| Ref | Part Number | Description |
|---|
| 1 |
233-35 |
KNOB Price: $8.06 |
| 1 |
427189 |
Reference Bar Price: Call Us |
| 2 |
04019-03 |
Nut, Serrated Flange 5/16-18 (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 2 |
120-2244 |
HOURMETER This part replaces 12-9990. Price: $48.06 |
| 3 |
3217-26 |
NUT-HEX Price: $0.25 |
| 3 |
483504 |
Bearing Price: Call Us |
| 4 |
04001-62 |
Capscrew, Hex Head 3/8-16 x 3.25" Price: Call Us |
| 4 |
3254-1 |
WASHER-LOCK, INT Price: $0.49 |
| 5 |
04001-01 |
BOLT, HEX HEAD, 1/4-20 X 3/4 GR.5 Price: Call Us |
| 5 |
38-1670 |
MTNG BRKT W/38-1660 This part replaces 26-4390. Price: $16.06 |
| 6 |
27-2360 |
SWITCH Price: $46.56 |
| 7 |
43600 |
Spacer, Bearing Price: Call Us |
| 7 |
62-7770 |
KEY-IGNITION This part replaces 218-412. Price: $4.39 |
| 8 |
48224 |
BEARINGS, BALL, NEUTRAL RETURN Price: Call Us |
| 8 |
83-0820 |
GAUGE - AMMETER This part replaces 38-1660. Price: $76.09 |
| 9 |
04019-04 |
NUT, 3/8-16 SERRATED FLANGE HEX HEAD Price: Call Us |
| 9 |
3254-9 |
WASHER-LOCK, INTERNAL Price: $0.25 |
| 10 |
04001-45 |
Capscrew, Hex Head 3/8-16 x 2.0" Price: Call Us |
| 10 |
3217-29 |
NUT-HEX Price: $0.25 |
| 11 |
26-6740 |
TEMP RESET RELAY Price: $165.84 |
| 11 |
431024 |
Spacer, Controls Price: Call Us |
| 12 |
04043-04 |
Flatwasher, 3/8 (.391 x .938 x .105 HD) Grade 8 Price: Call Us |
| 12 |
26-6750 |
ENG TEMP SWITCH GAGE Price: $332.79 |
| 13 |
04021-09 |
HEX NUT, ELASTIC STOP LOCK, 3/8-16 Price: Call Us |
| 13 |
322-3 |
SCREW-HH Price: $0.79 |
| 14 |
04001-10 |
Bolt, 5/16 - 18 x 1 - 1/4" Hex Head Price: Call Us |
| 14 |
3290-378 |
TIE-CABLE Price: $0.79 |
| 15 |
04021-10 |
HEX NUT, ELASTIC STOP LOCK, 5/16-18 Price: Call Us |
| 15 |
3254-2 |
WASHER-LOCK, INTERNAL Price: $0.27 |
| 16 |
3217-6 |
NUT-HEX Price: $1.19 |
| 16 |
485842 |
Linkage Assy., Steering Price: Call Us |
| 17 |
04108-02 |
Hex Head Socket, 5/16-18 x 1" (36) Price: Call Us |
| 18 |
28-1590 |
THROTTLE CONTROL Price: $35.36 |
| 18 |
43976 |
Spacer (excludes SVRII-36A) Price: Call Us |
| 19 |
3290-134 |
SCREW Price: $0.27 |
| 19 |
452842 |
Brake Paddle Weldment, RH Price: Call Us |
| 20 |
04003-23 |
Carriage Bolt, 3/8-16 x 1.0" Price: Call Us |
| 20 |
3290-360 |
SCREW-HH Price: $4.34 |
| 21 |
22-7810 |
SPACER Price: $16.90 |
| 21 |
452829 |
Bellcrank Weldment, Brake Price: Call Us |
| 22 |
119-2865 |
KIT-GM300 BUZZER, LOW OIL PRESSURE This part replaces 22-7820. Price: $135.43 |
| 22 |
452841 |
BRAKE PADDLE WLMT, LH Price: Call Us |
| 23 |
04001-32 |
Bolt, Hex Head 3/8-16 x 1-1/4", Kawasaki FX / FT & FT-EFI Price: Call Us |
| 23 |
32128-17 |
NUT-LOCK, FLANGE Price: $0.25 |
| 24 |
04117-02 |
Nut, Flange Elastic Stop Nut, 3/8-16 Price: Call Us |
| 24 |
44-2220 |
LEAD WIRE ASM Price: $9.24 |
| 25 |
28-1600 |
CHOKE CONTROL Price: $42.26 |
| 25 |
48100-30 |
BUSHING, BRONZE - .376 ID X .627 OD Price: Call Us |
| 26 |
04117-03 |
Nut, Flanged Elastic Stop 1/4-20 Price: Call Us |
| 26 |
70-2030 |
INST PANEL DECAL This part replaces 40-4400. Price: $18.52 |
| 27 |
04001-08 |
BOLT, SERRATED FLANGE HEX HEAD 5/16-18 X 3/4" Price: Call Us |
| 27 |
218-516 |
LENS Price: $11.36 |
| 28 |
28-1580 |
INST PANEL Price: $130.00 |
| 28 |
427547 |
Link, Brake Engage Price: Call Us |
| 30 |
481548 |
Grip, Parking Brake Price: Call Us |
| 31 |
04063-05 |
KEY, 3/16 X 3/16 X 1-1/2 Price: Call Us |
| 32 |
04012-15 |
Set Screw 1/4-20 x 1/4" Price: Call Us |
| 33 |
04040-03 |
Flatwasher, 1/4 (.281 x .625 x .065) Price: Call Us |
| 34 |
463392 |
LOCK WLMT, NEUTRAL W/ KEY This part replaces 453266. Price: Call Us |
| 35 |
04010-12 |
Screw, Hex-Slotted Washer Head #10 32 x 3/4" Price: Call Us |
| 36 |
04019-02 |
NUT, 1/4-20 SERRATED FLANGE HEX HEAD Price: Call Us |
| 37 |
427269 |
Bracket, Neutral Switch Price: Call Us |
| 38 |
481545 |
Switch, Interlock (see below) Price: Call Us |
| 39 |
422373 |
Plate, Threaded Price: Call Us |
| 40 |
04041-07 |
Flatwasher, 3/8" Special (.391 x .938 x .105) Price: Call Us |
| 41 |
04001-14 |
Capscrew, Hex Head 1/4-20 x 1" Price: Call Us |
| 42 |
04001-11 |
Bolt, Hex Head 5/16-18 x 1-1/2" (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 43 |
484038 |
Spring, Deck Lift Price: Call Us |
| 44 |
04040-04 |
Flatwasher, 5/16-.344 x .688 x .065 (48V / 52V) Price: Call Us |
| 45 |
04001-11 |
Bolt, Hex Head 5/16-18 x 1-1/2" (Right Front Engine Mounting, Briggs and Kohler Only) Price: Call Us |
| 481637 |
Switch, |
Interlock, Park Brake Normally Open Price: Call Us 481637 |
