18 Price: Call Us |
| 54 |
74780520 |
Bolt Fin Hex 5/16-18 Unc x 1-1/4 Price: Call Us |
| 62 |
167902 |
Kit, Steering Assembly Svc Price: Call Us |
| 63 |
74780616 |
Bolt Fin Hex 3/8-16unc x 1 Gr. 5 Price: Call Us |
| 65 |
160367 |
Brace Axle Price: Call Us |
| 66 |
154404 |
Bearing Arm Pittman Price: Call Us |
| 67 |
72140618 |
Bolt Rdhd Sq 3/8-16 Unc x 2-1/4 Price: Call Us |
| 68 |
169827 |
Axle, Brace Price: Call Us |
| 79 |
19132012 |
Washer 13/32 x 1-1/4 x 12 Ga. Price: Call Us |
| 80 |
74950612 |
Bolt Hex Nylon 3/8-16 x 3/4 Price: Call Us |
| 82 |
169835 |
Bracket Susp. Chassis Front Price: Call Us |
