| Ref | Part Number | Description |
|---|
| 1 |
532184233 |
DECK.SVC.4.GA.WHLS.48".BLK This part replaces 532174348. Price: $349.99 |
| 2 |
353-481 |
LIFT CHECK ASM Price: $338.44 |
| 3 |
237-54 |
O-RING Price: $1.97 |
| 3 |
531165401 |
SERVICE.KIT BRACKET BRKT ASM S This part replaces 532138017. Price: $12.99 |
| 4 |
353-306 |
WASHER-BACKUP Price: $9.12 |
| 5 |
353-305 |
O-RING Price: $10.91 |
| 5 |
532124670 |
RETAINER-SPRNG RB Price: $5.99 |
| 6 |
531149301 |
SERVICE KIT BAR BAR SWAY DECK. This part replaces 532130832. Price: $9.99 |
| 7 |
353-302 |
O-RING Price: $10.13 |
| 8 |
353-303 |
WASHER-BACKUP Price: $9.06 |
| 8 |
532193003 |
BOLT.WASHER.ASM.7/16-2 This part replaces 532174365. Price: $6.99 |
| 10 |
353-853 |
BOLT Price: $39.87 |
| 11 |
353-668 |
PLATE-COVER Price: $508.66 |
| 13 |
353-550 |
PLUG-HYD, HH Price: $10.71 |
| 13 |
532174360 |
SHAFT ASM W/LOWER BEARING Price: $39.99 |
| 14 |
353-848 |
O-RING Price: $0.89 |
| 14 |
532174358 |
HOUSING, MANDREL 48" Price: $49.99 |
| 15 |
353-957 |
CUP-SEAL Price: $16.26 |
| 15 |
532110485 |
BEARING Price: $11.99 |
| 16 |
353-958 |
WASHER Price: $13.57 |
| 16 |
531167701 |
SERVICE KIT MANDREL STRIPPER This part replaces 532174493. Price: $6.99 |
| 17 |
596987501 |
Bolts This part replaces 872110610. Price: $3.99 |
| 18 |
353-959 |
PLATE-RETAINER, SEAL Price: $7.40 |
| 18 |
596136401 |
Bolts This part replaces 872140505. Price: $2.99 |
| 19 |
353-733 |
SPACER-BONNET Price: $41.01 |
| 19 |
532132827 |
BOLT SHD 5/16-18 Price: $4.99 |
| 20 |
353-417 |
COLLAR-STOP Price: $10.31 |
| 20 |
531167501 |
SERVICE KIT BAFFLE BAFFLE This part replaces 532174378. Price: $12.99 |
| 21 |
353-831 |
SPRING Price: $13.22 |
| 21 |
596040501 |
Hardware This part replaces 873680500. Price: $2.99 |
| 22 |
353-529 |
PLATE-RETAINER, SEAL Price: $15.07 |
| 23 |
353-530 |
DISCONTINUED Price: Call Us |
| 24 |
353-808 |
COLLAR-SPRING Price: $27.44 |
| 24 |
532105304 |
CAP-SLEEVE LT Price: $3.99 |
| 25 |
353-830 |
O-RING Price: $1.41 |
| 25 |
539107609 |
TORSION SPRING This part replaces 532178102. Price: $4.99 |
| 26 |
532110452 |
NUT PUSH M Price: $2.99 |
| 26 |
94-4248 |
COLLAR-SPOOL This part replaces 353-829. Price: $58.22 |
| 27 |
532180655 |
DEFLECTOR.ASM.BLACK.48" This part replaces 532174346. Price: $39.99 |
| 27 |
68-4240 |
BONNET ASSEMBLY This part replaces 354-26. Price: $42.76 |
| 28 |
354-28 |
SCREW-HS Price: $8.35 |
| 28 |
819111016 |
Washer 11/32 x 5/8 x 16 Ga. Price: $5.99 |
| 29 |
353-851 |
BODY-RELIEF Price: $180.95 |
| 29 |
595297001 |
Rods This part replaces 532131491. Price: $4.99 |
| 30 |
353-392 |
RING-PISTON Price: $13.94 |
| 30 |
584953901 |
BOLT.HEX.WASHR.HED.313-18X1.19 This part replaces 532157722. Price: $3.99 |
| 31 |
353-531 |
POPPET AND RING ASM Price: $229.51 |
| 31 |
532187690 |
WASHER.SPACER.MANDREL This part replaces 532129963. Price: $3.99 |
| 32 |
353-328 |
SHIM (.040) Price: $3.53 |
| 32 |
532173436 |
PULLEY MANDREL This part replaces 532177865. Price: $14.99 |
| 33 |
353-329 |
SHIM (.020) Price: $2.10 |
| 33 |
596134801 |
Nuts This part replaces 532178342. Price: $1.00 |
| 34 |
353-330 |
SHIM (.010) Price: $3.60 |
| 35 |
353-398 |
SPRING Price: $30.09 |
| 36 |
353-334 |
CAP-RELIEF Price: $55.48 |
| 36 |
596565301 |
WASHER PLAIN WASHER 3/8 X 0.08 This part replaces 819131316. Price: $2.99 |
| 37 |
52-5900 |
SCREW Price: $26.40 |
| 37 |
532173437 |
PULLEY.IDLER.FLAT.PLATED Price: $24.99 |
| 38 |
353-847 |
BONNET Price: $129.59 |
| 39 |
353-849 |
SLEEVE Price: $46.19 |
| 39 |
532174375 |
PULLEY.DRIVEN.DECK.48' Price: $34.99 |
| 40 |
353-846 |
SPUD Price: $118.09 |
| 41 |
353-845 |
SLEEVE-DETENT Price: $79.50 |
| 42 |
353-730 |
SPRING Price: $18.22 |
| 42 |
532165723 |
SPACER.RETAINER.MOWER This part replaces 532122052. Price: $5.99 |
| 43 |
353-731 |
BALL Price: $12.95 |
| 43 |
532174373 |
ARM, IDLER SECONDARY Price: $9.99 |
| 44 |
353-398 |
SPRING This part replaces 353-855. Price: $30.09 |
| 45 |
3274-52 |
SCREW-HSH Price: $3.19 |
| 45 |
532180806 |
COVER.MANDREL.DECK.48" This part replaces 532174343. Price: $12.99 |
| 46 |
353-575 |
BOOT Price: $58.68 |
| 46 |
532137729 |
SCREW.1/4-20X5/8 Price: $3.99 |
| 47 |
532180808 |
V-BELT, 48"SECONDARY This part replaces 532174369. Price: $49.99 |
| 47 |
93-3651 |
RETAINER-BOOT This part replaces 353-559. Price: $31.38 |
| 48 |
532174368 |
V-BELT PRIMARY 48" Price: $49.99 |
| 48 |
93-3651 |
RETAINER-BOOT This part replaces 353-560. Price: $31.38 |
| 49 |
596322601 |
Nuts This part replaces 873680600. Price: $2.99 |
| 50 |
596136101 |
GSPW Bolts This part replaces 872110612. Price: $2.99 |
| 51 |
52-5860 |
COLLAR-SPOOL Price: $13.37 |
| 52 |
353-765 |
DISCONTINUED Price: Call Us |
| 52 |
596481401 |
Pulleys This part replaces 532175820. Price: $22.99 |
| 53 |
354-122 |
DISC-SEAL Price: $6.92 |
| 54 |
353-953 |
PLUG ASM Price: $182.79 |
| 55 |
353-844 |
PLUG Price: $75.53 |
| 56 |
353-850 |
O-RING Price: $1.17 |
| 56 |
532155986 |
BAR.ADJUST.WHEEL.ANTI.SCALP.BL This part replaces 532162648. Price: $17.99 |
| 57 |
3253-3 |
WASHER-LOCK Price: $0.31 |
| 57 |
532156941 |
RIVET.PIN.HEAD.YELLOW. Price: $4.99 |
| 58 |
3274-84 |
SCREW-HSH Price: $2.51 |
| 59 |
38-0410 |
NUT-HEX Price: $5.77 |
| 60 |
83-1890 |
SWITCH-BALL Price: $63.08 |
| 90 |
596580801 |
Bolts This part replaces 874760516. Price: $2.99 |
| 91 |
532175384 |
BRKT ASM NOSEROLLER(L)48" Price: $6.99 |
| 93 |
819171416 |
Washer 17/32 x 7/8 x 16 Price: $3.99 |
| 94 |
532176066 |
NOSE ROLLER 48" Price: $11.99 |
| 95 |
532175996 |
BRKT, ASM NOSEROLLER(R)48 Price: $6.99 |
| 97 |
532178515 |
WASHER This part replaces 532133943. Price: $5.99 |
| 98 |
532179479 |
SPRING PRIMARY DRIVE This part replaces 532174370. Price: $3.99 |
| 99 |
532193195 |
PULLEY.V.IDLER This part replaces 532175080. Price: $49.99 |
| 100 |
596136301 |
Bolts This part replaces 872110616. Price: $2.99 |
| 107 |
532175294 |
BAFFLE.VAC.EDGE.MOWER.48" Price: $2.99 |
| 108 |
872110404 |
BOLT Price: $7.99 |
| 109 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873680400. Price: $3.99 |
| 110 |
532175016 |
ARM, SPRING SECONDARY Price: $4.99 |
| 112 |
532174387 |
LEVER, TENSION RELIEF LINK Price: $14.99 |
| 113 |
596435701 |
Bolts This part replaces 872110508. Price: $2.99 |
| 114 |
532174384 |
LEVER ASM, TENSION RELIEF Price: $8.99 |
| 115 |
532174609 |
ARM, SPRING TENSION RELIEF Price: $4.99 |
| 116 |
596434404 |
Bolts This part replaces 532137644. Price: $4.99 |
| 117 |
532133957 |
WHEEL GAGE DONUT Price: $11.99 |
| 118 |
596322601 |
Nuts This part replaces 873930600. Price: $2.99 |
| 119 |
596134901 |
GSPH This part replaces 819121414. Price: $2.99 |
| 121 |
532174371 |
SPRING.DRIVE.SECONDARY.48".DEC Price: $5.99 |
| 122 |
532174606 |
BUSHING, PIVOT TENSION RELIEF Price: $3.99 |
| 126 |
532174372 |
ARM, IDLER PRIMARY DECK Price: $9.99 |
| 130 |
817000616 |
SCREW 3/8-16X1 This part replaces 817060616. Price: $5.99 |
| 180 |
596040501 |
Hardware This part replaces 873800500. Price: $2.99 |
