| Ref | Part Number | Description |
|---|
| 1 |
98000129 |
NUT Price: Call Us |
| 2 |
104086X520 |
SHIELD.SD.OUT.LH Price: Call Us |
| 2 |
92-9725-03 |
LH SPINDLE ASM Price: $553.13 |
| 3 |
8393J |
STAKE PIN TI Price: Call Us |
| 3 |
92-9724-03 |
RH SPINDLE ASM Price: $644.87 |
| 4 |
12000036 |
KLIP RING TI Price: Call Us |
| 4 |
3220-7 |
NUT-JAM Price: $4.09 |
| 5 |
3272-13 |
PIN-COTTER Price: $0.25 |
| 5 |
72110508 |
BOLT CRT Price: Call Us |
| 6 |
139-2564 |
NUT-LUG This part replaces 242-50. Price: $0.99 |
| 6 |
8394J |
SPRING TI Price: Call Us |
| 7 |
254-106 |
CONE-BEARING, TAPERED Price: $19.51 |
| 7 |
8392J |
LATCH BRACKET TI Price: Call Us |
| 8 |
109230X |
SPRING CRT Price: Call Us |
| 8 |
254-92 |
CONE-BEARING, OUTER Price: $15.84 |
| 9 |
102326X520 |
SHIELD.TINE Price: Call Us |
| 9 |
114-3908 |
HUB ASM This part replaces 92-9651. Price: $129.48 |
| 10 |
69-2980 |
SEAL Price: $33.94 |
| 10 |
72140506 |
BOLT Price: Call Us |
| 11 |
3272-12 |
PIN-COTTER Price: $0.25 |
| 11 |
73220500 |
NUT.HEX.5/16-18 Price: Call Us |
| 12 |
10040500 |
LOCKWASHER Price: Call Us |
| 12 |
98-8839 |
DISCONTINUED Price: Call Us |
| 13 |
72110510 |
BOLT Price: Call Us |
| 13 |
93-0309 |
WASHER-TAB Price: $3.52 |
| 14 |
124343X |
BRKT SHIELD TINE Price: Call Us |
| 14 |
93-0307 |
NUT-LOCK, RETAINER Price: $3.36 |
| 15 |
100-3769 |
PROTECTOR-BEARING Price: $41.94 |
| 15 |
104101X520 |
SHIELD.SD.OUT.RH Price: Call Us |
| 16 |
73220400 |
SUB= 50675 Price: Call Us |
| 17 |
10040400 |
LOCKWASHER Price: Call Us |
| 18 |
72040410 |
BOLT Price: Call Us |
| 19 |
102701X |
GRIP CRT Price: Call Us |
| 20 |
73220600 |
NUT.HEX.3/8-16UNC Price: Call Us |
| 21 |
102156X |
SUB= 102156X500 Price: Call Us |
| 22 |
74930632 |
BOLT Price: Call Us |
| 23 |
4440J |
HINGE CRT Price: Call Us |
| 24 |
72140404 |
BOLT Price: Call Us |
| 25 |
6712 |
J VINYL CAP TI Price: Call Us 6712 J |
| 26 |
109227X |
PAD IDLER TI Price: Call Us |
| 27 |
102695X520 |
SHIELD.LEVELING Price: Call Us |
| 28 |
120588X |
PIN HINGE Price: Call Us |
