| Ref | Part Number | Description |
|---|
| 1 |
710-04454 |
HEX SCREW #10-32 This part replaces GW-9782. Price: $3.71 |
| 2 |
GW-9463 |
KNOB-TAPERED Price: $10.32 |
| 3 |
GW-2263 |
PLATE-TINE ENGAGE W/DECAL #2599 (#4) Price: $45.91 |
| 4 |
777I20945 |
LABEL-TINES/PTO CL This part replaces GW-2599. Price: $4.38 |
| 5 |
1186349 |
SCR-HFLK 3/8-16X1.50 This part replaces GW-90047. Price: $3.11 |
| 6 |
N/A |
THIS REF. NOT USED |
| 7 |
710-04043 |
SCREW 5/16-18 This part replaces GW-90044. Price: $3.96 |
| 8 |
N/A |
THIS REF. NOT USED |
| 9 |
736-0567 |
NYLON FLAT WASHER Not Available This part replaces GW-9902. Price: |
| 10 |
1900870001 |
Clutch Bracket This part replaces GW-2149. Price: $156.99 |
| 11 |
GW-9362 |
PIN-SPRING .125 X 1 Price: $3.82 |
| 13 |
GW-9934 |
WASHER-# SHOULDER ZP (SHLDR FACES DISC WSHRS) Price: $13.73 |
| 16 |
719-04015P |
Power Unit Transmission Cover This part replaces GW-2523. Price: $204.95 |
| 16A |
GW-2566 |
ASSM-TRANS Not Available Price: |
| 17 |
GW-1123 |
GASKET-TRANS COVER Price: $7.44 |
| 18 |
710-0376 |
Hex Screw, 5/16-18 x 1.00 This part replaces GW-9751. Price: $3.66 |
| 19 |
712-3010 |
HEX NUT 5/16-18 This part replaces GW-9801. Price: $3.89 |
| 20 |
1901439 |
SPRING-REV PLUNGER ZP This part replaces GW-1496. Price: $10.67 |
| 21 |
GW-1035 |
ASSM-NEUTRAL PLUNGER W/ CLIP RING #22 (9504) Price: $33.23 |
| 22 |
1901440 |
RING-KLIP EXT .594 ID ZP This part replaces GW-9504. Price: $4.79 |
| 23 |
1186393 |
NUT-HFLK 3/8-16 This part replaces GW-9831. Price: $2.63 |
| 24 |
1902004 |
SCR 3/8-16X1.5 UNC-2AG This part replaces GW-9545. Price: $7.46 |
| 25 |
786-04002 |
Tines/PTO Clutch Lever This part replaces GW-2122. Price: $49.65 |
| 26 |
710-3013 |
SCREW 1/4-20X.5 GR5 This part replaces GW-9743. Price: $4.02 |
| 27 |
741-04008 |
Tines/PTO Clutch Bushing This part replaces GW-2123. Price: $25.38 |
| 28 |
GW-9516 |
RING-RETAINING 5100-50 Price: $3.56 |
| 29 |
1902404 |
CLUTCH KIT This part replaces GW-2130. Price: $146.17 |
| 30 |
GW-9911 |
WASHER-LK .25 HI-COLLAR Price: $5.23 |
| 31 |
710-04354 |
Screw, 1/4-20 x.375 This part replaces GW-9672. Price: $3.38 |
| 32 |
736-04304 |
Flat Washer, 1.25 x .75 x .06 This part replaces GW-50043. Price: $3.86 |
| 33 |
716-0101 |
Retaining Ring-external This part replaces GW-9500. Price: $3.37 |
| 34 |
1902404 |
CLUTCH KIT This part replaces GW-2120-3. Price: $146.17 |
| 35 |
GW-9301 |
KEY-.188 SQX1.0 (USED ON DRVE & PINION SHFTS) Price: $3.46 |
| 36 |
710-0157 |
HEX SCREW 5/16-24 x .75 This part replaces GW-9655. Price: $3.90 |
| 37 |
736-04193 |
Washer, 396 x 1140 x 095, B&S This part replaces GW-9944. Price: $5.94 |
| 38 |
GW-2107 |
PULLEY-TRANS MACH Price: $127.93 |
| 39 |
GW-50027 |
WASHER-SHLDR HARDENED Price: $5.94 |
| 40 |
710-3015 |
Hex Cap Screw, 1/4-20 x .75 This part replaces GW-9701. Price: $3.65 |
| 41 |
936-0329 |
Lock Washer This part replaces GW-9910. Price: $3.90 |
| 42 |
718-04007 |
Front Bearing Cap This part replaces GW-2424. Price: $16.60 |
| 43 |
921-04044 |
Oil Seal, .750 x 125 This part replaces GW-9600. Price: $8.80 |
| 44 |
GW-1124-2099 |
BEARING COVER GASKET This part replaces GW-1124-2. Price: $3.98 |
| 45 |
736-04305 |
Washer, Flat, 1.50 x 1.75 x .062 This part replaces GW-1224-4. Price: $3.52 |
| 45 |
736-04306 |
Washer, Flat, 1.50 x 1.75 x .005 This part replaces GW-1224-3. Price: $3.85 |
| 45 |
736-04307 |
Washer, Flat, 1.50 x 1.75 x .03 This part replaces GW-1224-2. Price: $3.85 |
| 45 |
736-04308 |
Washer, Flat, 1.50 x 1.75 x .010 This part replaces GW-1224-1. Price: $3.85 |
| 46 |
941-0107 |
Bearing, Tapered Roller (with race) This part replaces GW-1714. Price: $41.81 |
| 48 |
921-04030 |
Oil Seal, .75 x 1.783 This part replaces GW-9617. Price: $11.33 |
| 49 |
716-04102 |
Retaining Ring, Int This part replaces GW-9517. Price: $3.85 |
| 50 |
715-0121 |
Spirol Pin, 1/4 x 2.0 This part replaces GW-9309. Price: $5.95 |
| 51 |
GW-1060A |
PLUG-PINION BRG W/ Not Available Price: |
| 52 |
GW-9604 |
RING-O 1 ID Price: $4.62 |
| 53 |
736-04310 |
Flat Washer, 1/234 x 1.015 x .062 This part replaces GW-1132-2. Price: $3.95 |
| 53 |
GW-1132-3 |
SHIM-1.234X1.015X.01 Price: $5.95 |
| 54 |
GW-9404 |
BRG-BALL (7 BALLS) Price: $24.30 |
| 55 |
736-0272 |
FLAT WASHER .510 x .995 This part replaces GW-1126. Price: $4.37 |
| 56 |
GW-1222 |
GEAR-SPLINE 10 TEETH MACH Price: $122.90 |
| 57 |
716-04119 |
External Retaining Ring, 1.387 ID This part replaces GW-9502. Price: $12.96 |
| 58 |
GW-1221 |
BRONZE WORM GEAR 36 TEETH Not Available Price: |
| 59 |
GW-9300 |
KEY Price: $3.22 |
| 60 |
GW-1233 |
GEAR-SPUR 20 TEETH MACH Price: $125.18 |
| 61 |
921-04031 |
Oil Seal, 1.0 x 1.499 This part replaces GW-9621. Price: $9.58 |
| 62 |
716-04104 |
Retaining Ring This part replaces GW-9511. Price: $3.85 |
| 63 |
736-04257 |
Flat Washer, 1.375 x 1.015 x .005 This part replaces GW-1166-5. Price: $3.48 |
| 63 |
736-04258 |
Washer, 1.375 x 1.015 x .01 This part replaces GW-1166-4. Price: $3.48 |
| 63 |
736-04259 |
Washer, 1.375 x 1.015 x .015 This part replaces GW-1166-3. Price: $5.94 |
| 63 |
736-04260 |
Washer, 1.375 x 1.015 x .03 This part replaces GW-1166-2. Price: $5.94 |
| 63 |
736-04309 |
Washer, 1.375 x 1.015 x .062 This part replaces GW-1166-1. Price: $3.85 |
| 64 |
941-04300 |
Bushing, 1.25 x 1 x .005 x 1.5 This part replaces GW-1086. Price: $15.25 |
| 65 |
GW-1878 |
KIT-WHEELSHAFT (INCL 66 & 62) Price: $201.61 |
| 66 |
714-04014 |
Hi-Pro Key, .250 x 1.8125 This part replaces GW-9357. Price: $18.36 |
| 67 |
GW-1223 |
GEAR-SPUR 56 TEETH MACH Price: $196.25 |
| 68 |
GW-1232 |
GEAR-SPUR 46 TEETH MACH Price: $135.63 |
| 69 |
GW-1237 |
CLUTCH-MACH Price: $142.70 |
| 70 |
GW-1112 |
PIN-CLUTCH .25 2.65 Price: $4.06 |
| 71 |
915-0246 |
Pin, Spring, 3/16 x 1.25 Not Available This part replaces GW-9307. Price: |
| 72 |
619-04000-0637 |
Wheel Speed Shifting Lever This part replaces GW-1029. Price: $53.27 |
| 73 |
921-04034 |
Oil Seal, .625 x 1.0 This part replaces GW-9622. Price: $9.37 |
| 74 |
738-04448 |
PIN This part replaces GW-1442. Price: $7.14 |
| 75 |
611-04003 |
Wheel Speed Shifting Shaft This part replaces GW-1568. Price: $78.82 |
| 76 |
GW-1441 |
SPRING .845 X 1.25 Price: $3.61 |
| 77 |
736-04079 |
Support Washer This part replaces GW-1440. Price: $4.13 |
| 78 |
GW-2109099 |
HOUSING-POWER UNIT TRA This part replaces GW-2260. Price: $822.57 |
| 79 |
GW-9359 |
PIN-DRIVE .375X.75 ZP Price: $3.22 |
| 80 |
1100067 |
HEX HEAD CAP SCREW Not Available This part replaces GW-9560. Price: |
| 81 |
GW-9928 |
WASHER-DISC SPRING (CONCAVE) Price: $11.23 |
| 82 |
GW-2126 |
POST (TC) Price: $27.91 |
| 83 |
1105620 |
PLUG-SQ HEAD 1/4-18 NPT This part replaces GW-9726. Price: $3.66 |
| 84 |
GW-9122 |
PLUG-CAP (RED) Price: $8.93 |
| 85 |
GW-9205 |
CLIP-CONNECTOR Not Available Price: |
