| Ref | Part Number | Description |
|---|
| 1 |
285-17 |
PLUG-PIPE Price: $2.59 |
| 1 |
532447365 |
BAIL.CONT.D.STRAIGHT.PUSH.YELL Price: $7.99 |
| 2 |
237-22 |
O-RING Price: $2.43 |
| 2 |
532448263 |
HANDLE.UPPER.ECONOMY.BLACK Price: $22.99 |
| 3 |
25-2630 |
RING-BACK UP Price: $3.55 |
| 3 |
532434514 |
HANDLE.LOWER.D-STRAIT.BLACK Price: $22.99 |
| 4 |
532194788 |
GUIDE.ROPE.STD.BLK.ZIN Price: $3.99 |
| 4 |
88-8220 |
VALVE-BY PASS This part replaces 25-2620. Price: $189.03 |
| 5 |
48-1800 |
CYLINDER BLOCK KIT This part replaces 25-2600. Price: $1,923.22 |
| 5 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 532132004. Price: $1.99 |
| 6 |
25-2590 |
DISCONTINUED Price: Call Us |
| 6 |
532191574 |
BOLT, HANDLE 5/16-18X1.75 Price: $1.99 |
| 7 |
3257-32 |
KEY-WOODRUFF Price: $2.52 |
| 7 |
532007192 |
WIRE TIE This part replaces 532066426. Price: $3.99 |
| 8 |
25-3200 |
DISCONTINUED Price: Call Us |
| 8 |
539976934 |
HCS 5/16C X 3/4 This part replaces 874780512. Price: $1.99 |
| 9 |
252-82 |
BEARING-NEEDLE Price: $51.31 |
| 9 |
532154132 |
BRACKET.ASM.HOUSING.EZ.MUL Price: $4.99 |
| 10 |
25-3210 |
SEAL-LIP Price: $23.14 |
| 10 |
532165754 |
MULCH DOOR Price: $5.99 |
| 11 |
25-2510 |
WASHER-FLAT Price: $2.41 |
| 11 |
532440934 |
CABLE.MZR.RATO.22"LOW. Price: $11.99 |
| 12 |
25-2580 |
SHAFT-TRUNNION Price: $215.33 |
| 12 |
532178848 |
SCREW Price: $3.99 |
| 13 |
32151-46 |
RING-RETAINING Price: $8.38 |
| 13 |
532430034 |
BRACKET.UPSTOP.RT Price: $2.99 |
| 14 |
25-2700 |
DISCONTINUED Price: Call Us |
| 14 |
532185577 |
HANDLE.KNOB.BLACK This part replaces 532445019. Price: $1.99 |
| 15 |
237-86 |
O-RING Price: $5.47 |
| 15 |
532051793 |
HAIRPIN COTTER Price: $3.99 |
| 16 |
25-2470 |
PACK-SHIM Price: $47.36 |
| 17 |
25-2570 |
SPRING-VALVE Price: $12.67 |
| 18 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 18 |
83-7260 |
CONE-RELIEF, CHARGE This part replaces 25-2560. Price: $50.57 |
| 19 |
25-2690 |
DISCONTINUED Price: Call Us |
| 20 |
252-87 |
NEEDLE BRG Price: $29.99 |
| 21 |
253-44 |
SEAL-OIL Price: $24.63 |
| 21 |
532418655 |
KIT.SKIRT.21 DOMED.W/LIP Price: $11.99 |
| 22 |
322-4 |
SCREW-HH Price: $0.35 |
| 22 |
532401621 |
SPRING.SELECTOR.5POS.BZP This part replaces 532406428. Price: $3.99 |
| 23 |
25-2680 |
GEROTOR ASM Price: $651.02 |
| 23 |
532401814 |
DOOR.REAR.21.DOMED This part replaces 532410603. Price: $11.99 |
| 24 |
25-2530 |
PIN-STRAIGHT, HEADLESS Price: $21.24 |
| 25 |
237-95 |
O-RING Price: $11.97 |
| 26 |
25-3190 |
DISCONTINUED-SEE PB#945 This part replaces 25-3220. Price: Call Us |
| 27 |
25-2460 |
PLUG-HH Price: $37.38 |
| 28 |
25-2480 |
SPRING-VALVE Price: $4.93 |
| 28 |
532414441 |
BRACKET.ADJ.5.RTAB.LG.HOLE.ABS Price: $2.99 |
| 29 |
25-2490 |
BALL Price: $14.47 |
| 29 |
532407500 |
BRACKET.ADJ. RH This part replaces 532414440. Price: $2.99 |
| 30 |
251-8 |
BEARING-BALL Price: $30.06 |
| 30 |
532401629 |
SPACER.HEIGHT.ADJUSTER Price: $2.99 |
| 31 |
25-2450 |
PLATE-SWASH, VARIABLE Price: $896.81 |
| 31 |
532165760 |
CLIP ON DISCHARGE GUARD Price: $5.99 |
| 32 |
32121-91 |
PIN-SPRING Price: $0.81 |
| 32 |
532441559 |
SPRING.SEL.22.ECON.HI-WHL.RATO Price: $4.99 |
| 33 |
25-2380 |
PLATE-THRUST Price: $32.89 |
| 33 |
532087877 |
Selector Knob (AYP part number) This part replaces 532170143. Price: $2.99 |
| 34 |
25-2390 |
PLATE-VALVE, MOTOR Price: $832.97 |
| 35 |
25-2430 |
PIN-DOWEL Price: $0.95 |
| 35 |
532426589 |
NUT.FLANGE.HEX.5/16X18.BLACK Price: $2.99 |
| 36 |
25-3300 |
BEARING-NEEDLE Price: $107.05 |
| 36 |
532401638 |
SHOULDER BOLT 5/16-18 Price: $2.99 |
| 37 |
25-2400 |
GASKET Price: $19.26 |
| 37 |
532430501 |
WHEEL.7X1.75.5SPK.BRK.BLACK Price: $11.99 |
| 38 |
237-30 |
O-RING Price: $2.50 |
| 39 |
25-2670 |
DISCONTINUED Price: Call Us |
| 39 |
532409149 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $2.99 |
| 40 |
323-11 |
SCREW-HH Price: $1.08 |
| 40 |
532411949 |
FRAME.BAG.21.REAR.DOMED.PUSH Price: $27.99 |
| 41 |
25-2640 |
SPRING-VALVE Price: $4.22 |
| 41 |
532194186 |
SCREW.1/4-20X21/4.HEX. Price: $2.99 |
| 42 |
25-2650 |
PLUG-VALVE, CHECK Price: $89.01 |
| 44 |
532184193 |
BOLT Price: $3.99 |
| 45 |
532150406 |
BOLT 3/8-16X1-1/8 Price: $3.99 |
| 46 |
581579101 |
DECAL.CUTFINGER.CE.02 This part replaces 532404763. Price: $4.99 |
| 47 |
532751153 |
NUT.LOCK.5/16-18 Price: $1.99 |
| 49 |
532430500 |
RP.WHEEL.12X1.75.5SPK.BRK.BLK. Price: $27.99 |
| 50 |
532410666 |
GBAG.22510010.BLK.GEN This part replaces 532411060. Price: $49.99 |
| 51 |
532147286 |
ROD.HINGE.COMBI-C Price: $4.99 |
| 53 |
532851084 |
SCREW, HEX HD 3/8-24 X 1-3/8 Price: $2.99 |
| 54 |
539990118 |
SLW 3/8 STD This part replaces 532850263. Price: $1.99 |
| 55 |
532851074 |
WASHER,HARDEN Price: $2.99 |
| 56 |
532406712 |
BLADE.21.PUSH/RWGD/FWGD Price: $12.99 |
| 57 |
532418373 |
ADAPTER.BLADE.W/KEY.25MM.CE Price: $7.99 |
| 58 |
532152124 |
TORSION SPRING Price: $3.99 |
| 61 |
532409148 |
NUT.HEX.FLANGE.3/8-16.LOCKNUT Price: $2.99 |
| 62 |
539976978 |
NUT 1/4-20 NYLOC This part replaces 873800400. Price: $1.99 |
| 65 |
532088348 |
WASHER PM Price: $3.99 |
| 66 |
532197480 |
O-RING..070X.487.NEOPRENE Price: $3.99 |
| 67 |
532197991 |
CLIP.CABLE.BLK Price: $3.99 |
| 73 |
532401630 |
WASHER.CURVED.CYLINDRICAL Price: $2.99 |
| 74 |
532125078 |
WASHER.ENGINE.BZP Price: $3.99 |
| 76 |
532410589 |
BAFFLE.REAR.PLASTIC.21.RD.ECON Price: $8.99 |
| 77 |
817411312 |
SCREW.HX.13X.750 Price: $3.99 |
| 83 |
532428501 |
BAFFLE.FRONT.21.DOME.US Price: $9.99 |
| 84 |
817000510 |
BOLT.5/16HEX.WHS.HD Price: $3.99 |
