| Ref | Part Number | Description |
|---|
| 1 |
596135701 |
GSPW Nuts This part replaces 873900500. Price: $2.99 |
| 1 |
98-7707 |
PULLEY-ALTERNATOR Price: $64.31 |
| 2 |
98-7708 |
NUT Price: $7.76 |
| 3 |
532008393 |
STAKE PIN TI Price: $19.99 |
| 3 |
98-7709 |
COLLAR Price: $8.79 |
| 4 |
107-0136 |
ROTOR ASM This part replaces 98-7710. Price: $268.62 |
| 4 |
812000035 |
RING, KLIP Price: $3.99 |
| 5 |
595901601 |
GSPW Bolts This part replaces 532180847. Price: $2.99 |
| 5 |
98-7711 |
COVER-BEARING Price: $7.32 |
| 6 |
532008394 |
SPRING TI Price: $7.99 |
| 6 |
98-7712 |
BEARING-BALL Price: $31.09 |
| 7 |
532008392 |
BRACKET.LATCH.STAKE.3.20.BLACK Price: $4.99 |
| 7 |
98-7713 |
WASHER-THRUST Price: $4.49 |
| 8 |
532109230 |
SPRING CRT Price: $4.99 |
| 8 |
98-7714 |
FRAME-END, DRIVE Price: $311.88 |
| 9 |
532446449 |
SHIELD.TILLER.TINE.CRT14.ORNG This part replaces 532138863. Price: $49.99 |
| 9 |
98-7715 |
PLATE-RETAINER Price: $9.38 |
| 10 |
98-7716 |
SCREW-HEAD, ROUND Price: $0.91 |
| 11 |
98-7717 |
BOLT-THROUGH Price: $9.75 |
| 12 |
98-7718 |
BEARING-BALL Price: $34.82 |
| 13 |
872110510 |
BOLT.CARRIAGE.5/16-18 Price: $4.99 |
| 13 |
98-7719 |
FRAME-END Price: $88.65 |
| 14 |
584459301 |
BRACKET.TINE.SHIELD.BLACK This part replaces 532124343. Price: $32.99 |
| 14 |
98-7720 |
COVER-END Price: $39.58 |
| 15 |
98-7721 |
RECTIFIER ASM Price: $486.45 |
| 16 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873900400. Price: $3.99 |
| 16 |
98-7722 |
BUSHING-INSULATION Price: $28.44 |
| 17 |
98-7723 |
HOLDER-BRUSH Price: $52.72 |
| 18 |
872040410 |
BOLT Price: $3.99 |
| 18 |
98-7724 |
BRUSH Price: $12.41 |
| 19 |
532102701 |
GRIP CRT Price: $9.99 |
| 19 |
98-7725 |
SPRING-BRUSH Price: $4.32 |
| 20 |
873220600 |
NUT.HEX.3/8-16UNC Price: $4.99 |
| 20 |
98-7726 |
SCREW-HEAD, ROUND Price: $0.42 |
| 21 |
531154801 |
SERVICE KIT STAKE STAKE.DEPTH. This part replaces 532102156. Price: $8.99 |
| 21 |
98-7727 |
SCREW-HEAD, ROUND Price: $0.94 |
| 22 |
874930632 |
BOLT.375-16 Price: $5.99 |
| 22 |
98-7728 |
SCREW-HEAD, ROUND Price: $0.70 |
| 23 |
532004440 |
HINGE CRT Price: $3.99 |
| 23 |
98-7729 |
BOLT Price: $2.35 |
| 24 |
596133401 |
Bolts This part replaces 872140404. Price: $1.99 |
| 24 |
98-7730 |
NUT Price: $1.31 |
| 25 |
532006712 |
VINYL CAP This part replaces 532124717. Price: $3.99 |
| 25 |
98-7731 |
BOLT Price: $3.94 |
| 26 |
532109227 |
PAD IDLER TI Price: $3.99 |
| 26 |
98-7732 |
NUT Price: $1.45 |
| 27 |
532446452 |
SHIELD.PNT.LEVEL.CRT.14.ORANGE This part replaces 532125451. Price: $19.99 |
| 28 |
532120588 |
PIN.HINGE.TILLER Price: $6.99 |
| 29 |
585414301 |
KIT.TILLER.SIDE.SHIELD.BLACK This part replaces 532403960. Price: $37.99 |
| 30 |
596040501 |
Hardware This part replaces 873970500. Price: $2.99 |
| 32 |
532050675 |
NUT.HEX..25-20.UNC This part replaces 873220400. Price: $2.99 |
| 33 |
596029801 |
WASHER SPRING LOCK WASHER WITH This part replaces 810040400. Price: $2.99 |
