| Ref | Part Number | Description |
|---|
| 1 |
48-3250 |
DISCONTINUED Price: Call Us |
| 1 |
532405161 |
COVER, POWER STEERING Price: $8.99 |
| 2 |
33115-030 |
SCREW-HH This part replaces 48-9470. Price: $0.68 |
| 2 |
594975601 |
Screws This part replaces 532184471. Price: $1.99 |
| 3 |
48-8070 |
WASHER-LOCK Price: $0.47 |
| 3 |
812000045 |
RING Price: $5.99 |
| 4 |
48-7830 |
SCREW Price: $3.38 |
| 4 |
581645001 |
DRIVER.WHEEL This part replaces 532192126. Price: $27.99 |
| 5 |
48-3380 |
SUPPORT LEG *B Price: $147.58 |
| 5 |
532182466 |
RING, WIRE RETAINER Price: $3.99 |
| 6 |
33115-025 |
SCREW-HH This part replaces 48-7780. Price: $0.61 |
| 6 |
532187622 |
LOBE WHEEL Price: $32.99 |
| 7 |
48-9590 |
WASHER-LOCK Price: $0.25 |
| 7 |
581644901 |
SLIDE.CLUTCH.SNOW This part replaces 532194941. Price: $34.99 |
| 8 |
532179139 |
SPRING, CLUTCH SLIDE Price: $4.99 |
| 8 |
58-0660 |
FOOT-FRT ENG W.A. *B Price: $194.69 |
| 9 |
48-7960 |
NUT Price: $1.40 |
| 9 |
532189282 |
KEY, SQUARE 1/4 X .875 Price: $4.99 |
| 10 |
48-7570 |
SCREW-HH Price: $8.48 |
| 10 |
581645101 |
LOBE.AXLE This part replaces 532194940. Price: $8.99 |
| 11 |
33114-025 |
SCREW-HH This part replaces 48-9460. Price: $0.70 |
| 11 |
532007396 |
WASHER RACE BEARING THRUST This part replaces 532174697. Price: $3.99 |
| 12 |
3253-4 |
WASHER-LOCK This part replaces 48-9570. Price: $0.25 |
| 12 |
532445266 |
YOKE.WELDMENT.STEER.BLACK This part replaces 532199519. Price: $17.99 |
| 13 |
532184197 |
BRACKET.STEER.PNT.BLACK Price: $4.99 |
| 13 |
68-9400 |
NUT-FLANGE This part replaces 48-7930. Price: $2.29 |
| 14 |
33114-025 |
SCREW-HH This part replaces 60-4540. Price: $0.70 |
| 14 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 15 |
532194943 |
BRACKET.STEER.PIVOT.RH This part replaces 532199511. Price: $3.99 |
| 15 |
58-3590 |
DOWEL Price: $5.50 |
| 16 |
532194944 |
BELLCRANK.STEER.YZP This part replaces 532199518. Price: $3.99 |
| 16 |
92-1753 |
COUPLING-SPRING This part replaces 48-6260. Price: $696.17 |
| 17 |
532181847 |
PIN, STEERING BELLCRANK Price: $4.99 |
| 17 |
69-9550 |
PUMP ADAPTER PLATE *B Price: $729.10 |
| 18 |
817600406 |
SCREW 1/4X20 Price: $2.99 |
| 19 |
3213-20 |
SCREW-HH Price: $1.76 |
| 19 |
532405077 |
LINK.STEER.YOKE Price: $7.99 |
| 20 |
3253-7 |
WASHER-LOCK Price: $0.27 |
| 20 |
532700279 |
RETAINER CLIP Price: $2.99 |
| 21 |
33116-030 |
SCREW-HH This part replaces 60-6870. Price: $1.56 |
| 21 |
532085179 |
RETAINER CLIP PM Price: $3.99 |
| 22 |
532193885 |
SPRING LATCH Price: $3.99 |
| 22 |
60-1010 |
ANGLE LUG *B Price: $56.45 |
| 23 |
48-9480 |
SCREW Price: $1.97 |
| 23 |
532182015 |
PIN, STEERING LEVER Price: $2.99 |
| 24 |
3255-8 |
WASHER-LOCK Price: $0.31 |
| 25 |
3255-9 |
WASHER-LOCK Price: $0.28 |
| 26 |
33095-00 |
WASHER-FLAT This part replaces 48-9580. Price: $0.25 |
| 27 |
58-5100 |
WASHER-TRACTION Price: $28.50 |
| 28 |
323-7 |
SCREW-HH Price: $0.65 |
| 29 |
323-6 |
SCREW-HH Price: $0.66 |
| 30 |
3253-5 |
WASHER-LOCK Price: $0.29 |
