| Ref | Part Number | Description |
|---|
| 1 |
131-0285-03 |
STIFFENER-CHANNEL Price: $64.47 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
117-0701 |
HYDRAULIC CYLINDER ASM Price: $984.97 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 4 |
131-0275-03 |
PLATE-MOUNT Price: $135.25 |
| 5 |
112-7884 |
PIN-PIVOT Price: $20.16 |
| 6 |
110-5053 |
SCREW-HHF Price: $0.88 |
| 7 |
3234-29 |
SCREW-HHF Price: $1.84 |
| 8 |
130-8201-03 |
MOUNT-VALVE Price: $42.89 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
136-2400 |
ON-OFF BOOM LIFT VALVE ASM This part replaces 117-0702. Price: $1,383.95 |
| 10 |
340-2 |
FITTING-STRAIGHT Price: $11.43 |
| 11 |
59-7410 |
FITTING-DIAGNOSTIC Price: $36.39 |
| 12 |
354-79 |
CAP-DUST Price: $7.81 |
| 13 |
322-14 |
SCREW-HH Price: $1.01 |
| 14 |
110-5067 |
SCREW-CARR Price: $2.17 |
| 15 |
99-5107 |
NUT-LOCK Price: $1.77 |
| 16 |
131-0276 |
HOSE ASM Price: $67.56 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 24 |
532004799 |
BATTERY CABLE This part replaces 532124780. Price: $8.99 |
| 25 |
532146148 |
CABLE BATTERY 6 GA 22" W/16W Price: $11.99 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
532192749 |
SWITCH.SEAT.DP W/RAMPS Price: $17.99 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 40 |
532193376 |
HARNESS.IGN.ELECT.STL Price: $104.99 |
| 41 |
596437001 |
Screws This part replaces 871110408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
532146154 |
KIT SOLENOID .95 This part replaces 532178861. Price: $19.99 |
| 45 |
532122822 |
AMMETER Price: $17.99 |
| 46 |
532169642 |
KIT.HOURMETER.SNAP-IN This part replaces 532169635. Price: $109.99 |
| 50 |
582107601 |
SWITCH.PTO.8TERMINAL.STD.BLK This part replaces 532174651. Price: $24.99 |
| 55 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 89 |
532169639 |
BRACKET SNAP-IN HOURMETER Price: $4.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $4.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 92 |
532193465 |
HARNESS.PIGTAIL.REVERSE.SWITCH Price: $7.99 |
| 93 |
596039601 |
Bolts This part replaces 532192540. Price: $1.99 |
| 94 |
532191834 |
MODULE.REVERSE.ROS Price: $19.99 |
