| Ref | Part Number | Description |
|---|
| 1 |
104-3537 |
PIN-CYLINDER Price: $66.99 |
| 1 |
532123899 |
BATTERY.DRY.30.AMP This part replaces 532144927. Price: $149.99 |
| 2 |
32121-9 |
PIN-ROLL, SLOTTED Price: $2.56 |
| 2 |
874760412 |
BOLT.HEX.1/4.X.3/4.DICHROMATE Price: $3.99 |
| 3 |
3234-46 |
SCREW-HHF Price: $2.08 |
| 4 |
86-5350 |
BUMPER-RUBBER Price: $46.29 |
| 5 |
3269-11 |
RIVET-POP Price: $0.68 |
| 6 |
325-5 |
SCREW-HH Price: $1.20 |
| 7 |
106-2008 |
WASHER-THRUST Price: $5.16 |
| 8 |
121-3882 |
SHAFT-PIVOT, LIFT ARM Price: $265.49 |
| 8 |
532186491 |
BOX.BATTERY.MOUNT.FRONT.LT Price: $14.99 |
| 9 |
138-5253 |
PIVOT HUB ASM This part replaces 115-5468. Price: $73.95 |
| 10 |
256-304 |
WASHER-THRUST Price: $3.94 |
| 11 |
117-5479 |
PIN-SPRING Price: $1.45 |
| 12 |
120-8859-03 |
BLOCK-TAPPED Price: $41.09 |
| 13 |
3256-26 |
WASHER-FLAT Price: $0.39 |
| 14 |
100-6116 |
SCREW-HHF Price: $6.41 |
| 15 |
3296-47 |
NUT-LOCK, NI Price: $3.59 |
| 16 |
116-1399 |
LOCKNUT Price: $13.99 |
| 16 |
532176138 |
SWITCH INTERLOOK PUSH-IN Price: $19.99 |
| 17 |
104-0719 |
WASHER-HARDENED Price: $9.34 |
| 18 |
114-5641 |
WASHER-THRUST Price: $12.21 |
| 19 |
104-0721 |
WASHER-THRUST Price: $4.00 |
| 20 |
104-0720 |
SPACER Price: $35.75 |
| 21 |
114-5640-03 |
JOINT YOKE ASM Price: $448.74 |
| 21 |
532183759 |
HARNESS ASSY LIGHT Price: $24.99 |
| 22 |
145-8347 |
LIFT ARM ASM This part replaces 132-6210. Price: $736.74 |
| 22 |
532004152 |
LIGHTBULB Price: $3.99 |
| 23 |
132-6217 |
RH LIFT ARM ASM Price: $900.46 |
| 24 |
104-8300 |
NUT-HF, NI Price: $0.39 |
| 24 |
585555601 |
CABLE.FRBATT.W/WIRE.8GA.8 This part replaces 532400253. Price: $7.99 |
| 25 |
132-1429 |
SENSOR-TRIGGER Price: $27.80 |
| 25 |
532198893 |
CABLE.START.RED.17.5". Price: $11.99 |
| 26 |
3230-16 |
SCREW-CARR Price: $1.79 |
| 26 |
532175158 |
FUSE 20AMP Price: $4.99 |
| 27 |
27-0410 |
SCREW-SHOULDER Price: $2.59 |
| 27 |
586668901 |
NUT HEX_LRG FLG_1_4-20_LOCK This part replaces 873510400. Price: $3.99 |
| 28 |
131-4305 |
PIN Price: $24.18 |
| 28 |
532145491 |
CABLE GROUND 6 GA 21" 90T BLK Price: $6.99 |
| 29 |
139-0956 |
HYD CYLINDER ASM This part replaces 107-4303. Price: $1,027.18 |
| 29 |
532401545 |
SWITCH.SEAT.DELTA.OPC. Price: $34.99 |
| 30 |
115-5300 |
PROXIMITY SWITCH ASM Price: $137.95 |
| 30 |
532193350 |
SWITCH.IGN.DELTA.W.LGH.ROS Price: $19.99 |
| 31 |
120-9000-03 |
CROSSMEMBER Price: $249.32 |
| 32 |
3296-45 |
NUT-HEX Price: $3.79 |
| 33 |
104-3577 |
WASHER Price: $0.76 |
| 33 |
532140401 |
KEY MLD GEN DELTA Price: $5.99 |
| 34 |
136-4395-03 |
LATCH-DECK, LH Price: $29.96 |
| 34 |
532110712 |
SWITCH LT Price: $7.99 |
| 35 |
136-4394-03 |
LATCH-DECK, RH Price: $29.96 |
| 36 |
48-7081 |
GRIP-PLASTIC Price: $7.54 |
| 37 |
340-82 |
FITTING-ELBOW, 90 DEG Price: $20.57 |
| 38 |
340-77 |
FITTING-ELBOW, 90 DEG Price: $24.95 |
| 39 |
132-1421 |
PLATE-PIVOT, LH Price: $9.15 |
| 40 |
132-1422 |
PLATE-PIVOT, RH Price: $9.15 |
| 40 |
532194276 |
HARNESS-CHASSIS SUB Price: $27.99 |
| 41 |
596437001 |
Screws This part replaces 817720408. Price: $2.99 |
| 42 |
532154336 |
COVER.TERMINAL.RED This part replaces 532131563. Price: $4.99 |
| 43 |
582042802 |
Solenoids This part replaces 532192507. Price: $22.99 |
| 46 |
594919101 |
GUAGE.SRVCMNDR.HRMTR. This part replaces 532198138. Price: $19.99 |
| 55 |
596030701 |
Screws This part replaces 817490508. Price: $2.99 |
| 71 |
532401104 |
HARNESS.IGN.DASH.HUQ/P Price: $59.99 |
| 90 |
532435395 |
COVER.TERMINAL.BATTERY This part replaces 532180449. Price: $4.99 |
| 91 |
532190270 |
STRAP.BATTERY.MOUNT.FRONT(2 2) Price: $7.99 |
| 99 |
817670412 |
SCREW HEXWSHR 1/4-20X3/4 Price: $3.99 |
| 100 |
596135301 |
Washers This part replaces 819091416. Price: $2.99 |
