| Ref | Part Number | Description |
|---|
| 1 |
140064 |
SPRING CLUTCH MWR Price: Call Us |
| 1 |
647-04095A-0637 |
DECK LIFT SHAFT ASSEMBLY (POWDER BLACK) Not Available This part replaces 647-04095A. Price: |
| 2 |
122052X |
SPACER RETAINER Price: Call Us |
| 2 |
710-04187A |
Screw, TT, 1/4-15 x .500 This part replaces 710-04187. Price: $5.99 |
| 3 |
710-04484 |
SCREW 5/16-18 x .750 Price: $3.19 |
| 3 |
73680600 |
SUB= 73690600 Price: Call Us |
| 4 |
130840 |
BRAKE ASM Price: Call Us |
| 4 |
710-0451 |
Screw, Carriage, 5/16-18 x 75 Price: $3.53 |
| 5 |
131251 |
IDLER BELT GUIDE Price: Call Us |
| 5 |
710-0599 |
Screw, Hex Wash Hd. Tapp, 1/4-20 x .5 Price: $3.86 |
| 6 |
121316X |
PULLEY IDLER Price: Call Us |
| 6 |
710-0726 |
Screw, Hex Wash Hd. Tapp, 5/16-12 x .75 Price: $3.82 |
| 7 |
710-0895 |
Screw, Hex Wash Hd. Tapp, 1/4-15 x .75 Price: $5.82 |
| 7 |
72110616 |
BOLT Price: Call Us |
| 8 |
19131410 |
WASHER Price: Call Us |
| 8 |
712-04063 |
Nut, Hex Flange Insert Lock, 5/16-18 GrF Price: $3.56 |
| 9 |
127744 |
SUB= 140092 Price: Call Us |
| 9 |
712-04065 |
Nut, Hex Flange Insert Lock, 3/8-16 GrF Price: $3.68 |
| 10 |
714-0104 |
Pin, Internal Cotter Price: $3.90 |
| 10 |
72140610 |
BOLT.3/8-14X1.25 Price: Call Us |
| 11 |
130841 |
BRAKE ROD Price: Call Us |
| 11 |
714-0111 |
Pin, Cotter, 3/32 x 1.0 Price: $4.20 |
| 12 |
716-0106A |
E-ring, .625 Shaft Price: $4.42 |
| 13 |
720-0311 |
Grip, Handle Price: $13.26 |
| 13 |
72140506 |
BOLT Price: Call Us |
| 14 |
726-0135 |
Nut, Speed, .3125 Dia. Price: $5.94 |
| 14 |
73680500 |
SUB= 73690500 Price: Call Us |
| 15 |
726-0221 |
Nut, Speed, .5 Price: $5.34 |
| 16 |
726-3046 |
Clip, Ratchet Price: $3.71 |
| 17 |
128508 |
MOWER LINK STAB Price: Call Us |
| 17 |
731-05477 |
Cover, Rear Fender RH Not Available Price: |
| 18 |
731-05518 |
FENDER COVER (RH) Not Available Price: |
| 19 |
731-06208 |
SEAT ADJUST SPACER Not Available Price: |
| 20 |
732-04459 |
HANDLE LIFT TORSION SPRING Not Available Price: |
| 21 |
140296 |
WASHER.HARD.BLADE Price: Call Us |
| 21 |
732-04491 |
SEAT ADJUSTER Not Available Price: |
| 22 |
10030600 |
SUB= 10040600 Price: Call Us |
| 22 |
732-04508 |
Spring, Compression, 1.71 x 3.25 x .23 Price: $6.73 |
| 23 |
732-0826A |
Spring, Extension, .865 x 4.68 Price: $10.12 |
| 23 |
850857 |
BLADE BOLT Price: Call Us |
| 24 |
140329 |
STRIPPER RND MWR Price: Call Us |
| 24 |
735-04078A |
FOOT PAD (RH) Not Available Price: |
| 25 |
138776 |
SUB= 157722 Price: Call Us |
| 25 |
735-04109 |
FOOT PAD (LH) Not Available Price: |
| 26 |
736-0192 |
Washer, Flat, .535 x .93 x .09 Price: $3.75 |
| 27 |
129983 |
SUB= 156600 Price: Call Us |
| 27 |
736-3078 |
Washer, Flat, .344 x 1.0 x .063 HT Price: $3.95 |
| 28 |
1535317 |
PULLEY, MANDREL Price: Call Us |
| 28 |
738-0138A |
Bolt, Shoulder, .496 x 2.5:3/8-16 Price: $5.81 |
| 29 |
137266 |
SUB= 139729 Price: Call Us |
| 29 |
938-0373 |
Shoulder Screw This part replaces 738-0373. Price: $8.45 |
| 30 |
136631 |
SUB= 532136631 Price: Call Us |
| 30 |
738-0380 |
Bolt, Shoulder, .5 x .27:3/8-16 Price: $7.34 |
| 31 |
17490508 |
SCREW LT Price: Call Us |
| 31 |
941-0225 |
Bearing, Hex Flange This part replaces 741-0225. Price: $6.55 |
| 32 |
746-04369 |
LIFT CABLE 16.16" Not Available Price: |
| 33 |
139083 |
SHIELD.DEFL.36TUV Price: Call Us |
| 33 |
746-0968 |
Cable, Lift, 16.16 Lg Price: $18.10 |
| 34 |
747-04701 |
LIFT HANDLE Not Available Price: |
| 35 |
747-04821 |
SEAT ROD 5/16 x 11.62 Not Available Price: |
| 36 |
121980X |
HINGE ROD Price: Call Us |
| 36 |
750-04945 |
Spacer, .51 x .75 x 1.0 Price: $6.01 |
| 37 |
123713X |
SPRING TORSION Price: Call Us |
| 37 |
756-1154 |
Pulley, Roller Price: $6.63 |
| 38 |
105304X |
CAP-SLEEVE LT Price: Call Us |
| 38 |
757-04030A |
HIGH BACK SEAT (CUB) Not Available Price: |
| 39 |
19111016 |
WASHER Price: Call Us |
| 39 |
783-04977A-0637 |
DECK LIFT PLATE Not Available This part replaces 783-04977A. Price: |
| 40 |
110452X |
NUT PUSH M Price: Call Us |
| 40 |
783-05546A-0637 |
Link, Lift This part replaces 783-05546. Price: $17.96 |
| 41 |
131264 |
V-BELT.PRIM.78.5. Price: Call Us |
| 41 |
783-05816-0637 |
SEAT PIVOT BRACKET Not Available This part replaces 783-05816. Price: |
| 42 |
19171616 |
WASHER Price: Call Us |
| 42 |
783-05817-0637 |
SEAT PLATE Not Available This part replaces 783-05817. Price: |
| 43 |
3146R |
RETAINER.SPRING Price: Call Us |
| 43 |
783-05865A-0637 |
FENDER (POWDER BLACK) Not Available This part replaces 783-05865. Price: |
| 44 |
140608 |
KEEPER BELT LH Price: Call Us |
| 44 |
925-04040 |
Seat Switch This part replaces 725-04040. Price: $33.59 |
| 45 |
110485X |
BEARING Price: Call Us |
| 46 |
128774 |
HSG ASM MANDREL Price: Call Us |
| 47 |
129895 |
BEARING.BALL Price: Call Us |
| 48 |
137645 |
SUB= 137646 Price: Call Us |
| 49 |
133943 |
HARDENED WASHER Price: Call Us |
| 50 |
71161010 |
SCREW Price: Call Us |
| 51 |
136383 |
GUARD.DFTR.MWR.36 Price: Call Us |
| 52 |
19070718 |
NLA Price: Call Us |
| 53 |
60867 |
ACORN NUT RB Price: Call Us |
| 130794 |
MANDREL |
ASM Price: Call Us 130794 |
